Manual of product 1000W Power Zone
Technical Specifications 1000W Power Zone
General Information
-
Model1000W POWER ZONE
-
Brand
-
Category
-
Type
-
SKU131394
-
MPN131394
Power
-
Total power1000 W
-
AC input voltage100 - 240 V
-
AC input frequency50 - 60 Hz
-
Input current12 A
-
Power factor0.99
-
Type of Power Factor Corrector (PFC)Active
-
Maximum input current (@110 V)+12V, +3.3V, +5V, +5Vsb, -12V A
-
Combined power (+5V)170 W
-
Combined power (+12 V)996 W
-
Combined power (+5V)170 W
-
Combined power (-12V)3.6 W
-
Combined power (+5Vsb)15 W
-
Maximum output current (+5V)25 A
-
Maximum output current (+12V)83 A
-
Maximum output current (+5V)25 A
-
Maximum output current (-12V)0.3 A
-
Maximum output current (+5Vsb)3 A
-
Holding time23 ms
-
Effectiveness89 %
-
Electrical protection devicesOver current, Over power, Over voltage, Overheating, Short circuit, Under voltage
-
Peak power1050 W
Design
-
Fan diameter135 mm
-
Fan speed2900 rpm
-
Number of fans1 fan(s)
-
Cooling typeActive
-
Product colorBlack
Connectivity
-
Motherboard connector20+4 pin ATX
-
Number of SATA power cables10
-
PCI Express power connectors (6 +2 pin)6
-
PCI Express power connectors (6 +2 pin)6
-
CPU power connector (4+4 pin)Yes
-
CPU power connectors (8-pin)1
-
CPU power connectors (8-pin)1
-
Wiring typeFully modular
Representation / realization
-
Sound level37.1 dB
-
Mean time between failures100000 h
-
80 PLUS Certification80 PLUS Bronze
-
Form factor of the power supply unitATX
-
UtilityPC
-
Version ATX2.4
-
Version EPS2.92
-
CertificationCE, CB, TÜV, Semko (S), FCC, cTUVus, c-tick, BSMI
-
Rolling technologyFDB
Weight and dimensions
-
Width150 mm
-
Depth175 mm
-
Height86 mm
-
Weight2150 g
Technical details
-
Sustainability certificatesRoHS
-
ENERGY STAR
Packaging information
-
User manualYes
-
Package width248 mm
-
Package depth102 mm
-
Package height328 mm
-
Package weight2640 g
Other features
-
Noise level (silent mode, < 30 %)15.7 dB
-
Noise level (silent mode, 50 %)20.1 dB
-
Noise level (full charge mode, 100 %)37.1 dB
Similar products
More product categories from brand Be Quiet!
More product types from brand Be Quiet!
Presentation of product 1000W Power Zone specifications from brand Be Quiet!
Generalities
The brand of the product Be Quiet! 1000W Power Zone is Be Quiet!. This brand is known for its quality and innovation in the field of household appliances. The product model Be Quiet! 1000W Power Zone is 1000W Power Zone | BN213. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Be Quiet! 1000W Power Zone is 4260052183120. This code allows for the unique identification of the product in the distribution system.
Connectivity
The connector on the motherboard of the product Be Quiet! 1000W Power Zone contains 20+4 pin ATX. This connector is essential for ensuring a stable and reliable connection between the motherboard and the other components of the system. The number of SATA power cables for the product Be Quiet! 1000W Power Zone is 10. These cables provide a reliable and efficient connection to power your components. The Molex peripheral connector (4-pin) of the product Be Quiet! 1000W Power Zone contains 6. This connector is essential for ensuring a reliable connection between electronic components. The PCI Express power connector (6 +2 pin) of the product Be Quiet! 1000W Power Zone contains 6. This connector is essential for providing stable and efficient power to graphics cards and other components requiring a PCIe connection. Does the Be Quiet! 1000W Power Zone have a CPU power connector (4+4 pin)? Oui. This connector is essential for providing stable and efficient power to your processor. The power connector of the floppy disk drive of the product Be Quiet! 1000W Power Zone contains 1. This connector is essential to ensure adequate power supply to the floppy disk drive. The CPU power connector (8-pin) of the product Be Quiet! 1000W Power Zone contains 1. This connector is essential for ensuring stable and efficient power supply to your processor. The wiring type of the product Be Quiet! 1000W Power Zone is Entièrement modulaire. This non-modular wiring ensures a stable and reliable connection.
Design
The diameter of the Be Quiet! 1000W Power Zone fan is 135 mm. This diameter is essential for ensuring optimal air circulation. The cooling type of the product Be Quiet! 1000W Power Zone is active. This system ensures optimal temperature management for improved performance. The fan speed of the product Be Quiet! 1000W Power Zone is 2900 tr/min. This feature allows you to adjust the airflow according to your needs. The number of fans of the product Be Quiet! 1000W Power Zone is 1 ventilateur(s). This design allows for better air circulation and optimal performance. The color of the product Be Quiet! 1000W Power Zone is Noir. This shade gives it a modern and elegant look.
Technical details
The product Be Quiet! 1000W Power Zone has Sustainability Certificates: RoHS, ENERGY STAR. These certificates ensure that the product meets high standards for energy efficiency and environmental respect.
Weight and dimensions
The width of the product Be Quiet! 1000W Power Zone is 150 mm. This dimension is essential to ensure optimal integration into your space. The depth of the product Be Quiet! 1000W Power Zone is 175 mm. This dimension allows for optimal integration into your space. The height of the product Be Quiet! 1000W Power Zone is 86 mm. This dimension is essential to ensure that the product fits perfectly in your space. The weight of the product Be Quiet! 1000W Power Zone is 2150 g. This weight is ideal for ensuring optimal use and easy handling.
