Manual of product XNZ-L6320
Technical Specifications XNZ-L6320
General Information
-
ModelXNZ-L6320
-
Brand
-
Category
-
Type
-
SKU1301333
-
MPN1301333
Representation / realization
-
CertificationFCC
-
TypeUL
-
Entry/exit alarmCE
-
Entry/exit alarmEAC
-
Connectivity technologyIP security camera
-
Supported installationYes
-
Entry/exit alarmYes
-
Entry/exit alarmWired
-
Indoor
-
Yes
-
Yes
Network
-
Quality of Service (QoS)Yes
-
BluetoothNo
-
BluetoothNo
-
Type of Ethernet interfaceFast Ethernet
-
Supported network protocolsIPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP
-
Network standardsIEEE 802.1x, IEEE 802.3af
-
Number of users20 user(s)
-
Streaming methodMulticast, Unicast
-
Quality of Service (QoS)Yes
Storage support
-
Integrated hard driveNo
-
Built-in memory card readerYes
-
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Flash memory256 MB
-
Internal memory1024 MB
-
Maximum memory card size256 GB
Design
-
Mounting type-
-
FormatTerminal
-
Anti-fogYes
-
Product colorBlack
-
Anti-fogYes
-
Material of the case/bodyMetal
Management features
-
Reset buttonYes
Connectivity
-
Port on the terminal blockYes
-
Headset output1
-
Port on the terminal blockYes
-
Port on the terminal blockYes
-
Headset output1
Technical details
-
Video OutputCVBS
-
Removable infrared filterYes
Power
-
Power supply typeDC, PoE
-
Output CC in volts12
-
Energy consumption (Power over Ethernet (PoE))6.8 W
-
Typical electricity consumption3.5 W
Objective system
-
Number of lenses1
-
Auto focusYes
-
Optical zoom32 x
-
Focal length4.44 - 142.6 mm
-
Auto focusYes
-
TuningMotorized
-
Detection distance (wide)64.2 m
-
Detection distance (tele)2000 m
-
Observation distance (wide)25.7 m
-
Observation distance (tele)803.6 m
-
Recognition distance (wide)12.8 m
-
Recognition distance (tele)401.8 m
-
Identification distance (wide)6.4 m
-
Identification distance (tele)200.9 m
Video
-
Maximum resolution1944 x 1212 pixels
-
Total megapixels2 MP
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
-
Image stabilizerYes
-
Number of images per second60 fps
-
Image stabilizerYes
-
Supported graphic resolutions320 x 240,640 x 360,640 x 480 (VGA),720 x 480,720 x 576,800 x 448,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080)
-
Binary rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bit Rate (VBR)
-
Visual compression formatsH.264, H.265
Image sensor
-
Number of sensors1
-
Sensor typeCMOS
-
Optical sensor size1/2.8 "
Camera
-
Minimum illumination0.005 lux
-
Camera tilt controlNo
-
Camera tilt controlNo
-
White balanceATW, AWC, Indoor, Manual, Outdoor
-
Camera shutter typeElectronic
-
Camera shutter speed2 ~ 1/12000 s
Security
-
Anti-glareYes
-
Anti-glareYes
-
Functions of the IVS system (intelligent video surveillance)Defocus, Face detection
-
Security-supported algorithmEAP-LEAP, EAP-TLS
-
Anti-glareYes
Weight and dimensions
-
Width72 mm
-
Depth135.4 mm
-
Height63.9 mm
-
Weight480 g
Packaging contents
-
Number of cameras1
Audio
-
Audio detectionYes
-
Voice codecsG.711ulaw, G.726
-
Supported audio formatsAAC-LC, ADPCM
Environmental conditions
-
Operating temperature-10 - 55 °C
-
Temperature out of operation-50 - 60 °C
-
Relative humidity rate (storage)0 - 90 %
-
Relative humidity rate (storage)0 - 90 %
Minimum system requirements
-
Support for the Windows operating systemWindows 10
-
Support for the Mac operating systemWindows 7
-
Windows 8.1
-
Mac OS X 10.10 Yosemite
-
Mac OS X 10.11 El Capitan
-
Mac OS X 10.12 Sierra
Other features
-
Supported browsersGoogle Chrome
-
MS Explorer 11
-
MS Edge
-
Mozilla Firefox (Windows 64-bit only)
-
Apple Safari (Mac OS X only)
Night vision
-
Night vision-
Similar products
More product categories from brand Hanwha
More product types from brand Hanwha
Presentation of product XNZ-L6320 specifications from brand Hanwha
Generalities
The EAN code of the product Hanwha XNZ-L6320 is 8801089173799, 5706998423825. This code allows for the unique identification of the product in the distribution system. The brand of the product Hanwha XNZ-L6320 is Hanwha. This brand is known for its quality and innovation in the field of household appliances. The product model Hanwha XNZ-L6320 is XNZ-L6320 | XNZ-L6320. This model ensures optimal performance and an enhanced user experience.
