Technical Specifications QNO-7022R
General Information
-
ModelQNO-7022R
-
Brand
-
Category
-
Type
-
SKU1906832
-
MPN1906832
Representation / realization
-
TypeIP security camera
-
Supported installationOutdoor
-
Connectivity technologyWired
-
Large dynamic range (WRD)Yes
-
Large dynamic range (WRD)Yes
-
Large dynamic range (WRD)Yes
Design
-
FormatTerminal
-
Mounting typeCeiling/wall
-
Product colorGray
-
Material of the case/bodyAluminum
-
Code IKIK10
-
International Protection Code (IP)IP66
Camera
-
Camera tilt controlNo
-
Camera tilt controlNo
-
Minimum illumination0 lux
-
Angle of view of the lens, vertical41.2 °
-
Field of view of the lens, horizontal78.2 °
-
Angle of view of the lens, diagonal92 °
-
White balanceATW, AWC, Indoor, Manual, Outdoor
-
Camera shutter typeElectronic
Objective system
-
Detection distance63 m
-
Observation distance25.2 m
-
Recognition distance12.6 m
-
Identification distance6.3 m
-
Number of lenses1
-
Maximum number of openings1.6
-
Focal length4 mm
Image sensor
-
Sensor typeCMOS
-
Number of sensors1
-
Optical sensor size1/3
Night vision
-
Night visionYes
-
Night vision distance25 m
-
Type of LEDIR
Video
-
Maximum resolution2560 x 1440 pixels
-
Total megapixels4 MP
-
Supported video formatH.264, H.265, M-JPEG
-
Supported video formatH.264, H.265, M-JPEG
-
Supported graphic resolutions320 x 240,640 x 480 (VGA),720 x 480,800 x 448,800 x 480 (WVGA),800 x 600 (SVGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2560 x 1440
-
Number of images per second30 ips
-
Masking of personal dataYes
-
Masking of personal dataYes
-
Masking of personal dataYes
-
Masking of personal dataYes
-
Binary rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Audio
-
Sampling frequency8 kHz
-
Voice codecsG.711, G.711ulaw, G.726
Network
-
Quality of Service (QoS)Yes
-
BluetoothNo
-
BluetoothNo
-
Type of Ethernet interfaceFast Ethernet
-
Supported network protocolsIPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP
-
Number of users6 user(s)
-
Streaming methodMulticast, Unicast
-
Quality of Service (QoS)Yes
-
Network standardsIEEE 802.1x
Storage support
-
Integrated hard driveNo
-
Built-in memory card readerYes
-
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Maximum memory card size128 GB
-
Flash memory256 MB
Connectivity
-
Number of Ethernet LAN ports (RJ-45)1
Security
-
Anti-glareYes
-
Anti-glareYes
-
Password protectionUser
-
Anti-glareYes
-
Security-supported algorithmHTTPS, SNMPv2, SNMPv3
-
Anti-glareYes
-
Alert notification typeE-mail
-
Anti-glareYes
-
Anti-glareYes
Power
-
Power supply typeDC, PoE
-
Energy consumption (Power over Ethernet (PoE))10.7 W
-
Output CC in volts12
-
Typical electricity consumption8 W
Environmental conditions
-
Operating temperature-40 - 55 °C
-
Temperature out of operation-40 - 60 °C
-
Relative humidity rate (storage)0 - 95 %
-
Relative humidity rate (storage)0 - 95 %
Weight and dimensions
-
Weight700 g
-
Diameter70 mm
-
Product length246 mm
Packaging contents
-
Number of cameras1
Similar products
More product categories from brand Hanwha
More product types from brand Hanwha
Presentation of product QNO-7022R specifications from brand Hanwha
Generalities
The brand of the product Hanwha QNO-7022R is Hanwha. This brand is known for its quality and innovation in the field of household appliances. The product model Hanwha QNO-7022R is QNO-7022R | QNO-7022R. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Hanwha QNO-7022R is 8801089202413, 8801089202420. This code allows for the unique identification of the product in the distribution system.
Representation / realization
The type of product Hanwha QNO-7022R is an island. This type of design offers a functional and aesthetic solution to optimize space in your interior. The design of the product Hanwha QNO-7022R supports vertical installation. This feature allows for optimal integration into various spaces, thus offering flexibility and practicality. Does the product Hanwha QNO-7022R have a Day/Night Mode? Oui. This feature allows for adjusting the lighting according to the time of day, thus providing optimal comfort. The product Hanwha QNO-7022R features a Avec fil connectivity technology. This functionality allows for practical and flexible use without the constraints of cables. Does the product Hanwha QNO-7022R have an entry/end Alarm? Oui. This feature effectively secures access to your space. Does the product Hanwha QNO-7022R have a Wide Range Dynamic (WRD)? Oui. This specification ensures optimal performance and increased adaptability in various conditions.
