Manual of product Pro SD59430U-HNI
Technical Specifications Pro SD59430U-HNI
General Information
-
ModelPRO SD59430U-HNI
-
Brand
-
Category
-
Type
-
SKU796157
-
MPN796157
Representation / realization
-
TypeIP security camera
-
Supported installationIndoor and outdoor
-
Check-in tourYes
-
Check-in tourYes
-
Check-in tourYes
-
Check-in tourYes
-
Check-in tourYes
-
Connectivity technologyWired
-
CertificationCE: EN55032/EN55024/EN50130-4
-
PTZ ModesFCC: Part15 subpartB, ANSI C63.4- 2014
-
PTZ ProtocolsUL: UL60950-1+CAN/CSA C22.2, No.60950-1
-
Check-in tourAuto Scan, Auto pan, Preset point
-
DH-SD
-
Yes
Design
-
FormatDome
-
Product colorBlack, White
-
Mounting typeCeiling/wall
-
Protection functionsWater resistant
-
Material of the case/bodyMetal
-
International Protection Code (IP)IP66
-
Anti-fogYes
Video
-
Maximum resolution2592 x 1520 pixels
-
Visual compression formatsH.264, H.265, M-JPEG
-
Supported graphic resolutions2592 x 1520, 352 x 240, 352 x 288, 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296
-
Supported video modes720p, 1080p
-
Analog signal format systemPAL
-
Gain control typeAuto/Manual
-
Number of images per second60 fps
-
Total megapixels4 MP
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
-
Binary rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
BitrateH.265/H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
Camera
-
Minimum illumination0.05 lux
-
Field of view of the lens, horizontal60 °
-
Inclination angle-15 - 90 °
-
Tilt speed200 °/sec
-
Panoramic0 - 360 °
-
Tilt preset speed300 °/sec
-
Camera shutter typeElectronics
-
Camera shutter speed1/1 - 1/300000 s
-
Tilt preset speed300 °/sec
-
Camera pan commandYes
-
White balanceATW, Auto, Indoor, Manual, Outdoor
-
Pan tilt preset speed400 °/sec
-
Quantity of predefined programs300
-
Camera pan commandYes
-
Camera pan commandYes
Image sensor
-
Sensor typeCMOS
-
Optical sensor size1/3 "
-
Progressive scanYes
Objective system
-
Auto focusYes
-
Optical zoom30 x
-
Digital zoom16 x
-
Detection distance2700 m
-
Observation distance1080 m
-
Recognition distance540 m
-
Identification distance270 m
-
Auto focusYes
-
Maximum number of openings4.4
-
TuningMotorized/manual
-
Minimum opening amount1.6
-
Focal length4.5 - 135 mm
-
Minimum focusing distance1 m
Security
-
Motion detectorYes
-
Functions of the IVS system (intelligent video surveillance)Abandoned object
-
Face detection
-
Intrusion
-
Missing object
-
Tripwire
Storage support
-
Built-in memory card readerYes
-
Compatible memory cardsMicroSD (TransFlash)
-
Integrated hard driveNo
-
Maximum memory card size128 GB
-
Internal memory1024 MB
-
ROM capacity128 MB
Night vision
-
Night visionYes
-
Night vision distance100 m
-
Type of LEDIR
-
Number of lighting LEDs4
Network
-
Quality of Service (QoS)Yes
-
WifiNo
-
Type of Ethernet interfaceFast Ethernet
-
Wiring technology10/100Base-T(X)
-
Network standardsIEEE 802.3at
-
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
-
Quality of Service (QoS)Yes
-
Number of users20 user(s)
-
Streaming methodMulticast, Unicast
-
Client interoperabilityONVIF, PSIA, CGI
Connectivity
-
Number of Ethernet LAN ports (RJ-45)1
-
InterfaceRJ-45
Audio
-
Audio output channels1 channels
-
Audio output channels1 channels
-
Audio CodecsG.711a/G.711Mu/AAC/G.722 / G.726/G.729/MPEG2-L2
-
Signal-to-noise ratio report55 dB
Weight and dimensions
-
Height309 mm
-
Diameter186 mm
-
Weight3500 g
Packaging information
-
Package weight6800 g
Power
-
Ethernet connection, supporting power over this port (PoE)Yes
-
AC input voltage24 V
-
Typical electricity consumption13 W
-
Consumption (max)23 W
-
Output current of the power adapter3 A
-
Power supply typePoE
Management features
-
Web BrowserYes
-
Management softwareSmart PSS, DSS
Environmental conditions
-
Operating temperature-40 - 70 °C
-
Operating relative humidity (H-H)0 - 90 %
Minimum system requirements
-
Supported mobile systemAndroid
-
iOS
Packaging contents
-
Number of cameras1
Other features
-
Infrared commandAuto, Manual
-
Supported browsersIE, Chrome, Firefox, Safari
Technical details
-
