Manuals of product EF7742OBI
Editorial note
The Electrolux EF7742OBI washing machine stands out with its 7 kg washing capacity, allowing for a large amount of laundry to be processed at once, which optimizes washing time. Its modern design and integrated display, combined with intuitive controls (Rotary, Touch), provide a pleasant and practical user experience. Additionally, the maximum spin speed of 1400 rpm ensures perfectly spun laundry, thus reducing the drying time needed. With 14 varied washing programs, the appliance adapts to different types of textiles, ensuring optimal care for each type of laundry. However, some drawbacks are worth mentioning. The energy efficiency class B, while acceptable, is not among the best available on the market, which may lead to slightly higher energy costs in the long run. Furthermore, the lack of advanced features such as self-cleaning or the AquaStop system limits convenience and safety of use. The spin noise level of 69 dB may be perceived as quite high, potentially disturbing in a quiet environment, especially if the machine is used late at night. Finally, the 20-hour delayed start, while convenient, may not be sufficient for those seeking more flexibility in programming. Overall, the Electrolux EF7742OBI is a high-performing washing machine, well-designed and suitable for varied needs, but it could benefit from some improvements to stand out further in the market. The provided documentation is comprehensive and helpful, facilitating the understanding of its features and usage.Score details
User experience
The user experience is very pleasant thanks to an integrated screen and intuitive controls (Rotary, Touch) that facilitate use.
Performance
The maximum spin speed of 1400 rpm ensures perfectly spun laundry, thus reducing drying time.
Design
The design is modern and well thought out, with a washing capacity of 7 kg that optimizes washing time.
Value for money
Although the energy efficiency class B is acceptable, it may lead to slightly higher energy costs in the long run.
Features
The product offers 14 varied washing programs, suitable for different types of textiles, but lacks some advanced features like self-cleaning.
Support
The available documents, including the user manual and technical sheet, are comprehensive and useful.
Documentation
The provided documentation is exhaustive with 54 pages, which makes understanding the features easier.
Robustness
The spin noise level of 69 dB may be perceived as quite high, which could be disturbing in a quiet environment.
Usability
The 20-hour delayed start is convenient, but may be considered insufficient for some users seeking greater flexibility.
Advantages
7 kg capacity for effective washing
Intuitive screen and controls easy to use
Spin speed of 1400 rpm for almost dry laundry
14 programs suitable for all textiles
Energy class B for energy savings
Disadvantages
Energy efficiency B, not optimal
No advanced features available
High spin noise level (69 dB)
Drum volume of 52 L insufficient
Limited 20-hour delayed start
Technical Specifications EF7742OBI
General Information
-
ModelEF7742OBI
-
Brand
-
Category
-
Type
-
SKU1798666
-
MPN1798666
Design
-
Device placementIntegrated
-
Loading typeFront load
-
Door handle colorWhite
-
Built-in screenYes
-
Built-in screenYes
-
Order typeRotary, Touch
-
Hinge location of doorLeft
-
Opening the doorSide opening
-
Door handle colorWhite
-
Door handle colorWhite
-
Cable length1.62 m
-
Length of the supply pipe1.5 m
-
Length of the drainage pipe1.45 m
-
Drum volume52 L
-
Water fillingcold
-
Engine typeBeltless
-
Type of dispenser drawer3-way
Representation / realization
-
Overflow protection-
-
Load balancing system-
-
AquaStop function-
-
Foam control system-
-
Nominal capacity7 kg
-
Maximum spin speed1400 rpm
-
Spin efficiency classB
-
Number of washing programs14
-
Sound emission classA
-
Noise level (spin)69 dB
-
Noise level (washing)- dB
-
Clothing addition function (pause)Yes
-
Cycle duration (max)195 min
-
Washing programsCotton, Delicate/silk, Down wear/duvet, Eco, Hygiene air refresh, Jeans/denim, Outdoor, Quick 14min, Rinse, Spin/drain, Sport, Steam, Synthetics, Wool
-
Clothing addition function (pause)Yes
-
Minimum spin speed500 rpm
-
Clothing addition function (pause)Yes
-
Clothing addition function (pause)Yes
-
Delayed departure20 h
-
Clothing addition function (pause)Yes
Ergonomics
-
Error message witnessYes
-
Self-cleaningNo
-
Error message witnessYes
-
Error message witnessYes
-
Error message witnessYes
-
Error message witnessYes
Special features
-
AEG Technologies (laundry care)Woolmark blue
Power
-
Energy efficiency classB
-
Energy efficiency rangeA to G
-
Energy consumption per 100 cycles52 kWh
-
Water consumption per cycle44 L
-
AC input voltage230 - 240 V
-
AC input frequency50 Hz
-
Current13 A
-
Connected charge2100 W
Weight and dimensions
-
Width596 mm
-
Depth540 mm
-
Height819 mm
-
Installation compartment width600 mm
-
Installation compartment depth560 mm
-
Installation compartment height820 mm
Frequently Asked Questions
What is the ideal temperature to wash my clothes?
