Manuals of product V750
Technical Specifications V750
General Information
-
ModelV750
-
Brand
-
Category
-
Type
-
SKU1735778
-
MPN1735778
Power
-
Total power750 W
-
AC input voltage100 - 240 V
-
AC input frequency50 - 60 Hz
-
Power factor0.9
-
Type of Power Factor Corrector (PFC)Active
-
Combined power (+5V)120 W
-
Combined power (+5V)120 W
-
Combined power (+12 V)744 W
-
Combined power (-12V)3.6 W
-
Combined power (+5Vsb)12.5 W
-
Maximum output current (+3.3V)25 A
-
Maximum output current (+12V)62 A
-
Maximum output current (+5V)22 A
-
Maximum output current (-12V)0.3 A
-
Maximum output current (+5Vsb)2.5 A
-
Holding time16 ms
-
Effectiveness90 %
-
Electrical protection devicesOver current, Over power, Over voltage, Overheating, Short circuit, Under voltage
-
Input current5 - 10 A
Connectivity
-
Motherboard connector20+4 pin ATX
-
CPU power connector (4+4 pin)Yes
-
Floppy disk drive power connector1
-
CPU power connector (4+4 pin)Yes
-
Molex peripheral connector (4-pin)6
-
Number of SATA power cables8
-
PCI Express power connectors (6 +2 pin)4
-
Wiring typeFully modular
Weight and dimensions
-
Width140 mm
-
Depth150 mm
-
Height86 mm
-
Weight1500 g
Representation / realization
-
80 PLUS Certification80 PLUS Gold
-
Form factor of the power supply unitATX
-
UtilityPC
-
Version ATX2.31
-
Sound level- dB
-
Mean time between failures100000 h
-
CertificationCE/TUV/TUV-SUDNRTL/FCC/GOST/CCC/BSMI/C-tick/KCC
Packaging information
-
Package width290 mm
-
Package depth195 mm
-
Package height130 mm
Design
-
Built-in power buttonYes
-
Product colorBlack
-
Fan diameter120 mm
-
Number of fans1 fan(s)
-
Fan locationHigh
Environmental conditions
-
Operating temperature0 - 40 °C
Similar products
More product categories from brand Cooler Master
Other Cooler Master
Audio Cooler Master
More product types from brand Cooler Master
Presentation of product V750 specifications from brand Cooler Master
Weight and dimensions
The height of the product Cooler Master V750 is 86 mm. This dimension is essential to ensure that the product fits perfectly in your space. The width of the product Cooler Master V750 is 140 mm. This dimension is essential to ensure optimal integration into your space. The depth of the product Cooler Master V750 is 150 mm. This dimension allows for optimal integration into your space. The weight of the product Cooler Master V750 is 1500 g. This weight is ideal for ensuring optimal use and easy handling.
Generalities
The brand of the product Cooler Master V750 is Cooler Master. This brand is known for its quality and innovation in the field of household appliances. The product model Cooler Master V750 is V750 | RS-750-AFBA-G1-EU. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Cooler Master V750 is 4719512048276. This code allows for the unique identification of the product in the distribution system.
Connectivity
The connector on the motherboard of the product Cooler Master V750 contains 20+4 pin ATX. This connector is essential for ensuring a stable and reliable connection between the motherboard and the other components of the system. Does the Cooler Master V750 have an ATX power connector (20+4 pin)? Oui. This connector is essential for ensuring stable and efficient power supply to your system. Does the Cooler Master V750 have a CPU power connector (4+4 pin)? Oui. This connector is essential for providing stable and efficient power to your processor. The power connector of the floppy disk drive of the product Cooler Master V750 contains 1. This connector is essential to ensure adequate power supply to the floppy disk drive. The Molex peripheral connector (4-pin) of the product Cooler Master V750 contains 6. This connector is essential for ensuring a reliable connection between electronic components. The PCI Express power connector (6 +2 pin) of the product Cooler Master V750 contains 4. This connector is essential for providing stable and efficient power to graphics cards and other components requiring a PCIe connection. The number of SATA power cables for the product Cooler Master V750 is 8. These cables provide a reliable and efficient connection to power your components. The wiring type of the product Cooler Master V750 is Entièrement modulaire. This non-modular wiring ensures a stable and reliable connection.