Number of video streams3
Similar products
More product categories from brand Dahua Technology
More product types from brand Dahua Technology
Presentation of product Pro SD59430U-HNI specifications from brand Dahua Technology
Generalities
The brand of the product Dahua Technology Pro SD59430U-HNI is Dahua Technology. This brand is known for its quality and innovation in the field of household appliances. The EAN code of the product Dahua Technology Pro SD59430U-HNI is 6905208867926, 6939554922602. This code allows for the unique identification of the product in the distribution system. The product model Dahua Technology Pro SD59430U-HNI is Pro SD59430U-HNI | 1.0.01.07.10911. This model ensures optimal performance and an enhanced user experience.
Design
The format of the product Dahua Technology Pro SD59430U-HNI is a bar. This format allows for practical and efficient use in various contexts. The color of the product Dahua Technology Pro SD59430U-HNI is Black, White. This shade gives it a modern and elegant look. The product Dahua Technology Pro SD59430U-HNI has Résistant à l’eau protection features. These characteristics ensure reliable use in various environmental conditions. The mounting type of the product Dahua Technology Pro SD59430U-HNI is Plafond/mur. This type of mounting ensures easy and quick installation, thus guaranteeing optimal use of the product. The material of the product case Dahua Technology Pro SD59430U-HNI is Métal. This material ensures both durability and elegance. The International Protection Code (IP) for product Dahua Technology Pro SD59430U-HNI contains IP66. This code indicates the level of protection against solid objects and moisture. Does the product Dahua Technology Pro SD59430U-HNI have an anti-fog feature? Oui. This feature helps prevent fogging, ensuring optimal visibility.
Representation / realization
The type of product Dahua Technology Pro SD59430U-HNI is an island. This type of design offers a functional and aesthetic solution to optimize space in your interior. The design of the product Dahua Technology Pro SD59430U-HNI supports vertical installation. This feature allows for optimal integration into various spaces, thus offering flexibility and practicality. The PTZ control of the product Dahua Technology Pro SD59430U-HNI is Oui. This control allows for precise and efficient management of pan, tilt, and zoom. Does the product Dahua Technology Pro SD59430U-HNI have Automatic Tracking? Oui. This feature allows you to track your orders in real-time, providing you with peace of mind while shopping. Does the product Dahua Technology Pro SD59430U-HNI have a Wide Range Dynamic (WRD)? Oui. This specification ensures optimal performance and increased adaptability in various conditions. Does the product Dahua Technology Pro SD59430U-HNI have a Day/Night Mode? Oui. This feature allows for adjusting the lighting according to the time of day, thus providing optimal comfort. The certification of the product Dahua Technology Pro SD59430U-HNI contains CE: EN55032/EN55024/EN50130-4\nFCC: Part15 subpartB, ANSI C63.4- 2014\nUL: UL60950-1+CAN/CSA C22.2, No.60950-1. This certification guarantees compliance with the required safety and performance standards. Does the product Dahua Technology Pro SD59430U-HNI have an entry/end Alarm? Oui. This feature effectively secures access to your space. The product Dahua Technology Pro SD59430U-HNI features a Avec fil connectivity technology. This functionality allows for practical and flexible use without the constraints of cables. The PTZ modes of the product Dahua Technology Pro SD59430U-HNI contain Auto Scan, Auto pan, Preset point. These modes allow for increased flexibility and customization to meet your specific needs. The product Dahua Technology Pro SD59430U-HNI has PTZ Protocols DH-SD. These Protocols allow for precise and effective control of the camera movements, thus ensuring optimal surveillance. Does the product Dahua Technology Pro SD59430U-HNI have a recording loop? Oui. This product allows you to easily record your audio sessions.