Representation / realization
The certification of the product Hanwha XNZ-L6320 contains FCC, UL, CE, EAC. This certification guarantees compliance with the required safety and performance standards. Does the product Hanwha XNZ-L6320 have a Wide Range Dynamic (WRD)? Oui. This specification ensures optimal performance and increased adaptability in various conditions. Does the product Hanwha XNZ-L6320 have a Day/Night Mode? Oui. This feature allows for adjusting the lighting according to the time of day, thus providing optimal comfort. The type of product Hanwha XNZ-L6320 is an island. This type of design offers a functional and aesthetic solution to optimize space in your interior. The product Hanwha XNZ-L6320 features a Avec fil connectivity technology. This functionality allows for practical and flexible use without the constraints of cables. The design of the product Hanwha XNZ-L6320 supports vertical installation. This feature allows for optimal integration into various spaces, thus offering flexibility and practicality. Does the product Hanwha XNZ-L6320 have Automatic Tracking? Oui. This feature allows you to track your orders in real-time, providing you with peace of mind while shopping. Does the product Hanwha XNZ-L6320 have an entry/end Alarm? Oui. This feature effectively secures access to your space.
Storage support
Does the Hanwha XNZ-L6320 have a built-in hard drive? No. This feature means that the product does not have internal storage. The product Hanwha XNZ-L6320 has compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC. These memory cards ensure optimal performance for storing your data. Does the Hanwha XNZ-L6320 have a built-in memory card reader? Oui. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution. The product Hanwha XNZ-L6320 has a flash memory of 256 Mo. This memory provides an ideal storage capacity for your files, photos, and videos. The internal memory of the product Hanwha XNZ-L6320 contains 1024 Mo. This memory allows for the storage of a large amount of data and applications for smooth and efficient use. The maximum size of the memory card for the product Hanwha XNZ-L6320 is 256 Go. This feature allows for storing a large amount of data, ideal for users who need more space.
Network
Does the product Hanwha XNZ-L6320 have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. Does the Hanwha XNZ-L6320 have Bluetooth? Non. This feature allows for a convenient wireless connection with other compatible devices. The Wifi of the product Hanwha XNZ-L6320 contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices. The Ethernet interface type of the product Hanwha XNZ-L6320 is Fast Ethernet. This type of interface allows for fast and efficient network connections. The supported network protocols of the product Hanwha XNZ-L6320 are IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP. These protocols ensure efficient and reliable communication for your networking needs. Does the product Hanwha XNZ-L6320 have Quality of Service (QoS)? Oui. This feature ensures optimal management of network resources, thus providing a smooth and uninterrupted user experience. The number of users of the product Hanwha XNZ-L6320 is 20 utilisateur(s). This product is ideal for several people. The network standards of the product Hanwha XNZ-L6320 are IEEE 802.1x, IEEE 802.3af. These standards ensure optimal compatibility with various equipment and protocols. The streaming method of the product Hanwha XNZ-L6320 is Multicast, Unicast. This method allows for efficient data transmission to multiple users simultaneously.
Design
The color of the product Hanwha XNZ-L6320 is Noir. This shade gives it a modern and elegant look. Does the product Hanwha XNZ-L6320 have indicators? Oui. These indicators allow you to visualize the operating status of the device. The format of the product Hanwha XNZ-L6320 is a bar. This format allows for practical and efficient use in various contexts. Does the product Hanwha XNZ-L6320 have an anti-fog feature? Oui. This feature helps prevent fogging, ensuring optimal visibility. The material of the product case Hanwha XNZ-L6320 is Métal. This material ensures both durability and elegance. The mounting type of the product Hanwha XNZ-L6320 is -. This type of mounting ensures easy and quick installation, thus guaranteeing optimal use of the product.
Management features
Does the product Hanwha XNZ-L6320 have a Reset Button? Oui. This button allows you to easily reset the product settings.
Technical details
The video output of the Hanwha XNZ-L6320 product contains CVBS. This output allows for connecting multiple devices for an optimal visual experience. Does the product Hanwha XNZ-L6320 have a removable infrared filter? Oui. This filter helps improve image quality by reducing light interference.
