Manual of product P3245-VE
Technical Specifications P3245-VE
General Information
-
ModelP3245-VE
-
Brand
-
Category
-
Type
-
SKU1138499
-
MPN1138499
Representation / realization
-
TypeIP security camera
-
PTZ ControlYes
-
PTZ ControlYes
-
PTZ ControlYes
-
Connectivity technologyWired
-
PTZ ControlYes
-
CertificationEN 55032 A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-3(A)/NMMB-3(A), VCCI A, RCM AS/NZS CISPR 32 A, KC KN32 A, KC KN35
-
Number of languagesIEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IS 13252
-
Languages taken into accountIEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14,
-
Supported installationIEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-78
-
IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X
-
NIST SP500-267
-
11
-
CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
-
Outdoor
Image sensor
-
Progressive scanYes
-
Optical sensor size1/2.8 "
-
Number of sensors1
-
Sensor typeCMOS
Objective system
-
Number of lenses1
-
Focal length3.4 - 8.9 mm
-
Maximum number of openings1.8
Camera
-
Field of view of the lens, horizontal100 °
-
Angle of view of the lens, vertical53 °
-
Minimum illumination0.02 lux
-
Camera shutter speed1/66500 - 2 s
-
Panoramic-180 - 180 °
-
Inclination angle-75 - 75 °
-
Rotation angle175 °
-
Camera tilt controlYes
-
Camera tilt controlYes
Video
-
Video broadcastingYes
-
Visual compression formatsAVC, H.264, H.265, HEVC, M-JPEG, MPEG4
-
Maximum resolution1920 x 1080 pixels
-
Total megapixels- MP
-
Number of images per second60 fps
-
Binary rate controlVariable Bit Rate (VBR)
-
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
-
Supported video modes1080p
Packaging contents
-
Number of cameras1
-
User manualYes
Security
-
HTTPS encryptionYes
-
HTTPS encryptionYes
-
HTTPS encryptionYes
Network
-
Network standardsIEEE 802.1x
-
Supported network protocolsIEEE 802.3af
-
Ethernet/LANIEEE 802.3at
-
Ethernet/LAN
-
BluetoothIPv4
-
BluetoothIPv6 USGv6
-
Type of Ethernet interfaceHTTP
-
HTTPSa
-
SSL/TLSa
-
QoS Layer 3 DiffServ
-
FTP
-
SFTP
-
CIFS/SMB
-
SMTP
-
Bonjour
-
UPnP®
-
SNMP v1/v2c/v3 (MIB-II)
-
DNS
-
DynDNS
-
NTP
-
RTSP
-
RTP
-
SRTP
-
TCP
-
UDP
-
IGMP
-
RTCP
-
ICMP
-
DHCP
-
ARP
-
SOCKS
-
SSH
-
SIP
-
LLDP
-
-
Yes
-
Yes
-
No
-
No
-
Fast Ethernet
Design
-
Product colorWhite
-
FormatDome
-
Mounting typeCeiling/wall
-
International Protection Code (IP)IP66
-
Code IKIK10
Storage support
-
Internal memory1024 MB
-
Flash memory512 MB
-
Integrated hard driveNo
-
Built-in memory card readerYes
-
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Power
-
Power supply typePoE
-
Energy consumption (Power over Ethernet (PoE))8 W
-
Typical electricity consumption3.5 W
Connectivity
-
Number of Ethernet LAN ports (RJ-45)1
Environmental conditions
-
Operating temperature-40 - 50 °C
-
Operating relative humidity (H-H)10 - 100 %
-
Temperature out of operation-40 - 65 °C
-
Relative humidity rate (storage)5 - 95 %
Weight and dimensions
-
Diameter149 mm
-
Height104 mm
-
Weight800 g
Night vision
-
Night vision-
Logistics data
-
Harmonized System Code85258900
Similar products
More product categories from brand Axis
More product types from brand Axis
Presentation of product P3245-VE specifications from brand Axis
Generalities
The brand of the product Axis P3245-VE is Axis. This brand is known for its quality and innovation in the field of household appliances. The EAN code of the product Axis P3245-VE is 7331021065673. This code allows for the unique identification of the product in the distribution system. The product model Axis P3245-VE is P3245-VE | 01594-001. This model ensures optimal performance and an enhanced user experience.