Video
The maximum resolution of the product Dahua Technology Pro SD59430U-HNI is 2592 x 1520 pixels. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. The supported graphic resolutions of the product Dahua Technology Pro SD59430U-HNI are 2592 x 1520,352 x 240,352 x 288,704 x 480,704 x 576,1280 x 720 (HD 720),1920 x 1080 (HD 1080),2304 x 1296. These resolutions provide optimal display quality for your content. The supported video mode of the product Dahua Technology Pro SD59430U-HNI is 720p, 1080p. This mode allows you to enjoy optimal image quality for your videos. The product Dahua Technology Pro SD59430U-HNI has visual compression formats: H.264, H.265, M-JPEG. These formats ensure optimal image quality for your videos. The analog signal format system of the product Dahua Technology Pro SD59430U-HNI contains PAL. This system ensures compatibility with various broadcasting formats, thus providing an optimal viewing experience. The gain control type of the product Dahua Technology Pro SD59430U-HNI is Auto/Manual. This type of control allows for easy adjustment of the gain level according to needs, thus providing optimal flexibility for your video recordings. The number of frames per second of the product Dahua Technology Pro SD59430U-HNI is 60 ips. This specification ensures optimal smoothness when playing videos. The total megapixels of the product Dahua Technology Pro SD59430U-HNI is 4 MP. This total ensures exceptional image quality for your photos. Does the product Dahua Technology Pro SD59430U-HNI have noise reduction? Oui. This feature allows for an optimal sound experience by minimizing external distractions. Does the product Dahua Technology Pro SD59430U-HNI have a video broadcast? Oui. This feature allows sharing content in real-time with a large audience. Does the product Dahua Technology Pro SD59430U-HNI have Scrolling and mirroring? Oui. This feature allows for a smooth and immersive visual experience. Does the product Dahua Technology Pro SD59430U-HNI have Personal Data Masking? Oui. This feature ensures the protection of users' personal information when streaming videos. The binary bitrate control of the product Dahua Technology Pro SD59430U-HNI contains Constant Bit Rate (CBR)/Variable Bit Rate (VBR). This control allows for optimizing video quality while effectively managing file sizes. The bit rate of the product Dahua Technology Pro SD59430U-HNI is H.265/H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps. This bit rate determines the quality and clarity of the sound, providing an enriching audio experience. Does the product Dahua Technology Pro SD59430U-HNI have a Brightness Compensation? Oui. This feature allows for automatic adjustment of the image brightness for a better visual experience. Does the product Dahua Technology Pro SD59430U-HNI have Highlight Compensation (HLC)? Oui. This feature enhances image quality by reducing highlight effects. Does the product Dahua Technology Pro SD59430U-HNI have 3D noise reduction? Oui. This feature enhances video quality by reducing unwanted noise for a more enjoyable viewing experience. Does the product Dahua Technology Pro SD59430U-HNI have Region of Interest Encoding? Oui. This feature allows targeting specific areas in the video for more precise processing or analysis. Does the Dahua Technology Pro SD59430U-HNI have an image stabilizer? Oui. This image stabilizer allows for sharp videos and photos, even in motion.