Connectivity
Does the product Hanwha XNZ-L6320 have a microphone jack input? No. This feature means that the product does not allow connecting a microphone via a jack. The number of Ethernet LAN (RJ-45) ports of the product Hanwha XNZ-L6320 is 1. These ports provide a stable and fast network connection for your devices. Does the product Hanwha XNZ-L6320 have a DC Input? Oui. This specification ensures compatibility with DC power supplies. Does the product Hanwha XNZ-L6320 have a terminal block port? Oui. This feature allows for a secure and reliable connection for your installations. The headphone output of the Hanwha XNZ-L6320 is %. This output allows for easy connection of headphones or a headset for an optimal audio experience.
Power
The type of power source for the product Hanwha XNZ-L6320 is DC, PoE. This type of power supply ensures optimal performance and efficient use of the device. The typical power consumption of the product Hanwha XNZ-L6320 is 3.5 W. This feature allows for the assessment of the energy efficiency of the device. The energy consumption of the product Hanwha XNZ-L6320 is 6.8 W. This specification allows powering devices via the Ethernet network, thus providing a practical and efficient solution to reduce the number of cables needed. The product Hanwha XNZ-L6320 has a DC output in volts of 12. This specification ensures a stable power supply suitable for the needs of your electronic devices.
Image sensor
The number of sensors of the product Hanwha XNZ-L6320 is 1. This number of sensors allows for precise and efficient image detection. The sensor type of the product Hanwha XNZ-L6320 is CMOS. This type of sensor ensures optimal image quality for your needs. The optical sensor size of the product Hanwha XNZ-L6320 is 1/2.8 ". This size contributes to better image quality, allowing for sharper and more detailed shots.
Camera
The minimum illumination of the product Hanwha XNZ-L6320 is 0.005 lux. This feature ensures optimal performance even in low light conditions. The white balance of the product Hanwha XNZ-L6320 consists of several options, including Auto, Cloudy, Daylight, Fluorescent, Incandescent, and Manual. This feature allows you to adjust the color temperature to achieve true-to-life images. The tilt command of the Hanwha XNZ-L6320 camera is %. This feature allows you to adjust the viewing angle to capture images from different perspectives. Does the product Hanwha XNZ-L6320 have a camera pan command? No. This feature is not available on this model. The type of shutter of the camera of the product Hanwha XNZ-L6320 is Électronique. This type of shutter allows for precise and fast image capture, ideal for action photography. The shutter speed of the camera of the product Hanwha XNZ-L6320 is 2 ~ 1/12000 s. This feature allows capturing sharp images even in low light conditions.
Objective system
Does the product Hanwha XNZ-L6320 have zoom capacity? Oui. This feature allows you to capture precise details, even from a distance. The number of lenses in the product Hanwha XNZ-L6320 is 1. This number determines the quality and versatility of the lens. The optical zoom of the product Hanwha XNZ-L6320 is 32 x. This zoom allows for capturing precise details from a distance, thus providing superior image quality. The focal length of the product Hanwha XNZ-L6320 is 4.44 - 142.6 mm. This specification determines the field of view and the distance at which subjects can be captured accurately. Does the Hanwha XNZ-L6320 have Auto focus? Oui. This feature allows for capturing sharp and accurate images by automatically adjusting the focus. The adjustment of the Hanwha XNZ-L6320 is manual. This specification allows for precise and personalized control of the objective to meet the specific needs of each user. The observation distance (wide) of the product Hanwha XNZ-L6320 is 25.7 m. This feature allows for an extended and clear view over long distances. The observation (tele) distance of the product Hanwha XNZ-L6320 is 803.6 m. This specification allows for an appreciation of the lens's range for distant shots. The detection distance (wide) of the product Hanwha XNZ-L6320 is 64.2 m. This feature allows for effective identification over a wide area, ensuring optimal performance. The detection distance (tele) of the product Hanwha XNZ-L6320 is 2000 m. This specification ensures optimal performance for your remote detection needs. The recognition distance (wide) of the product Hanwha XNZ-L6320 is 12.8 m. This feature allows for effective identification over long distances. The recognition (tele) distance of the product Hanwha XNZ-L6320 is 401.8 m. This specification allows for assessing the effective range of the lens in terms of detecting subjects at a distance. The identification distance (wide) of the product Hanwha XNZ-L6320 is 6.4 m. This specification ensures optimal performance for applications requiring long-range recognition. The identification (tele) distance of the product Hanwha XNZ-L6320 is 200.9 m. This specification allows for determining the remote identification range, essential for optimal use.