Power
The AC input frequency of the product Be Quiet! 1000W Power Zone is 50 - 60 Hz. This specification is essential to ensure optimal operation and compatibility with electrical systems. The total power of the product Be Quiet! 1000W Power Zone is 1000 W. This power ensures optimal performance for efficient use. The AC input voltage of the Be Quiet! 1000W Power Zone is 100 - 240 V. This specification ensures optimal compatibility with standard electrical systems. The input current of the product Be Quiet! 1000W Power Zone is 12 A. This input current ensures optimal performance and increased energy efficiency. The power factor of the product Be Quiet! 1000W Power Zone is 0.99. This power factor indicates the efficiency with which the product uses energy. The power factor correction device of the product Be Quiet! 1000W Power Zone is active. This type of correction device optimizes energy efficiency by improving the power factor of the system. The maximum input current of the product Be Quiet! 1000W Power Zone is +12V, +3.3V, +5V, +5Vsb, -12V A. This specification ensures optimal performance and compatibility with various electrical systems. The product Be Quiet! 1000W Power Zone has a combined power (+3.3 V) of 170 W. This specification ensures optimal performance for your energy needs. The combined power (+12 V) of the product Be Quiet! 1000W Power Zone is 996 W. This specification ensures optimal performance for your energy needs. The product Be Quiet! 1000W Power Zone has a combined power (+5V) of 170 W. This specification ensures optimal performance for your devices. The product Be Quiet! 1000W Power Zone has a combined power (-12V) of 3.6 W. This specification ensures optimal performance and increased energy efficiency. The combined power (+5Vsb) of the Be Quiet! 1000W Power Zone is 15 W. This specification ensures optimal performance for your devices. The maximum output current (+3.3V) of the Be Quiet! 1000W Power Zone is 25 A. This current ensures optimal performance for your power supply needs. The product Be Quiet! 1000W Power Zone has a maximum output current (+12V) of 83 A. This specification ensures optimal performance for your power supply needs. The product Be Quiet! 1000W Power Zone has a maximum output current (+5V) of 25 A. This current allows you to efficiently power your electronic devices. The maximum output current (-12V) of the Be Quiet! 1000W Power Zone is 0.3 A. This specification ensures optimal performance for your energy needs. The maximum output current (+5Vsb) of the Be Quiet! 1000W Power Zone is 3 A. This current ensures a stable and efficient power supply for your devices. The retention time of the product Be Quiet! 1000W Power Zone is 23 ms. This retention time ensures optimal performance and increased responsiveness during its use. The effectiveness of the product Be Quiet! 1000W Power Zone is 89 %. This performance ensures optimal results for daily use. The electrical protection devices of the product Be Quiet! 1000W Power Zone include protections against overloads, surges, and short circuits. These devices ensure the safety and reliability of your electrical installation. The peak power of the product Be Quiet! 1000W Power Zone is 1050 W. This power ensures optimal audio quality for an immersive listening experience.
Other features
The noise level in full charge mode, 100% of the product Be Quiet! 1000W Power Zone is 37.1 dB. This noise level ensures discreet and pleasant use in any environment. The noise level in silent mode of the product Be Quiet! 1000W Power Zone is 20.1 dB. This sound level allows for a discreet and pleasant use. The noise level of the product Be Quiet! 1000W Power Zone is below 30%. This feature allows for discreet and pleasant use, ideal for noise-sensitive environments.
Representation / realization
The noise level of the product Be Quiet! 1000W Power Zone is 37.1 dB. This noise level allows for pleasant use without excessive noise disturbances. The form factor of the power supply unit of the product Be Quiet! 1000W Power Zone is ATX. This form factor determines the compatibility of the power supply with the case and components of your system. The average time between failures of the product Be Quiet! 1000W Power Zone is 100000 h. This feature demonstrates the reliability and durability of the product, ensuring prolonged use without interruptions. The product Be Quiet! 1000W Power Zone has the 80 PLUS 80 PLUS Bronze certification. This certification ensures high energy efficiency, thereby helping to reduce energy consumption and associated costs. The usefulness of the product Be Quiet! 1000W Power Zone is PC. This product has been designed to meet specific needs and provide an optimal experience for its users. The ATX version of the product Be Quiet! 1000W Power Zone is 2.4. This specification ensures optimal compatibility with modern computer components. The EPS version of the product Be Quiet! 1000W Power Zone contains 2.92. This version ensures optimal print quality and compatibility with various graphic design software. The product Be Quiet! 1000W Power Zone features a FDB bearing technology. This technology ensures optimal performance and increased durability. The certification of the product Be Quiet! 1000W Power Zone contains CE, CB, TÜV, Semko (S), FCC, cTUVus, c-tick, BSMI. This certification guarantees compliance with the required safety and performance standards.
Packaging information
Does the product Be Quiet! 1000W Power Zone have a User Manual? Oui. This document provides clear instructions for optimal use of the product. The height of the package of the product Be Quiet! 1000W Power Zone is 328 mm. This dimension is essential to ensure optimal transport and storage. The depth of the product package Be Quiet! 1000W Power Zone is 102 mm. This dimension is essential to ensure proper packaging and secure transport. The width of the package of the product Be Quiet! 1000W Power Zone is 248 mm. This dimension is essential to ensure optimal transport and storage. The weight of the Be Quiet! 1000W Power Zone package is 2640 g. This weight ensures optimal protection during transport and delivery.
