Manual of product 3BC497GN
Technical Specifications 3BC497GN
General Information
-
Model3BC497GN
-
Brand
-
Category
-
Type
-
SKU799551
-
MPN799551
Design
-
Diameter of the exhaust duct150 mm
-
Number of engines2
-
Engine includedYes
-
Cable length1.3 m
-
Built-in screenNo
-
TypeWall-mounted
-
Product colorBlack, Stainless steel
-
Escape locationHigh
-
Material of the case/bodyGlass
-
Order typeTouch
-
CertificationCE, VDE
Power
-
Annual energy consumption39 kWh
-
Energy efficiency classA
-
Connected charge143 W
-
Engine power140 W
-
AC input voltage220-240 V
-
AC input frequency50 - 60 Hz
-
Current10 A
Lighting
-
Type of bulbLED
-
Power of the bulb3 W
-
Number of bulbs2 bulb(s)
Representation / realization
-
Minimum distance of an electric plate450 mm
-
Minimum distance from a gas plate600 mm
-
Maximum extraction power730 m³/h
-
Type of extractionDuct / Recirculation
-
Lighting efficiency classA
-
Lighting efficiency classA
-
Grease filtration efficiency classC
-
Number of speeds3
-
Intensive speedYes
-
Sound level (fast speed)56 dB
-
Sound level (fast speed)56 dB
-
Sound level (intensive speed)70 dB
-
The maximum recirculation power290 m³/h
-
Sound level (slow speed)43 dB
Filtering
-
Type of grease filterAluminium
-
Washable filterYes
-
Washable filterYes
-
Washable filterYes
Weight and dimensions
-
Width890 mm
-
Depth281 mm
-
Height- mm
-
Height (min)1003 mm
-
Height (max)1333 mm
-
Height without the chimney535 mm
-
Weight20000 g
Similar products
More product categories from brand Balay
More product types from brand Balay
Presentation of product 3BC497GN specifications from brand Balay
Generalities
The product model Balay 3BC497GN is 3BC497GN | 3BC497GN. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Balay 3BC497GN is 4242006264406. This code allows for the unique identification of the product in the distribution system. The brand of the product Balay 3BC497GN is Balay. This brand is known for its quality and innovation in the field of household appliances.
Lighting
The type of bulb for the product Balay 3BC497GN is LED. This bulb offers intense brightness and an extended lifespan. The power of the bulb of the product Balay 3BC497GN is 3 W. This specification ensures optimal lighting for your needs. The number of bulbs in the product Balay 3BC497GN is 2 ampoule(s). This detail is essential to ensure adequate brightness in your space.
Power
The annual energy consumption of the product Balay 3BC497GN is 39 kWh. This specification allows you to assess energy efficiency and the impact on your electricity bill. The engine power of the product Balay 3BC497GN is 140 W. This power ensures optimal performance for efficient use. The product Balay 3BC497GN has a connected charge of 143 W. This specification ensures optimal performance and increased energy efficiency. The energy efficiency class of the product Balay 3BC497GN is A. This class indicates the level of energy performance of the product, thereby contributing to energy savings and reducing environmental impact. The AC input voltage of the Balay 3BC497GN is 220-240 V. This specification ensures optimal compatibility with standard electrical systems. The AC input frequency of the product Balay 3BC497GN is 50 - 60 Hz. This specification is essential to ensure optimal operation and compatibility with electrical systems. The current of the product Balay 3BC497GN is 10 A. This current ensures optimal performance and safe use.
