Manuals of product MWE Bronze 550
Technical Specifications MWE Bronze 550
General Information
-
ModelMWE BRONZE 550
-
Brand
-
Category
-
Type
-
SKU1736049
-
MPN1736049
Power
-
Total power550 W
-
AC input voltage100 - 240 V
-
AC input frequency50 - 60 Hz
-
Input current4 - 8 A
-
Type of Power Factor Corrector (PFC)Active
-
Combined power (+5V)110 W
-
Combined power (+12 V)516 W
-
Combined power (+5V)110 W
-
Combined power (-12V)3.6 W
-
Combined power (+5Vsb)15 W
-
Maximum output current (+5V)20 A
-
Maximum output current (+12V)43 A
-
Maximum output current (+5V)20 A
-
Maximum output current (-12V)0.3 A
-
Maximum output current (+5Vsb)3 A
-
Holding time16 ms
-
Effectiveness85 %
-
Electrical protection devicesOver current, Over power, Over voltage, Short circuit
-
Power Good signal trigger delay100 - 500 ms
Design
-
Fan diameter120 mm
-
Number of fans1 fan(s)
-
Product colorBlack
Connectivity
-
Motherboard connector20+4 pin ATX
-
Length of motherboard power cable610 mm
-
Number of SATA power cables4
-
Length of the SATA power cable450.570 mm
-
Molex peripheral connector (4-pin)3
-
Length of the device's power cable (Molex)450.570.690.810 mm
-
PCI Express power connectors (6 +2 pin)2
-
Length of the PCI Express power cable700 mm
-
Floppy disk drive connectorYes
-
Length of the CPU power cable600 mm
-
Floppy disk drive power connector1
-
Floppy disk drive connectorYes
-
Wiring typeNon-modular
Representation / realization
-
Form factor of the power supply unitATX
-
UtilityPC
-
Version ATX2.31
-
Mean time between failures100000 h
-
80 PLUS Certification80 PLUS Bronze
-
CertificationTUV-RH, CE, CCC, KC, EAC, RCM, cTUVus, FCC, BSMI
-
Rolling technologyLDB
Environmental conditions
-
Operating temperature0 - 40 °C
Weight and dimensions
-
Width150 mm
-
Depth140 mm
-
Height86 mm
-
Weight1560 g
Packaging information
-
Package width194 mm
-
Package depth266 mm
-
Package height112 mm
-
Package weight2283 g
Logistics data
-
Width of the main locker (external)279 mm
-
Length of the main locker (external)582 mm
-
Height of the main locker (external)217 mm
-
Product by main locker (external)5 piece(s)
-
Products by pallet24 piece(s)
Other features
-
Optimized cable managementYes
Similar products
More product categories from brand Cooler Master
Other Cooler Master
Audio Cooler Master
More product types from brand Cooler Master
Presentation of product MWE Bronze 550 specifications from brand Cooler Master
Generalities
The brand of the product Cooler Master MWE Bronze 550 is Cooler Master. This brand is known for its quality and innovation in the field of household appliances. The product model Cooler Master MWE Bronze 550 is MWE Bronze 550 | MPX-5501-ACAAB-EU. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Cooler Master MWE Bronze 550 is 0884102034503, 4719512061824, 4719512061848, 884102034503. This code allows for the unique identification of the product in the distribution system.
Design
The diameter of the Cooler Master MWE Bronze 550 fan is 120 mm. This diameter is essential for ensuring optimal air circulation. The number of fans of the product Cooler Master MWE Bronze 550 is 1 ventilateur(s). This design allows for better air circulation and optimal performance. The color of the product Cooler Master MWE Bronze 550 is Noir. This shade gives it a modern and elegant look.
Power
The total power of the product Cooler Master MWE Bronze 550 is 550 W. This power ensures optimal performance for efficient use. The AC input voltage of the Cooler Master MWE Bronze 550 is 100 - 240 V. This specification ensures optimal compatibility with standard electrical systems. The input current of the product Cooler Master MWE Bronze 550 is 4 - 8 A. This input current ensures optimal performance and increased energy efficiency. The AC input frequency of the product Cooler Master MWE Bronze 550 is 50 - 60 Hz. This specification is essential to ensure optimal operation and compatibility with electrical systems. The power factor correction device of the product Cooler Master MWE Bronze 550 is active. This type of correction device optimizes energy efficiency by improving the power factor of the system. The product Cooler Master MWE Bronze 550 has a combined power (+3.3 V) of 110 W. This specification ensures optimal performance for your energy needs. The combined power (+12 V) of the product Cooler Master MWE Bronze 550 is 516 W. This specification ensures optimal performance for your energy needs. The product Cooler Master MWE Bronze 550 has a combined power (+5V) of 110 W. This specification ensures optimal performance for your devices. The product Cooler Master MWE Bronze 550 has a combined power (-12V) of 3.6 W. This specification ensures optimal performance and increased energy efficiency. The combined power (+5Vsb) of the Cooler Master MWE Bronze 550 is 15 W. This specification ensures optimal performance for your devices. The maximum output current (+3.3V) of the Cooler Master MWE Bronze 550 is 20 A. This current ensures optimal performance for your power supply needs. The product Cooler Master MWE Bronze 550 has a maximum output current (+12V) of 43 A. This specification ensures optimal performance for your power supply needs. The product Cooler Master MWE Bronze 550 has a maximum output current (+5V) of 20 A. This current allows you to efficiently power your electronic devices. The maximum output current (-12V) of the Cooler Master MWE Bronze 550 is 0.3 A. This specification ensures optimal performance for your energy needs. The maximum output current (+5Vsb) of the Cooler Master MWE Bronze 550 is 3 A. This current ensures a stable and efficient power supply for your devices. The retention time of the product Cooler Master MWE Bronze 550 is 16 ms. This retention time ensures optimal performance and increased responsiveness during its use. The effectiveness of the product Cooler Master MWE Bronze 550 is 85 %. This performance ensures optimal results for daily use. The electrical protection devices of the product Cooler Master MWE Bronze 550 include protections against overloads, surges, and short circuits. These devices ensure the safety and reliability of your electrical installation. The trigger delay for the Power Good signal of the product Cooler Master MWE Bronze 550 is 100 - 500 ms. This delay is essential to ensure stable and reliable power supply.