Camera
The tilt command of the Hanwha QNO-7022R camera is %. This feature allows you to adjust the viewing angle to capture images from different perspectives. Does the product Hanwha QNO-7022R have a camera pan command? No. This feature is not available on this model. The minimum illumination of the product Hanwha QNO-7022R is 0 lux. This feature ensures optimal performance even in low light conditions. The vertical field of view of the product Hanwha QNO-7022R is 41.2 °. This field of view allows for image capture with an expanded perspective, ideal for dynamic compositions. The field of view of the Hanwha QNO-7022R lens is 78.2 °. This field of view allows for capturing images with a wide perspective, ideal for landscapes and group shots. The angle of view of the lens, diagonal of the product Hanwha QNO-7022R is 92 °. This angle allows capturing images with a wide perspective, thus providing an immersive visual experience. The white balance of the product Hanwha QNO-7022R consists of several options, including Auto, Cloudy, Daylight, Fluorescent, Incandescent, and Manual. This feature allows you to adjust the color temperature to achieve true-to-life images. The type of shutter of the camera of the product Hanwha QNO-7022R is Électronique. This type of shutter allows for precise and fast image capture, ideal for action photography.
Design
The format of the product Hanwha QNO-7022R is a bar. This format allows for practical and efficient use in various contexts. The material of the product case Hanwha QNO-7022R is Aluminium. This material ensures both durability and elegance. The color of the product Hanwha QNO-7022R is Gris. This shade gives it a modern and elegant look. The mounting type of the product Hanwha QNO-7022R is Plafond/mur. This type of mounting ensures easy and quick installation, thus guaranteeing optimal use of the product. The IK Code of the product Hanwha QNO-7022R is IK10. This IK Code allows for easy identification of the specific design of the item. The International Protection Code (IP) for product Hanwha QNO-7022R contains IP66. This code indicates the level of protection against solid objects and moisture.
Image sensor
The sensor type of the product Hanwha QNO-7022R is CMOS. This type of sensor ensures optimal image quality for your needs. The number of sensors of the product Hanwha QNO-7022R is 1. This number of sensors allows for precise and efficient image detection. The optical sensor size of the product Hanwha QNO-7022R is 1/3 ". This size contributes to better image quality, allowing for sharper and more detailed shots.
Night vision
The night vision distance of the product Hanwha QNO-7022R is 25 m. This feature allows for clear and precise observation even in darkness. Does the product Hanwha QNO-7022R have night vision? Oui. This feature allows for clear visibility in the dark, thus providing enhanced security. The type of LED of the product Hanwha QNO-7022R is IR. This type of LED allows for optimal night vision, ensuring image clarity even in darkness.
Objective system
The detection distance of the product Hanwha QNO-7022R is 63 m. This feature allows for effective detection over a significant range. The observation distance of the product Hanwha QNO-7022R is 25.2 m. This specification allows for an appreciation of the range and clarity of the observed images. The detection range of the product Hanwha QNO-7022R is 12.6 m. This specification allows for the assessment of the system's effectiveness under various usage conditions. The product identification distance Hanwha QNO-7022R is 6.3 m. This specification allows determining the range at which the device can recognize objects or people. The number of lenses in the product Hanwha QNO-7022R is 1. This number determines the quality and versatility of the lens. The maximum number of openings for the product Hanwha QNO-7022R is 1.6. This feature allows for optimal use and increased flexibility. The focal length of the product Hanwha QNO-7022R is 4 mm. This specification determines the field of view and the distance at which subjects can be captured accurately.
Audio
The voice codec of the Hanwha QNO-7022R product contains G.711, G.711ulaw, G.726. This voice codec ensures optimal audio quality for your communications. The sampling frequency of the product Hanwha QNO-7022R is 8 kHz. This feature ensures optimal sound quality for your recordings.
Video
The maximum resolution of the product Hanwha QNO-7022R is 2560 x 1440 pixels. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. The total megapixels of the product Hanwha QNO-7022R is 4 MP. This total ensures exceptional image quality for your photos. The product Hanwha QNO-7022R has visual compression formats: H.264, H.265, M-JPEG. These formats ensure optimal image quality for your videos. The supported video format of the product Hanwha QNO-7022R contains H.264, H.265, M-JPEG. This format allows for smooth and high-quality playback of your multimedia content. The supported graphic resolutions of the product Hanwha QNO-7022R are 320 x 240,640 x 480 (VGA),720 x 480,800 x 448,800 x 480 (WVGA),800 x 600 (SVGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2560 x 1440. These resolutions provide optimal display quality for your content. The number of frames per second of the product Hanwha QNO-7022R is 30 ips. This specification ensures optimal smoothness when playing videos. Does the product Hanwha QNO-7022R have Scrolling and mirroring? Oui. This feature allows for a smooth and immersive visual experience. Does the product Hanwha QNO-7022R have Personal Data Masking? Oui. This feature ensures the protection of users' personal information when streaming videos. Does the product Hanwha QNO-7022R have noise reduction? Oui. This feature allows for an optimal sound experience by minimizing external distractions. Does the product Hanwha QNO-7022R have a video broadcast? Oui. This feature allows sharing content in real-time with a large audience. The binary bitrate control of the product Hanwha QNO-7022R contains Constant Bit Rate (CBR)/Variable Bit Rate (VBR). This control allows for optimizing video quality while effectively managing file sizes.