Video
The maximum resolution of the product Hanwha XNZ-L6320 is 1944 x 1212 pixels. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. Does the product Hanwha XNZ-L6320 have a Brightness Compensation? Oui. This feature allows for automatic adjustment of the image brightness for a better visual experience. Does the product Hanwha XNZ-L6320 have Highlight Compensation (HLC)? Oui. This feature enhances image quality by reducing highlight effects. The total megapixels of the product Hanwha XNZ-L6320 is 2 MP. This total ensures exceptional image quality for your photos. Does the product Hanwha XNZ-L6320 have noise reduction? Oui. This feature allows for an optimal sound experience by minimizing external distractions. Does the product Hanwha XNZ-L6320 have Scrolling and mirroring? Oui. This feature allows for a smooth and immersive visual experience. Does the Hanwha XNZ-L6320 have an image stabilizer? Oui. This image stabilizer allows for sharp videos and photos, even in motion. Does the product Hanwha XNZ-L6320 have Personal Data Masking? Oui. This feature ensures the protection of users' personal information when streaming videos. The supported graphic resolutions of the product Hanwha XNZ-L6320 are 320 x 240,640 x 360,640 x 480 (VGA),720 x 480,720 x 576,800 x 448,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080). These resolutions provide optimal display quality for your content. The number of frames per second of the product Hanwha XNZ-L6320 is 60 ips. This specification ensures optimal smoothness when playing videos. The binary bitrate control of the product Hanwha XNZ-L6320 contains Constant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bit Rate (VBR). This control allows for optimizing video quality while effectively managing file sizes. The product Hanwha XNZ-L6320 has visual compression formats: H.264, H.265. These formats ensure optimal image quality for your videos.
Security
The supported security algorithm of the product Hanwha XNZ-L6320 contains EAP-LEAP, EAP-TLS. This algorithm ensures optimal protection of your data. The intelligent video surveillance system of the product Hanwha XNZ-L6320 has features such as face detection and intrusion. These advanced functionalities ensure optimal security by enabling proactive and effective monitoring. Does the Hanwha XNZ-L6320 product filter IP addresses? Oui. This feature enhances security by blocking unauthorized access. Does the product Hanwha XNZ-L6320 have a Motion Detector (video)? Oui. This device provides effective monitoring by capturing video footage during motion detections. Does the Hanwha XNZ-L6320 have an Anti-glare? Oui. This feature ensures optimal protection against unwanted reflections, thus providing an enhanced visual experience.
Weight and dimensions
The depth of the product Hanwha XNZ-L6320 is 135.4 mm. This dimension allows for optimal integration into your space. The width of the product Hanwha XNZ-L6320 is 72 mm. This dimension is essential to ensure optimal integration into your space. The weight of the product Hanwha XNZ-L6320 is 480 g. This weight is ideal for ensuring optimal use and easy handling. The height of the product Hanwha XNZ-L6320 is 63.9 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Packaging contents
The number of cameras of the product Hanwha XNZ-L6320 is 1. This product is equipped with a camera that allows capturing high-quality images.
Audio
The supported audio formats of the product Hanwha XNZ-L6320 are AAC-LC, ADPCM. These formats ensure optimal compatibility for an enriching listening experience. The voice codec of the Hanwha XNZ-L6320 product contains G.711ulaw, G.726. This voice codec ensures optimal audio quality for your communications. Does the product Hanwha XNZ-L6320 have Audio Detection? Oui. This feature allows capturing and analyzing surrounding sounds for an enhanced audio experience.
Environmental conditions
The product Hanwha XNZ-L6320 has an operating relative humidity (H-H) of 0 - 90 %. This specification ensures optimal operation in a wide range of ambient humidity. The non-operating temperature of the product Hanwha XNZ-L6320 is -50 - 60 °C. This specification ensures that the product can withstand extreme conditions without suffering damage. The operating temperature of the product Hanwha XNZ-L6320 is -10 - 55 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The relative humidity (storage) rate of the product Hanwha XNZ-L6320 is 0 - 90 %. This rate ensures optimal conditions for the preservation and durability of the product.
Other features
The browser support for the product Hanwha XNZ-L6320 includes Google Chrome, MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only. This feature ensures an optimal user experience on compatible platforms.
Minimum system requirements
Does the product Hanwha XNZ-L6320 support the Mac operating system? Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra. This feature ensures optimal compatibility for Mac users. Does the product Hanwha XNZ-L6320 support the Windows operating system? Windows 10, Windows 7, Windows 8.1. This feature ensures optimal compatibility with Windows systems, providing a smooth and uninterrupted user experience.
Night vision
Does the product Hanwha XNZ-L6320 have night vision? -. This feature allows for clear visibility in the dark, thus providing enhanced security.