Image sensor
The optical sensor size of the product Dahua Technology Pro SD59430U-HNI is 1/3 ". This size contributes to better image quality, allowing for sharper and more detailed shots. The sensor type of the product Dahua Technology Pro SD59430U-HNI is CMOS. This type of sensor ensures optimal image quality for your needs. Does the product Dahua Technology Pro SD59430U-HNI have a Progressive Scan? Oui. This feature allows for superior image quality by displaying each image in its entirety, thus providing a smoother and sharper visual experience.
Camera
The field of view of the Dahua Technology Pro SD59430U-HNI lens is 60 °. This field of view allows for capturing images with a wide perspective, ideal for landscapes and group shots. The minimum illumination of the product Dahua Technology Pro SD59430U-HNI is 0.05 lux. This feature ensures optimal performance even in low light conditions. The tilt speed of the product Dahua Technology Pro SD59430U-HNI is 200 °/sec. This feature allows for a quick and smooth adjustment of the viewing angle, thus providing an optimal user experience. The tilt angle of the product Dahua Technology Pro SD59430U-HNI is -15 - 90 °. This angle allows for adjusting the position for optimal comfort. The panoramic view of the product Dahua Technology Pro SD59430U-HNI is 0 - 360 °. This specification allows for an expanded overview, ideal for capturing landscapes or wide scenes. The panning speed of the product Dahua Technology Pro SD59430U-HNI is 300 °/sec. This feature allows for smooth and fast rotation, ideal for capturing dynamic images. The type of shutter of the camera of the product Dahua Technology Pro SD59430U-HNI is Électronique. This type of shutter allows for precise and fast image capture, ideal for action photography. The tilt pre-setting speed of the product Dahua Technology Pro SD59430U-HNI is 300 °/sec. This feature allows for quick and precise adjustment of the camera angle to capture images from different angles. Does the Dahua Technology Pro SD59430U-HNI have automatic flipping? Oui. This feature allows the camera to automatically adjust to capture the best angles. The shutter speed of the camera of the product Dahua Technology Pro SD59430U-HNI is 1/1 - 1/300000 s. This feature allows capturing sharp images even in low light conditions. The white balance of the product Dahua Technology Pro SD59430U-HNI consists of several options, including Auto, Cloudy, Daylight, Fluorescent, Incandescent, and Manual. This feature allows you to adjust the color temperature to achieve true-to-life images. The product Dahua Technology Pro SD59430U-HNI has a preset panning speed of 400 °/sec. This specification allows for smooth and fast camera movement, ideal for capturing dynamic scenes. The number of predefined programs of the product Dahua Technology Pro SD59430U-HNI is 300. This specification allows for optimizing the use and customization of the device. The tilt command of the Dahua Technology Pro SD59430U-HNI camera is %. This feature allows you to adjust the viewing angle to capture images from different perspectives. Does the product Dahua Technology Pro SD59430U-HNI have a camera pan command? No. This feature is not available on this model.
Security
The intelligent video surveillance system of the product Dahua Technology Pro SD59430U-HNI has features such as face detection and intrusion. These advanced functionalities ensure optimal security by enabling proactive and effective monitoring. Does the product Dahua Technology Pro SD59430U-HNI have a Motion Detector? Oui. This device allows for the detection of any presence within its field of vision, thus providing enhanced security.
Storage support
The maximum size of the memory card for the product Dahua Technology Pro SD59430U-HNI is 128 Go. This feature allows for storing a large amount of data, ideal for users who need more space. Does the Dahua Technology Pro SD59430U-HNI have a built-in hard drive? No. This feature means that the product does not have internal storage. Does the Dahua Technology Pro SD59430U-HNI have a built-in memory card reader? Oui. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution. The product Dahua Technology Pro SD59430U-HNI has compatible memory cards: MicroSD (TransFlash). These memory cards ensure optimal performance for storing your data. The internal memory of the product Dahua Technology Pro SD59430U-HNI contains 1024 Mo. This memory allows for the storage of a large amount of data and applications for smooth and efficient use. The capacity of the ROM of the product Dahua Technology Pro SD59430U-HNI is 128 Mo. This capacity allows for the storage of a significant amount of data and applications.