Design
The diameter of the exhaust duct for the product Balay 3BC497GN is 150 mm. This diameter is essential for ensuring effective evacuation of smoke or gases. Does the product Balay 3BC497GN come with a motor included? Oui. This ensures optimal performance and immediate use. The number of engines of the product Balay 3BC497GN is 2. This unique engine ensures optimal performance and increased efficiency. The cable of the product Balay 3BC497GN has a length of 1.3 m. This length allows for flexible and practical use in various environments. The Balay 3BC497GN has a built-in screen. This screen provides an immersive and convenient visual experience, making it easier to use the device. The type of product Balay 3BC497GN is an island. This type of design offers a functional and aesthetic solution to optimize space in your interior. The color of the product Balay 3BC497GN is Black, Stainless steel. This shade gives it a modern and elegant look. The material of the product case Balay 3BC497GN is Verre. This material ensures both durability and elegance. The product Balay 3BC497GN order type consists of Tactile. This order type allows for intuitive and practical use. The certification of the product Balay 3BC497GN contains CE, VDE. This certification guarantees compliance with the required safety and performance standards. The exhaust location of the product Balay 3BC497GN is Haut. This exhaust location ensures efficient gas evacuation, thus contributing to optimal operation.
Filtering
Does the product Balay 3BC497GN have a removable filter? Oui. This filter allows for easy and quick maintenance, thus ensuring optimal use of your device. Does the product Balay 3BC497GN have a waterproof dishwasher filter? Oui. This filter ensures optimal protection against leaks, thus ensuring efficient operation of your dishwasher. The grease filter type of the product Balay 3BC497GN is made of Aluminium. This aluminum filter ensures excellent performance in capturing fats and residues, thus guaranteeing a clean and healthy cooking environment. Does the product Balay 3BC497GN have a washable filter? Oui. This filter is designed to be easily cleaned and reused, ensuring optimal performance and increased durability.
Weight and dimensions
The minimum height of the product Balay 3BC497GN is 1003 mm. This dimension ensures optimal use tailored to your needs. The height of the product Balay 3BC497GN is - mm. This dimension is essential to ensure that the product fits perfectly in your space. The depth of the product Balay 3BC497GN is 281 mm. This dimension allows for optimal integration into your space. The width of the product Balay 3BC497GN is 890 mm. This dimension is essential to ensure optimal integration into your space. The maximum height of the product Balay 3BC497GN is 1333 mm. This dimension is essential to ensure that the product fits perfectly in your space. The height without the chimney of the product Balay 3BC497GN is 535 mm. This dimension is essential to ensure the product fits in your space. The weight of the product Balay 3BC497GN is 20000 g. This weight is ideal for ensuring optimal use and easy handling.
Representation / realization
The minimum distance of an electric plate from the product Balay 3BC497GN is 450 mm. This specification ensures safe and optimal use of the device. The maximum extraction power of the product Balay 3BC497GN is 730 m³/h. This feature ensures optimal efficiency in eliminating odors and particles from the air. The minimum distance of a gas plate from the product Balay 3BC497GN is 600 mm. This specification ensures safe and efficient use of the device. The extraction type of the product Balay 3BC497GN is Conduit / Recirculation. This extraction type determines the method used to obtain the essential elements of the product. The dynamic efficiency class of the fluid of the product Balay 3BC497GN is A. This class indicates the energy performance of the fluid in question. The lighting efficiency class of the product Balay 3BC497GN is A. This class allows for the assessment of the energy performance of the proposed lighting. The grease filtering efficiency class of the product Balay 3BC497GN is C. This class ensures optimal grease filtration, thus providing a healthier cooking environment and better performance of your appliance. The number of speeds of the product Balay 3BC497GN is 3. This number of speeds allows for easy adjustment of performance according to the user's needs. The intensive speed of the product Balay 3BC497GN is Oui. This feature allows for optimizing performance and improving efficiency during its use. The maximum recirculation power of the product Balay 3BC497GN is 290 m³/h. This feature ensures optimal efficiency in air treatment, thus providing a pleasant and healthy environment. The sound level of the product Balay 3BC497GN is 56 dB. This sound level ensures a pleasant user experience without being too intrusive. The noise level of the product Balay 3BC497GN is 56 dB. This noise level allows for pleasant use without excessive noise disturbances. The noise level (intensive speed) of the product Balay 3BC497GN is 70 dB. This noise level ensures efficient performance while maintaining user comfort. The sound level of the product Balay 3BC497GN is 43 dB. This sound level allows for discreet and pleasant use, ideal for quiet environments.