Storage support
Does the Hanwha QNO-7022R have a built-in hard drive? No. This feature means that the product does not have internal storage. The product Hanwha QNO-7022R has compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC. These memory cards ensure optimal performance for storing your data. The maximum size of the memory card for the product Hanwha QNO-7022R is 128 Go. This feature allows for storing a large amount of data, ideal for users who need more space. Does the Hanwha QNO-7022R have a built-in memory card reader? Oui. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution. The product Hanwha QNO-7022R has a flash memory of 256 Mo. This memory provides an ideal storage capacity for your files, photos, and videos.
Connectivity
The number of Ethernet LAN (RJ-45) ports of the product Hanwha QNO-7022R is 1. These ports provide a stable and fast network connection for your devices.
Network
The Wifi of the product Hanwha QNO-7022R contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices. Does the product Hanwha QNO-7022R have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. The Ethernet interface type of the product Hanwha QNO-7022R is Fast Ethernet. This type of interface allows for fast and efficient network connections. Does the Hanwha QNO-7022R have Bluetooth? Non. This feature allows for a convenient wireless connection with other compatible devices. The supported network protocols of the product Hanwha QNO-7022R are IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP. These protocols ensure efficient and reliable communication for your networking needs. The network standards of the product Hanwha QNO-7022R are IEEE 802.1x. These standards ensure optimal compatibility with various equipment and protocols. The streaming method of the product Hanwha QNO-7022R is Multicast, Unicast. This method allows for efficient data transmission to multiple users simultaneously. Does the product Hanwha QNO-7022R have Quality of Service (QoS)? Oui. This feature ensures optimal management of network resources, thus providing a smooth and uninterrupted user experience. The number of users of the product Hanwha QNO-7022R is 6 utilisateur(s). This product is ideal for several people.
Power
The type of power source for the product Hanwha QNO-7022R is DC, PoE. This type of power supply ensures optimal performance and efficient use of the device. The energy consumption of the product Hanwha QNO-7022R is 10.7 W. This specification allows powering devices via the Ethernet network, thus providing a practical and efficient solution to reduce the number of cables needed. The product Hanwha QNO-7022R has a DC output in volts of 12. This specification ensures a stable power supply suitable for the needs of your electronic devices. The typical power consumption of the product Hanwha QNO-7022R is 8 W. This feature allows for the assessment of the energy efficiency of the device.
Environmental conditions
The non-operating temperature of the product Hanwha QNO-7022R is -40 - 60 °C. This specification ensures that the product can withstand extreme conditions without suffering damage. The operating temperature of the product Hanwha QNO-7022R is -40 - 55 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The relative humidity (storage) rate of the product Hanwha QNO-7022R is 0 - 95 %. This rate ensures optimal conditions for the preservation and durability of the product. The product Hanwha QNO-7022R has an operating relative humidity (H-H) of 0 - 95 %. This specification ensures optimal operation in a wide range of ambient humidity.
Security
Does the product Hanwha QNO-7022R have a Motion Detector (video)? Oui. This device provides effective monitoring by capturing video footage during motion detections. Does the product Hanwha QNO-7022R have Password Protection? Oui. This feature ensures the security of your data by restricting unauthorized access. Does the Hanwha QNO-7022R product filter IP addresses? Oui. This feature enhances security by blocking unauthorized access. Does the product Hanwha QNO-7022R have Password Protection? Utilisateur. This feature ensures the security of your personal data. The supported security algorithm of the product Hanwha QNO-7022R contains HTTPS, SNMPv2, SNMPv3. This algorithm ensures optimal protection of your data. Does the product Hanwha QNO-7022R have HTTPS Encryption? Oui. This encryption ensures the security of the data exchanged between the user and the site. Does the Hanwha QNO-7022R have an Anti-glare? Oui. This feature ensures optimal protection against unwanted reflections, thus providing an enhanced visual experience. Does the product Hanwha QNO-7022R have a Mirror? Oui. This mirror ensures better visibility and contributes to the safety of your space. The alert notification type for the product Hanwha QNO-7022R is E-mail. This feature allows for real-time alerts for better security.
Weight and dimensions
The weight of the product Hanwha QNO-7022R is 700 g. This weight is ideal for ensuring optimal use and easy handling. The diameter of the product Hanwha QNO-7022R is 70 mm. This diameter allows for optimal use and fits perfectly with your needs. The length of the product Hanwha QNO-7022R is 246 mm. This dimension is essential to ensure optimal use.
Packaging contents
The number of cameras of the product Hanwha QNO-7022R is 1. This product is equipped with a camera that allows capturing high-quality images.