Objective system
Does the product Dahua Technology Pro SD59430U-HNI have zoom capacity? Oui. This feature allows you to capture precise details, even from a distance. The optical zoom of the product Dahua Technology Pro SD59430U-HNI is 30 x. This zoom allows for capturing precise details from a distance, thus providing superior image quality. The digital zoom of the product Dahua Technology Pro SD59430U-HNI is 16 x. This zoom allows for capturing precise details even from a distance. The detection distance of the product Dahua Technology Pro SD59430U-HNI is 2700 m. This feature allows for effective detection over a significant range. The observation distance of the product Dahua Technology Pro SD59430U-HNI is 1080 m. This specification allows for an appreciation of the range and clarity of the observed images. The maximum number of openings for the product Dahua Technology Pro SD59430U-HNI is 4.4. This feature allows for optimal use and increased flexibility. The detection range of the product Dahua Technology Pro SD59430U-HNI is 540 m. This specification allows for the assessment of the system's effectiveness under various usage conditions. The product identification distance Dahua Technology Pro SD59430U-HNI is 270 m. This specification allows determining the range at which the device can recognize objects or people. Does the Dahua Technology Pro SD59430U-HNI have Auto focus? Oui. This feature allows for capturing sharp and accurate images by automatically adjusting the focus. The adjustment of the Dahua Technology Pro SD59430U-HNI is manual. This specification allows for precise and personalized control of the objective to meet the specific needs of each user. The focal length of the product Dahua Technology Pro SD59430U-HNI is 4.5 - 135 mm. This specification determines the field of view and the distance at which subjects can be captured accurately. The minimum focusing distance of the product Dahua Technology Pro SD59430U-HNI is 1 m. This feature allows for sharp images even at relatively far distances. The minimum opening number of the product Dahua Technology Pro SD59430U-HNI is 1.6. This minimum opening number allows for better brightness and enables high-quality shots in low-light conditions.
Night vision
Does the product Dahua Technology Pro SD59430U-HNI have night vision? Oui. This feature allows for clear visibility in the dark, thus providing enhanced security. The type of LED of the product Dahua Technology Pro SD59430U-HNI is IR. This type of LED allows for optimal night vision, ensuring image clarity even in darkness. The number of lighting LEDs in the product Dahua Technology Pro SD59430U-HNI is 4. This number determines the light intensity and energy efficiency of the device. The night vision distance of the product Dahua Technology Pro SD59430U-HNI is 100 m. This feature allows for clear and precise observation even in darkness.
Network
Does the product Dahua Technology Pro SD59430U-HNI have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. The wiring technology of the product Dahua Technology Pro SD59430U-HNI contains 10/100Base-T(X). This technology ensures a fast and reliable connection for your networking needs. The Ethernet interface type of the product Dahua Technology Pro SD59430U-HNI is Fast Ethernet. This type of interface allows for fast and efficient network connections. The Wifi of the product Dahua Technology Pro SD59430U-HNI contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices. The network standards of the product Dahua Technology Pro SD59430U-HNI are IEEE 802.3at. These standards ensure optimal compatibility with various equipment and protocols. The supported network protocols of the product Dahua Technology Pro SD59430U-HNI are IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x. These protocols ensure efficient and reliable communication for your networking needs. The streaming method of the product Dahua Technology Pro SD59430U-HNI is Multicast, Unicast. This method allows for efficient data transmission to multiple users simultaneously. The product Dahua Technology Pro SD59430U-HNI has client interoperability ONVIF, PSIA, CGI, thus ensuring optimal compatibility with various systems and protocols. Does the product Dahua Technology Pro SD59430U-HNI have Quality of Service (QoS)? Oui. This feature ensures optimal management of network resources, thus providing a smooth and uninterrupted user experience. The number of users of the product Dahua Technology Pro SD59430U-HNI is 20 utilisateur(s). This product is ideal for several people.