Image sensor
Does the product Axis P3245-VE have a Progressive Scan? Oui. This feature allows for superior image quality by displaying each image in its entirety, thus providing a smoother and sharper visual experience. The number of sensors of the product Axis P3245-VE is 1. This number of sensors allows for precise and efficient image detection. The sensor type of the product Axis P3245-VE is CMOS. This type of sensor ensures optimal image quality for your needs. The optical sensor size of the product Axis P3245-VE is 1/2.8 ". This size contributes to better image quality, allowing for sharper and more detailed shots.
Objective system
The maximum number of openings for the product Axis P3245-VE is 1.8. This feature allows for optimal use and increased flexibility. The focal length of the product Axis P3245-VE is 3.4 - 8.9 mm. This specification determines the field of view and the distance at which subjects can be captured accurately. The number of lenses in the product Axis P3245-VE is 1. This number determines the quality and versatility of the lens.
Representation / realization
The type of product Axis P3245-VE is an island. This type of design offers a functional and aesthetic solution to optimize space in your interior. Does the product Axis P3245-VE have a Day/Night Mode? Oui. This feature allows for adjusting the lighting according to the time of day, thus providing optimal comfort. Does the product Axis P3245-VE have a Wide Range Dynamic (WRD)? Oui. This specification ensures optimal performance and increased adaptability in various conditions. Does the product Axis P3245-VE have an infrared cut filter? Oui. This filter blocks infrared wavelengths, thereby improving image quality and color accuracy. The product Axis P3245-VE features a Avec fil connectivity technology. This functionality allows for practical and flexible use without the constraints of cables. The PTZ control of the product Axis P3245-VE is Oui. This control allows for precise and efficient management of pan, tilt, and zoom. The languages considered for the product Axis P3245-VE are CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS. This product thus caters to a wide international audience. The design of the product Axis P3245-VE supports vertical installation. This feature allows for optimal integration into various spaces, thus offering flexibility and practicality. The certification of the product Axis P3245-VE contains EN 55032 A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-3(A)/NMMB-3(A), VCCI A, RCM AS/NZS CISPR 32 A, KC KN32 A, KC KN35\nIEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IS 13252\nIEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, \nIEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-78\nIEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X\nNIST SP500-267. This certification guarantees compliance with the required safety and performance standards. The number of languages of the product Axis P3245-VE is 11. This product offers an enriching multilingual experience.
Packaging contents
The number of cameras of the product Axis P3245-VE is 1. This product is equipped with a camera that allows capturing high-quality images. Does the product Axis P3245-VE have a User Manual? Oui. This document provides clear instructions for optimal use of the product.
Camera
The field of view of the Axis P3245-VE lens is 100 °. This field of view allows for capturing images with a wide perspective, ideal for landscapes and group shots. The minimum illumination of the product Axis P3245-VE is 0.02 lux. This feature ensures optimal performance even in low light conditions. The vertical field of view of the product Axis P3245-VE is 53 °. This field of view allows for image capture with an expanded perspective, ideal for dynamic compositions. The shutter speed of the camera of the product Axis P3245-VE is 1/66500 - 2 s. This feature allows capturing sharp images even in low light conditions. The panoramic view of the product Axis P3245-VE is -180 - 180 °. This specification allows for an expanded overview, ideal for capturing landscapes or wide scenes. The tilt angle of the product Axis P3245-VE is -75 - 75 °. This angle allows for adjusting the position for optimal comfort. The rotation angle of the product Axis P3245-VE is 175 °. This angle allows for optimal usage flexibility. Does the product Axis P3245-VE have a camera pan command? No. This feature is not available on this model. The tilt command of the Axis P3245-VE camera is %. This feature allows you to adjust the viewing angle to capture images from different perspectives.
Security
Does the product Axis P3245-VE have HTTPS Encryption? Oui. This encryption ensures the security of the data exchanged between the user and the site. Does the Axis P3245-VE product filter IP addresses? Oui. This feature enhances security by blocking unauthorized access. Does the product Axis P3245-VE have Password Protection? Oui. This feature ensures the security of your data by restricting unauthorized access.