Environmental conditions
The operating temperature of the product Cooler Master MWE Bronze 550 is 0 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments.
Connectivity
The connector on the motherboard of the product Cooler Master MWE Bronze 550 contains 20+4 pin ATX. This connector is essential for ensuring a stable and reliable connection between the motherboard and the other components of the system. The length of the motherboard power cable of the product Cooler Master MWE Bronze 550 is 610 mm. This specification ensures optimal connectivity for your components. The number of SATA power cables for the product Cooler Master MWE Bronze 550 is 4. These cables provide a reliable and efficient connection to power your components. The SATA power cable of the product Cooler Master MWE Bronze 550 has a length of 450,570 mm. This specification ensures optimal connectivity for your components. The Molex peripheral connector (4-pin) of the product Cooler Master MWE Bronze 550 contains 3. This connector is essential for ensuring a reliable connection between electronic components. The length of the power cable of the device (Molex) of the product Cooler Master MWE Bronze 550 is 450,570,690,810 mm. This specification ensures optimal connectivity for your power needs. Does the Cooler Master MWE Bronze 550 have a CPU power connector (4+4 pin)? Oui. This connector is essential for providing stable and efficient power to your processor. The PCI Express power connector (6 +2 pin) of the product Cooler Master MWE Bronze 550 contains 2. This connector is essential for providing stable and efficient power to graphics cards and other components requiring a PCIe connection. The product Cooler Master MWE Bronze 550 has a CPU power cable length of 600 mm. This specification ensures optimal connectivity for your system. The length of the PCI Express power cable of the product Cooler Master MWE Bronze 550 is 700 mm. This cable is essential for ensuring a reliable and efficient connection between your power supply and your graphics card. The power connector of the floppy disk drive of the product Cooler Master MWE Bronze 550 contains 1. This connector is essential to ensure adequate power supply to the floppy disk drive. The wiring type of the product Cooler Master MWE Bronze 550 is Non-modulaire. This non-modular wiring ensures a stable and reliable connection. Does the product Cooler Master MWE Bronze 550 have a floppy disk drive connector? Oui. This connector allows for easy and quick connection with floppy disk drives, ensuring optimal compatibility.
Representation / realization
The form factor of the power supply unit of the product Cooler Master MWE Bronze 550 is ATX. This form factor determines the compatibility of the power supply with the case and components of your system. The average time between failures of the product Cooler Master MWE Bronze 550 is 100000 h. This feature demonstrates the reliability and durability of the product, ensuring prolonged use without interruptions. The ATX version of the product Cooler Master MWE Bronze 550 is 2.31. This specification ensures optimal compatibility with modern computer components. The usefulness of the product Cooler Master MWE Bronze 550 is PC. This product has been designed to meet specific needs and provide an optimal experience for its users. The product Cooler Master MWE Bronze 550 has the 80 PLUS 80 PLUS Bronze certification. This certification ensures high energy efficiency, thereby helping to reduce energy consumption and associated costs. The certification of the product Cooler Master MWE Bronze 550 contains TUV-RH, CE, CCC, KC, EAC, RCM, cTUVus, FCC, BSMI. This certification guarantees compliance with the required safety and performance standards. The product Cooler Master MWE Bronze 550 features a LDB bearing technology. This technology ensures optimal performance and increased durability.
Weight and dimensions
The width of the product Cooler Master MWE Bronze 550 is 150 mm. This dimension is essential to ensure optimal integration into your space. The weight of the product Cooler Master MWE Bronze 550 is 1560 g. This weight is ideal for ensuring optimal use and easy handling. The depth of the product Cooler Master MWE Bronze 550 is 140 mm. This dimension allows for optimal integration into your space. The height of the product Cooler Master MWE Bronze 550 is 86 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Packaging information
The width of the package of the product Cooler Master MWE Bronze 550 is 194 mm. This dimension is essential to ensure optimal transport and storage. The depth of the product package Cooler Master MWE Bronze 550 is 266 mm. This dimension is essential to ensure proper packaging and secure transport. The weight of the Cooler Master MWE Bronze 550 package is 2283 g. This weight ensures optimal protection during transport and delivery. The height of the package of the product Cooler Master MWE Bronze 550 is 112 mm. This dimension is essential to ensure optimal transport and storage.
Logistics data
The height of the external main locker of the product Cooler Master MWE Bronze 550 is 217 mm. This dimension is essential to ensure optimal storage. The length of the main (external) locker of the product Cooler Master MWE Bronze 550 is 582 mm. This specification is essential to ensure optimal storage and efficient use of space. The width of the external main locker of the product Cooler Master MWE Bronze 550 is 279 mm. This dimension is essential to ensure optimal storage and efficient use of space. The product Cooler Master MWE Bronze 550 contains 5 pièce(s) piece(s). This specification is essential for inventory management and shipping optimization. The number of products per pallet of the product Cooler Master MWE Bronze 550 is 24 pièce(s). This specification is essential for optimizing logistics and inventory management.
Other features
Does the product Cooler Master MWE Bronze 550 have optimized cable management? Oui. This feature helps maintain an organized and clutter-free workspace.
