Technical Specifications DCS-2230L
General Information
-
ModelDCS-2230L
-
Brand
-
Category
-
Type
-
SKU393987
-
MPN393987
Representation / realization
-
TypeIP security camera
-
PTZ ControlNo
-
Supported installationIndoor
-
Connectivity technologyWired & wireless
-
CertificationCE
-
Day/Night ModeCE LVD
-
FCC
-
C-Tick
-
Yes
Design
-
FormatCube
-
Product colorWhite
Video
-
Supported video modes-
-
Maximum resolution1920 x 1080 pixels
-
Supported video formatH.264, M-JPEG
-
Supported graphic resolutions1440 x 1080, 320 x 240, 480 x 270, 640 x 360, 1280 x 960, 1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 800 x 600 (SVGA)
-
Full HDYes
-
Number of images per second30 fps
-
Total megapixels2 MP
Camera
-
Minimum illumination0 lux
-
Field of view of the lens, horizontal103 °
-
Angle of view of the lens, vertical55 °
-
Angle of view of the lens, diagonal118 °
Image sensor
-
Sensor typeCMOS
-
Optical sensor size1/2.7
Objective system
-
Zoom capacity-
-
Optical zoom- x
-
Digital zoom10 x
-
Tuning1.8
-
Fixed Focal Length2.8 mm
Storage support
-
Built-in memory card readerYes
-
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
-
Integrated hard driveNo
Night vision
-
Night visionYes
-
Night vision distance5 m
Network
-
Ethernet/LANYes
-
Wiring technology10/100Base-T(X)
-
WifiNo
-
Supported network protocolsIPv6 / IPv4 TCP/IP UDP ICMP Client DHCP Client NTP (D-Link) Client DNS Client DDNS (D-Link) Client SMTP Client FTP Bonjour HTTP / HTTPS Client Samba PPPoE UPnP RTP / RTSP/ RTCP QoS CoS IGMP
Connectivity
-
Number of Ethernet LAN ports (RJ-45)1
-
InterfaceRJ-45
Audio
-
Supported audio formatsAAC
-
Built-in speakersYes
-
Built-in speakersYes
-
Audio system1-way
Weight and dimensions
-
Width58 mm
-
Depth38.7 mm
-
Height95 mm
-
Weight75 g
Power
-
Ethernet connection, supporting power over this port (PoE)-
-
AC input voltage100-240 V
-
AC input frequency50 - 60 Hz
-
Output CC in amperes1.2 A
-
Output CC in volts+5V
-
Consumption (max)4 W
Environmental conditions
-
Operating temperature0 - 40 °C
-
Temperature out of operation-20 - 70 °C
-
Operating relative humidity (H-H)20 - 80 %
-
Relative humidity rate (storage)5 - 95 %
Minimum system requirements
-
Support for the Mac operating systemYes
-
Support for the Mac operating systemYes
-
Supported mobile systemAndroid
Similar products
More product categories from brand D-Link
More product types from brand D-Link
Presentation of product DCS-2230L specifications from brand D-Link
Generalities
The brand of the product D-Link DCS-2230L is D-Link. This brand is known for its quality and innovation in the field of household appliances. The product model D-Link DCS-2230L is DCS-2230L | DCS-2230L. This model ensures optimal performance and an enhanced user experience. The EAN code of the product D-Link DCS-2230L is 790069411717, 0790069411717, 0790069411823. This code allows for the unique identification of the product in the distribution system.
Design
The format of the product D-Link DCS-2230L is a bar. This format allows for practical and efficient use in various contexts. The color of the product D-Link DCS-2230L is Blanc. This shade gives it a modern and elegant look.
Video
The maximum resolution of the product D-Link DCS-2230L is 1920 x 1080 pixels. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. The supported graphic resolutions of the product D-Link DCS-2230L are 1440 x 1080,320 x 240,480 x 270,640 x 360,1280 x 960,1024 x 768 (XGA),1280 x 720 (HD 720),1920 x 1080 (HD 1080),800 x 600 (SVGA). These resolutions provide optimal display quality for your content. The supported video mode of the product D-Link DCS-2230L is -. This mode allows you to enjoy optimal image quality for your videos. The supported video format of the product D-Link DCS-2230L contains H.264, M-JPEG. This format allows for smooth and high-quality playback of your multimedia content. Does the product D-Link DCS-2230L have Full HD? Oui. This feature ensures exceptional image quality for an immersive viewing experience. The number of frames per second of the product D-Link DCS-2230L is 30 ips. This specification ensures optimal smoothness when playing videos. The total megapixels of the product D-Link DCS-2230L is 2 MP. This total ensures exceptional image quality for your photos.
Representation / realization
The type of product D-Link DCS-2230L is an island. This type of design offers a functional and aesthetic solution to optimize space in your interior. The product D-Link DCS-2230L features a Avec fil &sans fil connectivity technology. This functionality allows for practical and flexible use without the constraints of cables. The design of the product D-Link DCS-2230L supports vertical installation. This feature allows for optimal integration into various spaces, thus offering flexibility and practicality. The PTZ control of the product D-Link DCS-2230L is Non. This control allows for precise and efficient management of pan, tilt, and zoom. The certification of the product D-Link DCS-2230L contains CE \r\nCE LVD \r\nFCC\r\nC-Tick. This certification guarantees compliance with the required safety and performance standards. Does the product D-Link DCS-2230L have a Day/Night Mode? Oui. This feature allows for adjusting the lighting according to the time of day, thus providing optimal comfort.