Connectivity
The number of Ethernet LAN (RJ-45) ports of the product Dahua Technology Pro SD59430U-HNI is 1. These ports provide a stable and fast network connection for your devices. The product Dahua Technology Pro SD59430U-HNI has an Interface RJ-45. This interface allows for easy and quick connection with various devices.
Audio
The number of audio input channels of the product Dahua Technology Pro SD59430U-HNI is 1 canaux. This specification ensures optimal sound quality and an enriching listening experience. The audio output channels of the Dahua Technology Pro SD59430U-HNI are 1 canaux. This specification allows for an immersive and high-quality sound experience. The signal-to-noise ratio of the product Dahua Technology Pro SD59430U-HNI is 55 dB. This high ratio ensures exceptional audio quality, allowing for clear and precise listening without unwanted interference. The audio codecs of the product Dahua Technology Pro SD59430U-HNI contain G.711a/G.711Mu/AAC/G.722 / G.726/G.729/MPEG2-L2. These codecs ensure optimal sound quality and a smooth listening experience.
Weight and dimensions
The height of the product Dahua Technology Pro SD59430U-HNI is 309 mm. This dimension is essential to ensure that the product fits perfectly in your space. The weight of the product Dahua Technology Pro SD59430U-HNI is 3500 g. This weight is ideal for ensuring optimal use and easy handling. The diameter of the product Dahua Technology Pro SD59430U-HNI is 186 mm. This diameter allows for optimal use and fits perfectly with your needs.
Packaging information
The weight of the Dahua Technology Pro SD59430U-HNI package is 6800 g. This weight ensures optimal protection during transport and delivery.
Power
The maximum consumption of the product Dahua Technology Pro SD59430U-HNI is 23 W. This specification allows for the assessment of the energy efficiency of the device. The AC input voltage of the Dahua Technology Pro SD59430U-HNI is 24 V. This specification ensures optimal compatibility with standard electrical systems. Does the Dahua Technology Pro SD59430U-HNI have an Ethernet connection, supporting power over this port (PoE)? Oui. This feature allows for simplified and efficient power supply to connected devices. The typical power consumption of the product Dahua Technology Pro SD59430U-HNI is 13 W. This feature allows for the assessment of the energy efficiency of the device. The output current of the power adapter for the product Dahua Technology Pro SD59430U-HNI is 3 A. This current provides efficient and stable power for your devices. The type of power source for the product Dahua Technology Pro SD59430U-HNI is PoE. This type of power supply ensures optimal performance and efficient use of the device.
Environmental conditions
The operating temperature of the product Dahua Technology Pro SD59430U-HNI is -40 - 70 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The product Dahua Technology Pro SD59430U-HNI has an operating relative humidity (H-H) of 0 - 90 %. This specification ensures optimal operation in a wide range of ambient humidity.
Management features
Does the product Dahua Technology Pro SD59430U-HNI have a Web Browser? Oui. This feature allows easy access to the Internet to browse your favorite sites. The Dahua Technology Pro SD59430U-HNI management software contains Smart PSS, DSS. This management software allows for efficient and intuitive administration of video security systems.
Minimum system requirements
The supported mobile system of the product Dahua Technology Pro SD59430U-HNI contains Android, iOS. This system allows for smooth usage on major mobile platforms.
Packaging contents
The number of cameras of the product Dahua Technology Pro SD59430U-HNI is 1. This product is equipped with a camera that allows capturing high-quality images.
Other features
The browser support for the product Dahua Technology Pro SD59430U-HNI includes IE, Chrome, Firefox, Safari. This feature ensures an optimal user experience on compatible platforms. The infrared control of the product Dahua Technology Pro SD59430U-HNI is automatic, manual. This feature allows for convenient and flexible control of the device.
Technical details
The number of video streams for the product Dahua Technology Pro SD59430U-HNI is 3. This number determines the product's ability to handle multiple video sources simultaneously.
