Manual of product EZ-2300Plus
Technical Specifications EZ-2300Plus
General Information
-
ModelEZ-2300PLUS
-
Brand
-
Category
-
Type
-
SKU248012
-
MPN248012
Print speed
-
Maximum resolution300 x 300 DPI
-
Print speed (metric measurement)150 mm/sec
-
Printing technologyDirect thermal/Thermal transfer
Design
-
ScreenLCD
-
Product colorBlack
Other features
-
Ready-to-use networkYes
-
Dimensions (LxWxH)274 x 512 x 291 mm
-
Maximum internal memory1 GB
-
Network featuresFast Ethernet
Connectivity
-
RS-232 port1
-
Standard interfacesRS-232
-
Optional connectivityParallel, Wireless LAN
-
Connectivity technologyWired
-
RS-232 InterfaceYes
-
BluetoothNo
-
RS-232 port1
Representation / realization
-
Internal memory16 MB
-
Flash memory4 MB
-
Embedded barcodes1D, 2D, CODABAR (NW-7), EAN128, EAN13, EAN8, PDF417, UPC-A, UPC-E
-
Compatible memory cardsCF
-
CertificationCE, EMC, FCC, CB, cUL, CCC
Weight and dimensions
-
Width274 mm
-
Depth512 mm
-
Height291 mm
-
Weight15000 g
Power
-
Power requirements100 - 240V, 50/60Hz
Minimum system requirements
-
Mac CompatibilityNo
-
Compatible operating systemsWindows 2000
-
Windows XP
-
Windows Vista
-
Windows 7
-
Windows Server 2003
-
Windows Server 2008
Packaging contents
-
Provided softwareQLabel-IV
-
Drivers includedYes
Paper management
-
Max. width of the label104 mm
-
Max. label length2.15 m
-
Ribbon length450 m
-
Ribbon width110 mm
-
Max. diameter of the roll203.2 mm
-
Thickness of the support0.06 - 0.25 mm
-
Thickness of the support/media (imperial)0.003 - 0.01 "
-
Supported paper width50.8 - 118 mm
-
Supported paper width2 - 4.64 "
-
Main diameter76.2 mm
Environmental conditions
-
Operating relative humidity (H-H)30 - 85 %
-
Operating temperature41 - 104 °F
-
Operating temperature5 - 40 °C
-
Relative humidity rate (storage)10 - 90 %
-
Temperature out of operation-20 - 50 °C
Similar products
More product categories from brand Godex
Presentation of product EZ-2300Plus specifications from brand Godex
Other features
The dimensions (LxWxH) of the product Godex EZ-2300Plus are 274 x 512 x 291 mm. These dimensions ensure an optimal fit in your space. The ready-to-use network of the product Godex EZ-2300Plus is Oui. This network is designed to provide immediate and hassle-free connectivity, thus facilitating access to the Internet as soon as it is activated. The maximum internal memory of the product Godex EZ-2300Plus is 1 Go. This capacity allows for the storage of a large amount of data, applications, and multimedia files. The Godex EZ-2300Plus network has Fast Ethernet network features. These features ensure a fast and reliable connection for all your digital needs.
Print speed
The maximum resolution of the product Godex EZ-2300Plus is 300 x 300 DPI. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. The printing system of the product Godex EZ-2300Plus features a Thermique direct/Transfert thermique printing technology. This technology ensures optimal print quality and precise results. The product Godex EZ-2300Plus has a printing speed of 150 mm/sec. This feature ensures optimal efficiency during your prints.
Generalities
The brand of the product Godex EZ-2300Plus is Godex. This brand is known for its quality and innovation in the field of household appliances. The product model Godex EZ-2300Plus is EZ-2300Plus | GP-EZ-2300PLUS+E. This model ensures optimal performance and an enhanced user experience.
Design
The Godex EZ-2300Plus screen contains LCD. This screen offers exceptional image quality for an immersive visual experience. The color of the product Godex EZ-2300Plus is Noir. This shade gives it a modern and elegant look.
Power
The power requirements of the product Godex EZ-2300Plus are 100 - 240V, 50/60Hz. These requirements ensure optimal operation of the device.