Image sensor
The optical sensor size of the product D-Link DCS-2230L is 1/2.7 ". This size contributes to better image quality, allowing for sharper and more detailed shots. The sensor type of the product D-Link DCS-2230L is CMOS. This type of sensor ensures optimal image quality for your needs.
Camera
The minimum illumination of the product D-Link DCS-2230L is 0 lux. This feature ensures optimal performance even in low light conditions. The field of view of the D-Link DCS-2230L lens is 103 °. This field of view allows for capturing images with a wide perspective, ideal for landscapes and group shots. The vertical field of view of the product D-Link DCS-2230L is 55 °. This field of view allows for image capture with an expanded perspective, ideal for dynamic compositions. The angle of view of the lens, diagonal of the product D-Link DCS-2230L is 118 °. This angle allows capturing images with a wide perspective, thus providing an immersive visual experience.
Objective system
Does the product D-Link DCS-2230L have zoom capacity? -. This feature allows you to capture precise details, even from a distance. The optical zoom of the product D-Link DCS-2230L is - x. This zoom allows for capturing precise details from a distance, thus providing superior image quality. The digital zoom of the product D-Link DCS-2230L is 10 x. This zoom allows for capturing precise details even from a distance. The adjustment of the D-Link DCS-2230L is manual. This specification allows for precise and personalized control of the objective to meet the specific needs of each user. The product goal system D-Link DCS-2230L has a fixed focal length of 2.8 mm. This feature allows for images with great sharpness and exceptional quality.
Storage support
The product D-Link DCS-2230L has compatible memory cards: MicroSD (TransFlash), MicroSDHC. These memory cards ensure optimal performance for storing your data. Does the D-Link DCS-2230L have a built-in memory card reader? Oui. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution. Does the D-Link DCS-2230L have a built-in hard drive? No. This feature means that the product does not have internal storage.
Network
The wiring technology of the product D-Link DCS-2230L contains 10/100Base-T(X). This technology ensures a fast and reliable connection for your networking needs. Does the product D-Link DCS-2230L have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. The Wifi of the product D-Link DCS-2230L contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices. The supported network protocols of the product D-Link DCS-2230L are IPv6 / IPv4 TCP/IP UDP ICMP Client DHCP Client NTP (D-Link) Client DNS Client DDNS (D-Link) Client SMTP Client FTP Bonjour HTTP / HTTPS Client Samba PPPoE UPnP RTP / RTSP/ RTCP QoS CoS IGMP. These protocols ensure efficient and reliable communication for your networking needs.
Night vision
The night vision distance of the product D-Link DCS-2230L is 5 m. This feature allows for clear and precise observation even in darkness. Does the product D-Link DCS-2230L have night vision? Oui. This feature allows for clear visibility in the dark, thus providing enhanced security.
Connectivity
The number of Ethernet LAN (RJ-45) ports of the product D-Link DCS-2230L is 1. These ports provide a stable and fast network connection for your devices. The product D-Link DCS-2230L has an Interface RJ-45. This interface allows for easy and quick connection with various devices.
Audio
The supported audio formats of the product D-Link DCS-2230L are AAC. These formats ensure optimal compatibility for an enriching listening experience. Does the product D-Link DCS-2230L have built-in speakers? Oui. These speakers provide an immersive and convenient audio experience. The audio system of the product D-Link DCS-2230L is stereo. This audio system provides an immersive and high-quality sound experience. Does the product D-Link DCS-2230L have a built-in Microphone? Oui. This microphone allows for clear and precise audio capture, ideal for calls and recordings.
Weight and dimensions
The depth of the product D-Link DCS-2230L is 38.7 mm. This dimension allows for optimal integration into your space. The width of the product D-Link DCS-2230L is 58 mm. This dimension is essential to ensure optimal integration into your space. The weight of the product D-Link DCS-2230L is 75 g. This weight is ideal for ensuring optimal use and easy handling. The height of the product D-Link DCS-2230L is 95 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Minimum system requirements
The supported mobile system of the product D-Link DCS-2230L contains Android. This system allows for smooth usage on major mobile platforms. Does the product D-Link DCS-2230L support the Mac operating system? Oui. This feature ensures optimal compatibility for Mac users. Does the product D-Link DCS-2230L support the Windows operating system? Oui. This feature ensures optimal compatibility with Windows systems, providing a smooth and uninterrupted user experience.
Environmental conditions
The operating temperature of the product D-Link DCS-2230L is 0 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The product D-Link DCS-2230L has an operating relative humidity (H-H) of 20 - 80 %. This specification ensures optimal operation in a wide range of ambient humidity. The non-operating temperature of the product D-Link DCS-2230L is -20 - 70 °C. This specification ensures that the product can withstand extreme conditions without suffering damage. The relative humidity (storage) rate of the product D-Link DCS-2230L is 5 - 95 %. This rate ensures optimal conditions for the preservation and durability of the product.
Power
Does the D-Link DCS-2230L have an Ethernet connection, supporting power over this port (PoE)? -. This feature allows for simplified and efficient power supply to connected devices. The product D-Link DCS-2230L has a DC output in amperes of 1.2 A. This specification ensures a stable power supply suitable for your needs. The AC input voltage of the D-Link DCS-2230L is 100-240 V. This specification ensures optimal compatibility with standard electrical systems. The AC input frequency of the product D-Link DCS-2230L is 50 - 60 Hz. This specification is essential to ensure optimal operation and compatibility with electrical systems. The product D-Link DCS-2230L has a DC output in volts of +5V. This specification ensures a stable power supply suitable for the needs of your electronic devices. The maximum consumption of the product D-Link DCS-2230L is 4 W. This specification allows for the assessment of the energy efficiency of the device.
