Manuals of product B914
Editorial note
The ACTi B914 product stands out for its exceptional image quality, offering a maximum resolution of 2048 x 1536 pixels and a total of 3 MP. These features ensure video recordings of remarkable clarity, making it an ideal choice for professional and personal needs. Additionally, its wired connectivity technology and PTZ Pelco-P/D protocols ensure effective control of the camera's movements, thus contributing to optimal surveillance. In terms of design, the ACTi B914 features an island format with vertical installation, allowing for aesthetic and practical integration in various environments. Its IP67 protection rating also guarantees weather resistance, making it reliable in varied conditions. However, this product has some drawbacks. The lack of night vision limits its effectiveness in low-light conditions. Furthermore, wireless connectivity, such as Wi-Fi and Bluetooth, is not available, which may complicate installation by requiring cables. The weight of 1495 g could also pose challenges when installing on fragile surfaces. Finally, the absence of an integrated hard drive means that users will need to invest in compatible memory cards for data storage. In summary, the ACTi B914 offers solid performance and design but has some limitations in terms of connectivity and night features. It is therefore recommended to consider these aspects before making a purchase decision.Score details
User experience
The user experience is overall positive, thanks to an intuitive interface and well-thought-out features, particularly behavior analysis for security.
Performance
The product offers exceptional image quality with a maximum resolution of 2048 x 1536 pixels and a total of 3 MP, ensuring precise details for video recordings.
Design
The functional island design with vertical installation allows for aesthetic and practical integration in various spaces, while meeting weather resistance standards with an IP67 protection rating.
Features
Features include wired connectivity technology and Pelco-P/D PTZ protocols, but the lack of night vision and wireless connectivity limits their use in certain situations.
Value for money
Although the product performs well, the absence of an integrated hard drive and the need to purchase compatible memory cards can represent an additional cost for users.
Robustness
The product is robust with an IP67 protection rating, ensuring reliable operation in various environmental conditions.
Usability
Installation can be complex due to the weight of 1495 g and the lack of Wi-Fi or Bluetooth connectivity, requiring cables for optimal use.
Advantages
3 MP image quality, precise details
PTZ control via Pelco-P/D protocols
Vertical installation, aesthetic design
Advanced noise reduction
Behavioral analysis for enhanced security
IP67 rating, weather-resistant
Disadvantages
No night vision available
No Wi-Fi and Bluetooth
High weight for delicate installation
No built-in hard drive
Insufficient noise reduction
Technical Specifications B914
General Information
-
ModelB914
-
Brand
-
Category
-
Type
-
SKU1955733
-
MPN1955733
Representation / realization
-
Connectivity technologyWith cable
-
PTZ ProtocolsPelco-P/D
-
Day/Night ModeYes
-
TypeIP security camera
-
Supported installationOutdoor
-
Day/Night ModeYes
-
Day/Night ModeYes
-
Day/Night ModeYes
Weight and dimensions
-
Diameter152.8 mm
-
Height131 mm
-
Weight1495 g
Video
-
Total megapixels3 MP
-
Number of images per second60 ips
-
Maximum resolution2048 x 1536 pixels
-
Visual compression formatsH.264, M-JPEG
-
Bitrate128Kbps - 12Mbps
-
Binary rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Scrolling and mirroringYes
-
Scrolling and mirroringYes
-
Noise reduction technology2D noise reduction, 3D noise reduction
-
Scrolling and mirroringYes
-
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
-
Scrolling and mirroringYes
-
Gain control typeAuto
Image sensor
-
Optical sensor size1/2.8 "
-
Effective pixel count (H x V)
-
2065 x 1553 pixels
Objective system
-
Maximum number of openings1.6
-
Minimum opening amount3
-
Optical zoom10 x
-
Zoom capacityYes
-
Number of lenses1
Camera
-
Field of view of the lens, horizontal58 °
-
Angle of view of the lens, vertical45.3 °
-
Panoramic-175 - 175 °
-
Inclination angle0 - 180 °
Network
-
Ethernet/LANYes
-
Supported network protocolsIPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X
-
Network standardsIEEE 802.1x, IEEE 802.3af
-
Ethernet/LANYes
-
BluetoothNo
-
BluetoothNo
Audio
-
Sampling frequency8 kHz
-
Voice codecsG.711, PCM
-
Audio system2-way
Power
-
Energy consumption (Power over Ethernet (PoE))12.2 W
-
Consumption (max)9.12 W
-
Output CC in volts12
-
Power supply typeDC, PoE
Design
-
International Protection Code (IP)IP67
-
FormatDome
-
Mounting typeCeiling/wall
-
Product colorWhite
-
Code IKIK10
Packaging contents
-
Number of cameras1
Night vision
-
Night visionNo
Environmental conditions
-
Operating temperature-40 - 50 °C
-
Operating relative humidity (H-H)10 - 85 %
Management features
-
Behavior analysisLine crossing detection
-
Unattended baggage detection
Security
-
Functions of the IVS system (intelligent video surveillance)Face detection
-
HTTPS encryptionYes
-
HTTPS encryptionYes
-
HTTPS encryptionYes
-
HTTPS encryptionYes
Connectivity
-
Number of Ethernet LAN ports (RJ-45)1
Storage support
-
Built-in memory card readerYes
-
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Integrated hard driveNo
Frequently Asked Questions
What is the weight of the ACTi B914?