Video
Does the product Axis P3245-VE have a video broadcast? Oui. This feature allows sharing content in real-time with a large audience. The product Axis P3245-VE has visual compression formats: AVC, H.264, H.265, HEVC, M-JPEG, MPEG4. These formats ensure optimal image quality for your videos. The maximum resolution of the product Axis P3245-VE is 1920 x 1080 pixels. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. The total megapixels of the product Axis P3245-VE is - MP. This total ensures exceptional image quality for your photos. The number of frames per second of the product Axis P3245-VE is 60 ips. This specification ensures optimal smoothness when playing videos. The binary bitrate control of the product Axis P3245-VE contains Débit binaire variable (VBR). This control allows for optimizing video quality while effectively managing file sizes. The image quality setting of the product Axis P3245-VE contains Brightness, Contrast, Saturation, Sharpness. This setting allows for optimizing the display for an enhanced visual experience. The supported video mode of the product Axis P3245-VE is 1080p. This mode allows you to enjoy optimal image quality for your videos.
Design
The color of the product Axis P3245-VE is Blanc. This shade gives it a modern and elegant look. The mounting type of the product Axis P3245-VE is Plafond/mur. This type of mounting ensures easy and quick installation, thus guaranteeing optimal use of the product. The format of the product Axis P3245-VE is a bar. This format allows for practical and efficient use in various contexts. The International Protection Code (IP) for product Axis P3245-VE contains IP66. This code indicates the level of protection against solid objects and moisture. The IK Code of the product Axis P3245-VE is IK10. This IK Code allows for easy identification of the specific design of the item.
Network
Does the product Axis P3245-VE have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. Does the product Axis P3245-VE have Quality of Service (QoS)? Oui. This feature ensures optimal management of network resources, thus providing a smooth and uninterrupted user experience. The supported network protocols of the product Axis P3245-VE are IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, SIP, LLDP. These protocols ensure efficient and reliable communication for your networking needs. The network standards of the product Axis P3245-VE are IEEE 802.1x, IEEE 802.3af, IEEE 802.3at. These standards ensure optimal compatibility with various equipment and protocols. The Wifi of the product Axis P3245-VE contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices. Does the Axis P3245-VE have Bluetooth? Non. This feature allows for a convenient wireless connection with other compatible devices. The Ethernet interface type of the product Axis P3245-VE is Fast Ethernet. This type of interface allows for fast and efficient network connections.
Power
The type of power source for the product Axis P3245-VE is PoE. This type of power supply ensures optimal performance and efficient use of the device. The typical power consumption of the product Axis P3245-VE is 3.5 W. This feature allows for the assessment of the energy efficiency of the device. The energy consumption of the product Axis P3245-VE is 8 W. This specification allows powering devices via the Ethernet network, thus providing a practical and efficient solution to reduce the number of cables needed.
Storage support
The internal memory of the product Axis P3245-VE contains 1024 Mo. This memory allows for the storage of a large amount of data and applications for smooth and efficient use. The product Axis P3245-VE has a flash memory of 512 Mo. This memory provides an ideal storage capacity for your files, photos, and videos. Does the Axis P3245-VE have a built-in hard drive? No. This feature means that the product does not have internal storage. Does the Axis P3245-VE have a built-in memory card reader? Oui. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution. The product Axis P3245-VE has compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC. These memory cards ensure optimal performance for storing your data.
Connectivity
The number of Ethernet LAN (RJ-45) ports of the product Axis P3245-VE is 1. These ports provide a stable and fast network connection for your devices.
Night vision
Does the product Axis P3245-VE have night vision? -. This feature allows for clear visibility in the dark, thus providing enhanced security.
Weight and dimensions
The diameter of the product Axis P3245-VE is 149 mm. This diameter allows for optimal use and fits perfectly with your needs. The height of the product Axis P3245-VE is 104 mm. This dimension is essential to ensure that the product fits perfectly in your space. The weight of the product Axis P3245-VE is 800 g. This weight is ideal for ensuring optimal use and easy handling.
Environmental conditions
The operating temperature of the product Axis P3245-VE is -40 - 50 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The non-operating temperature of the product Axis P3245-VE is -40 - 65 °C. This specification ensures that the product can withstand extreme conditions without suffering damage. The relative humidity (storage) rate of the product Axis P3245-VE is 5 - 95 %. This rate ensures optimal conditions for the preservation and durability of the product. The product Axis P3245-VE has an operating relative humidity (H-H) of 10 - 100 %. This specification ensures optimal operation in a wide range of ambient humidity.
Logistics data
The Harmonized System code for the product Axis P3245-VE is 85258900. This code allows for the unique identification of goods in international trade.