Packaging information
The width of the package of the product Cooler Master V750 is 290 mm. This dimension is essential to ensure optimal transport and storage. The depth of the product package Cooler Master V750 is 195 mm. This dimension is essential to ensure proper packaging and secure transport. The height of the package of the product Cooler Master V750 is 130 mm. This dimension is essential to ensure optimal transport and storage.
Representation / realization
The product Cooler Master V750 has the 80 PLUS 80 PLUS Gold certification. This certification ensures high energy efficiency, thereby helping to reduce energy consumption and associated costs. The form factor of the power supply unit of the product Cooler Master V750 is ATX. This form factor determines the compatibility of the power supply with the case and components of your system. The ATX version of the product Cooler Master V750 is 2.31. This specification ensures optimal compatibility with modern computer components. The usefulness of the product Cooler Master V750 is PC. This product has been designed to meet specific needs and provide an optimal experience for its users. The average time between failures of the product Cooler Master V750 is 100000 h. This feature demonstrates the reliability and durability of the product, ensuring prolonged use without interruptions. The noise level of the product Cooler Master V750 is - dB. This noise level allows for pleasant use without excessive noise disturbances. The certification of the product Cooler Master V750 contains CE/TUV/TUV-SUDNRTL/FCC/GOST/CCC/BSMI/C-tick/KCC. This certification guarantees compliance with the required safety and performance standards.
Power
The total power of the product Cooler Master V750 is 750 W. This power ensures optimal performance for efficient use. The power factor of the product Cooler Master V750 is 0.9. This power factor indicates the efficiency with which the product uses energy. The AC input voltage of the Cooler Master V750 is 100 - 240 V. This specification ensures optimal compatibility with standard electrical systems. The AC input frequency of the product Cooler Master V750 is 50 - 60 Hz. This specification is essential to ensure optimal operation and compatibility with electrical systems. The power factor correction device of the product Cooler Master V750 is active. This type of correction device optimizes energy efficiency by improving the power factor of the system. The product Cooler Master V750 has a combined power (+3.3 V) of 120 W. This specification ensures optimal performance for your energy needs. The product Cooler Master V750 has a combined power (+5V) of 120 W. This specification ensures optimal performance for your devices. The combined power (+12 V) of the product Cooler Master V750 is 744 W. This specification ensures optimal performance for your energy needs. The product Cooler Master V750 has a combined power (-12V) of 3.6 W. This specification ensures optimal performance and increased energy efficiency. The combined power (+5Vsb) of the Cooler Master V750 is 12.5 W. This specification ensures optimal performance for your devices. The maximum output current (+3.3V) of the Cooler Master V750 is 25 A. This current ensures optimal performance for your power supply needs. The product Cooler Master V750 has a maximum output current (+12V) of 62 A. This specification ensures optimal performance for your power supply needs. The product Cooler Master V750 has a maximum output current (+5V) of 22 A. This current allows you to efficiently power your electronic devices. The maximum output current (-12V) of the Cooler Master V750 is 0.3 A. This specification ensures optimal performance for your energy needs. The effectiveness of the product Cooler Master V750 is 90 %. This performance ensures optimal results for daily use. The retention time of the product Cooler Master V750 is 16 ms. This retention time ensures optimal performance and increased responsiveness during its use. The maximum output current (+5Vsb) of the Cooler Master V750 is 2.5 A. This current ensures a stable and efficient power supply for your devices. The electrical protection devices of the product Cooler Master V750 include protections against overloads, surges, and short circuits. These devices ensure the safety and reliability of your electrical installation. The input current of the product Cooler Master V750 is 5 - 10 A. This input current ensures optimal performance and increased energy efficiency.
Environmental conditions
The operating temperature of the product Cooler Master V750 is 0 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments.
Design
Does the product Cooler Master V750 have a built-in power button? Oui. This feature allows for simplified use and optimal control of the device. The diameter of the Cooler Master V750 fan is 120 mm. This diameter is essential for ensuring optimal air circulation. The number of fans of the product Cooler Master V750 is 1 ventilateur(s). This design allows for better air circulation and optimal performance. The color of the product Cooler Master V750 is Noir. This shade gives it a modern and elegant look. The location of the fan of the product Cooler Master V750 is at the front and back. This positioning allows for optimal air circulation to maintain an ideal temperature.