What is the height of the ACTi B914?
Is the manual for the ACTi B914 available in French?
Similar products
More product categories from brand ACTi
More product types from brand ACTi
Presentation of product B914 specifications from brand ACTi
Generalities
The ACTi B914 model from the ACTi brand stands out for its reputation in quality and innovation in the electronic devices sector. This model is designed to offer optimal performance and an enhanced user experience. The EAN code, 4710751962750, allows for unique identification in the distribution system.
Representation / realization
The ACTi B914 integrates wired connectivity technology, facilitating practical use without the constraints of cumbersome wiring. Thanks to the PTZ Pelco-P/D protocols, it benefits from precise control of the camera movements, ensuring effective surveillance. The island design allows for vertical installation, optimizing space aesthetically. Additionally, the infrared cut filter improves image quality by blocking unwanted wavelengths, while the wide dynamic range and day/night mode ensure adaptability in various lighting conditions.
Weight and dimensions
With a diameter of 152.8 mm and a height of 131 mm, the ACTi B914 is designed to easily fit into different environments. Its weight of 1495 g ensures easy handling while guaranteeing optimal use.
Video
This model has a maximum resolution of 2048 x 1536 pixels and a total of 3 MP, ensuring exceptional image quality for detailed video recordings. With 60 frames per second, playback fluidity is optimal. The H.264 and M-JPEG compression formats ensure top-notch visual quality. Furthermore, the ACTi B914 offers features such as real-time video streaming and personal data masking to protect user information.
Image sensor
The 1/2.8" optical sensor contributes to sharp and detailed images, with effective pixels of 2065 x 1553, ensuring precise image quality.
Lens system
The lens system features a maximum aperture of 1.6 and a minimum aperture of 3, facilitating shooting in low-light conditions. With a 10x optical zoom, it allows capturing distant details. The number of lenses is 1, determining the versatility of the lens.
Camera
The field of view of 58° and the vertical field of view of 45.3° allow for wide and dynamic captures. The pan range of -175 to 175° and the tilt angle of 0 to 180° provide optimal adjustment for user comfort.
Network
The ACTi B914 supports various network protocols, including IPv4/v6 and TCP, ensuring effective communication. Although it is equipped with an Ethernet LAN port, it does not have Wi-Fi or Bluetooth connectivity, which may limit its flexibility. Quality of Service (QoS) ensures optimal management of network resources.
Audio
This model offers a sampling frequency of 8 kHz and uses G.711 and PCM codecs for optimal audio quality. Its stereo audio system provides an immersive sound experience.
Power
The power consumption of the ACTi B914 is 12.2 W, allowing for power supply via the Ethernet network, while the maximum consumption is 9.12 W. It operates on a DC power source, PoE, ensuring efficient performance.
Design
With an IP67 protection rating, the ACTi B914 is weather-resistant, making it reliable in various conditions. Its ceiling/wall mount facilitates installation, and its white color gives it a modern appearance. The IK10 rating indicates increased robustness against impacts.
Packaging content
The product includes a camera, allowing for high-quality image capture.
Night vision
It is important to note that the ACTi B914 does not have night vision functionality, which may limit its effectiveness in low-light conditions.
Environmental conditions
Designed to operate within a temperature range of -40 to 50 °C, this model is suitable for various environments. It also supports a relative humidity of operation from 10 to 85 %.
Management features
The system is equipped with behavior analysis, allowing for intrusion detection and monitoring of passage lines, thereby enhancing security.
Security
Security features include face and intrusion detection, as well as password protection. The motion detector and IP address filtering enhance data protection.
Connectivity
The ACTi B914 is equipped with an Ethernet LAN port for stable network connection but does not offer wireless connectivity.
Storage support
This model includes a built-in memory card reader, compatible with MicroSD, MicroSDHC, and MicroSDXC, but does not have an internal hard drive.