Weight and dimensions
The width of the product Godex EZ-2300Plus is 274 mm. This dimension is essential to ensure optimal integration into your space. The weight of the product Godex EZ-2300Plus is 15000 g. This weight is ideal for ensuring optimal use and easy handling. The depth of the product Godex EZ-2300Plus is 512 mm. This dimension allows for optimal integration into your space. The height of the product Godex EZ-2300Plus is 291 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Representation / realization
The integrated barcode of the product Godex EZ-2300Plus is of type 1D, 2D, CODABAR (NW-7), EAN128, EAN13, EAN8, PDF417, UPC-A, UPC-E. This barcode allows for quick and efficient reading of information. The product Godex EZ-2300Plus has a flash memory of 4 Mo. This memory provides an ideal storage capacity for your files, photos, and videos. The product Godex EZ-2300Plus has compatible memory cards: CF. These memory cards ensure optimal performance for storing your data. The internal memory of the product Godex EZ-2300Plus contains 16 Mo. This memory allows for the storage of a large amount of data and applications for smooth and efficient use. The certification of the product Godex EZ-2300Plus contains CE, EMC, FCC, CB, cUL, CCC. This certification guarantees compliance with the required safety and performance standards.
Connectivity
The Godex EZ-2300Plus product has 1 USB 1.1 port. This port allows for a simple and efficient connection for your compatible devices. The optional connectivity of the product Godex EZ-2300Plus includes Parallel, Wireless LAN. This connectivity expands the possibilities for use and compatibility with various devices. The product Godex EZ-2300Plus has standard interfaces. These interfaces ensure optimal connectivity and facilitate integration with various devices. The product Godex EZ-2300Plus features a Avec fil connectivity technology. This functionality allows for practical and flexible use without the constraints of cables. Does the product Godex EZ-2300Plus have RS-232 Interface? Oui. This interface allows for standardized serial communication, ideal for many devices. Does the Godex EZ-2300Plus have Bluetooth? Non. This feature allows for a convenient wireless connection with other compatible devices. The RS-232 port of the Godex EZ-2300Plus contains 1. This port is essential for ensuring reliable serial communication with other devices.
Minimum system requirements
Is the product Godex EZ-2300Plus compatible with Mac? No. This product is not compatible with Mac systems. The compatible operating system for the product Godex EZ-2300Plus is Windows XP, Windows Vista, Windows 7. These operating systems ensure optimal and smooth use of the product.
Packaging contents
Does the product Godex EZ-2300Plus come with included Drivers? Oui. This ensures an easy and quick installation. The software provided with the product Godex EZ-2300Plus contains QLabel-IV. This software enhances the user experience and optimizes the device's performance.
Paper management
The maximum length of the product label Godex EZ-2300Plus is 2.15 m. This specification ensures optimal resource use and efficient paper management. The ribbon length of the product Godex EZ-2300Plus is 450 m. This specification ensures optimal use for your paper management needs. The width of the ribbon of the product Godex EZ-2300Plus is 110 mm. This feature ensures optimal use for your printing projects. The maximum width of the product label Godex EZ-2300Plus is 104 mm. This specification ensures optimal compatibility with various printing media. The maximum diameter of the Godex EZ-2300Plus roll is 203.2 mm. This diameter is essential to ensure optimal compatibility with your paper management equipment. The thickness of the support for the product Godex EZ-2300Plus is 0.06 - 0.25 mm. This feature ensures optimal quality for your prints. The product Godex EZ-2300Plus has a support/media thickness (imperial) of 0.003 - 0.01 ". This specification ensures optimal compatibility with various printing equipment. The product Godex EZ-2300Plus has a supported paper width of 50.8 - 118 mm. This feature ensures optimal compatibility with various paper formats for your prints. The product Godex EZ-2300Plus has a supported paper width of 2 - 4.64 ". This feature ensures optimal compatibility with various paper formats for your prints. The main diameter of the product Godex EZ-2300Plus is 76.2 mm. This dimension is essential to ensure optimal paper management.
Environmental conditions
The product Godex EZ-2300Plus has an operating relative humidity (H-H) of 30 - 85 %. This specification ensures optimal operation in a wide range of ambient humidity. The operating temperature of the product Godex EZ-2300Plus is 41 - 104 °F. This specification ensures optimal performance within a temperature range suitable for various environments. The relative humidity (storage) rate of the product Godex EZ-2300Plus is 10 - 90 %. This rate ensures optimal conditions for the preservation and durability of the product. The operating temperature of the product Godex EZ-2300Plus is 5 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The non-operating temperature of the product Godex EZ-2300Plus is -20 - 50 °C. This specification ensures that the product can withstand extreme conditions without suffering damage.
