Manual of product CWF12J01
Editorial note
The Constructa CWF12J01 washing machine stands out with its 7 kg washing capacity and 15 programs, providing great flexibility to meet the specific needs of each type of fabric. Its integrated LED screen with multi-illumination makes it easy to use, even in low-light conditions, and its relatively quiet operation with a noise level of 52 dB during washing makes it a suitable choice for households. However, some drawbacks deserve to be highlighted. The energy efficiency class D may lead to higher energy consumption compared to other models on the market. Additionally, the lack of advanced features such as remote control via Wi-Fi limits its appeal to users looking for modern and connected solutions. The spin noise level of 74 dB could also be perceived as disturbing in certain environments. Regarding ergonomics, the child safety feature and the delayed start of up to 24 hours are undeniable assets. Nevertheless, the weight of 69 kg makes the machine difficult to move, which could pose a challenge during installation or relocation. In summary, the Constructa CWF12J01 is a washing machine offering good performance and intuitive use, but it could benefit from improvements in energy efficiency and modern features to fully meet user expectations.Score details
User experience
The user experience is generally positive thanks to an integrated LED screen with multi-illumination, making it easy to use even in low light conditions.
Performance
Washing performance is satisfactory with 15 suitable programs, but the energy efficiency class D may lead to higher energy consumption.
Design
The design is modern and integrated, optimizing aesthetics while offering a large washing capacity of 7 kg.
Value for money
The value for money is fair, although the lack of advanced features like remote control via Wi-Fi limits its appeal.
Robustness
The weight of 69 kg can make the appliance difficult to move, raising concerns about sturdiness during installation.
Features
Features such as delayed start and child safety are advantages, but the absence of the AquaStop function may raise concerns.
Usability
The use is intuitive thanks to Rotary and Touch controls, although the spin noise level of 74 dB may be disturbing in some environments.
Support
A user manual is available, but the lack of modern features limits technical support related to connectivity.
Documentation
The user manual is concise and helpful, although it does not cover advanced features that may interest some users.
Advantages
Washing capacity of 7 kg
15 programs suitable for textiles
Silent operation at 52 dB
Delay start up to 24 hours
Intuitive and visible LED display
Child safety for secure use
Disadvantages
Low energy efficiency (class D)
No Wi-Fi remote control
High spin noise level (74 dB)
Heavy weight (69 kg) difficult to move
Lack of AquaStop leak protection
Technical Specifications CWF12J01
General Information
-
ModelCWF12J01
-
Brand
-
Category
-
Type
-
SKU1278924
-
MPN1278924
Design
-
Device placementFree pose
-
Loading typeFront load
-
Product colorWhite
-
Custom panels ready to useNo
-
Screen illuminationYes
-
Screen typeLED
-
Screen illuminationYes
-
Color of the lightingYellow
-
Order typeRotary, Touch
-
Hinge location of doorLeft
-
Color of the doorBlack
-
CertificationCE, VDE
-
Cable length1.6 m
-
Door opening angle140 °
-
Tank materialPlastic
-
Drum volume55 L
Representation / realization
-
Number of washing programs15
-
Nominal capacity7 kg
-
Sound emission classB
-
Maximum spin speed1200 rpm
-
Noise level (washing)52 dB
-
Noise level (spin)74 dB
-
Half-loadYes
-
Delayed departure24 h
-
Residual moisture53 %
-
Cycle duration (max)200 min
-
Half-loadYes
-
Half-loadYes
-
Contactless paymentNo
-
Half-loadYes
-
Half-loadYes
-
Half-loadYes
-
Half-loadYes
-
Language menuGerman
-
Contactless paymentNo
-
Contactless paymentNo
-
Half-loadYes
-
Washing programsBlouse/shirt, Cotton, Easy care, Hand/wool, Mix, Quick, Delicate/silk
-
Sound emission classB
Power
-
Connected charge2300 W
-
AC input voltage220 - 240 V
-
AC input frequency50 Hz
-
Current10 A
-
Electricity consumption (stop)0.12 W
-
Electricity consumption (residual)0.5 W
-
Energy efficiency rangeA to G
-
Energy consumption per wash0.8 kWh
-
Energy efficiency classD
-
Energy consumption per 100 cycles69 kWh
-
Water consumption per cycle45 L
Weight and dimensions
-
Height848 mm
-
Width598 mm
-
Depth546 mm
-
Weight69026 g
-
Door diameter300 mm
Ergonomics
-
Adjustable feetYes
-
Adjustable feetYes
-
Adjustable feetYes
-
Adjustable feetYes
-
Adjustable feetYes
-
Adjustment of the feet12 mm
Frequently Asked Questions
What is the ideal temperature to wash my clothes?
Is it necessary to use a descaling product for my washing machine?
How can I prevent bad odors in my washing machine?
What is the weight of the Constructa CWF12J01 model?
What certifications does the Constructa CWF12J01 have?
What is the height of the Constructa CWF12J01?
What is the width of the Constructa CWF12J01?
What is the depth of the Constructa CWF12J01?
What is the energy rating of the Constructa CWF12J01?
Is the user manual for the Constructa CWF12J01 available in French?
Similar products
More product categories from brand Constructa
Other Constructa
More product types from brand Constructa
Presentation of product CWF12J01 specifications from brand Constructa
General Information
The Constructa CWF12J01 washing machine is a household appliance from the well-established brand Constructa, known for its commitment to quality and innovation. This model, identified by the EAN code 4242004250623, offers reliable performance and an enhanced user experience.
Design
Designed for built-in placement, the CWF12J01 features a front-loading design that optimizes space while maintaining the aesthetics of your interior. With its white finish and elegant black door, it easily fits into various decors. Its LED screen, illuminated in multiple colors, provides increased visibility and intuitive use, even in low-light conditions. The rotary and touch controls ensure easy handling, while the door opening angle of 140° facilitates access to the 55 L plastic drum, offering durability and corrosion resistance.
Representation / Performance
The CWF12J01 offers a varied selection of 15 washing programs, suitable for different types of textiles, thus meeting specific needs. Its 7 kg capacity optimizes usage, while its spin efficiency class B and maximum spin speed of 1200 rpm ensure well-spun laundry, reducing drying time. With a noise level of 52 dB during washing and 74 dB during spinning, this machine operates relatively quietly. Additionally, the delayed start function of up to 24 hours provides appreciated usage flexibility.
Power
The CWF12J01 is designed for efficient energy consumption, with a connected load of 2300 W and an input voltage of 220 to 240 V. Although its energy efficiency class is D, it allows for a consumption of 0.8 kWh per wash and a water consumption of 45 L per cycle, thus optimizing resources. The machine is also equipped with a low consumption standby function, consuming only 0.12 W when idle.
Weight and Dimensions
With a height of 848 mm, a width of 598 mm, and a depth of 546 mm, the CWF12J01 is designed to fit into various spaces. However, its weight of 69 kg may complicate its movement during installation or relocation.
Ergonomics
This washing machine includes several practical features, such as child safety to prevent accidents, a remaining time indicator, and a program progress indicator. Additionally, the adjustable feet, offering a 12 mm adjustment, allow for optimized installation according to your needs.