Is it necessary to use a descaling product for my washing machine?
How can I prevent bad odors in my washing machine?
What is the height of the Electrolux EF7742OBI?
What is the width of the Electrolux EF7742OBI?
What is the depth of the Electrolux EF7742OBI?
What is the energy label of the Electrolux EF7742OBI?
Is the manual for the Electrolux EF7742OBI available in French?
Similar products
More product categories from brand Electrolux
More product types from brand Electrolux
Presentation of product EF7742OBI specifications from brand Electrolux
General Information
The Electrolux EF7742OBI washing machine embodies the expertise of the Electrolux brand, known for its innovation and the quality of its appliances. This model, referenced under the number EF7742OBI | 914 580 516, guarantees efficient performance, contributing to an enhanced washing experience. The EAN code, 7332543989638, allows for unique identification in the distribution network.
Design
The Electrolux EF7742OBI features a built-in design, allowing for optimal use while preserving the aesthetics of your interior. Its front loading makes access easy and maximizes space. The machine sports a white hue, giving it a modern and elegant look, while the custom panels add a unique touch. The integrated screen offers an intuitive user interface with Rotary and Touch controls. The door opens sideways, and its bottom hinge ensures easy handling. With power and drainage cables measuring 1.62 m, 1.5 m, and 1.45 m respectively, this machine easily adapts to various environments. Its 52 L drum allows for handling a large amount of laundry, thus optimizing washing time.
Performance / Execution
The washing capacity of the Electrolux EF7742OBI is 7 kg, ideal for family loads. Its maximum spin speed reaches 1400 rpm, ensuring perfectly spun laundry and reducing drying time. Rated B for spin efficiency, this machine offers good performance. With 14 washing programs, it adapts to various types of fabrics, ensuring optimal care for each item. The spin noise level is 69 dB, which is relatively high for use in quiet environments. The delayed start function, up to 20 hours, allows you to schedule washing according to your preferences. The programs include various options such as Cotton, Delicate/silk, Wool, and Quick 14min.
Ergonomics
This machine is equipped with a child safety lock, ensuring safe use for families. The remaining time indicator facilitates cycle management, while the adjustable feet allow for height adjustment for optimal comfort. A Power/Off button simplifies its use, and an error message indicator alerts the user in case of a problem.
Special Features
The integrated AEG Woolmark blue technology in this machine optimizes the care of your laundry, ensuring a gentle and effective wash.
Power
Rated B for energy efficiency, the Electrolux EF7742OBI contributes to energy savings while being environmentally friendly. Its energy consumption for 100 cycles is 52 kWh, and it uses 44 L of water per cycle. Compatible with an input voltage of 230 - 240 V and a frequency of 50 Hz, it ensures optimal operation in domestic installations.
Weight and Dimensions
With a width of 596 mm, a depth of 540 mm, and a height of 819 mm, the Electrolux EF7742OBI is designed to fit easily into your space. The installation compartment dimensions are also optimized, with a width of 600 mm, a depth of 560 mm, and a height of 820 mm.
