Manuals of product DS-7608NI-Q1
Technical Specifications DS-7608NI-Q1
General Information
-
ModelDS-7608NI-Q1
-
Brand
-
Category
-
Type
-
SKU1240336
-
MPN1240336
Representation / realization
-
Number of channels read simultaneously8 channels
-
Output bandwidth80 Mbit/s
-
Number of channels read simultaneously8 channels
-
Maximum resolution4096 x 2160 pixels
-
Supported video formatH.264, H.264+, H.265, H.265+, MPEG4
-
Output bandwidth80 Mbit/s
-
Supported resolutions4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720
-
Bi-directional dialogueYes
-
Supported audio formatsG.711 A-law, G.711 μ-law, G.726
-
Number of users64 user(s)
Wireless LAN Features
-
WifiNo
Disk reader
-
Number of installed hard drives0
-
Hard drive capacity- Go
-
Number of supported hard drives1
-
Maximum storage capacity8 To
-
Hard drive interfaceSATA
Connectivity
-
Audio RCA inputs1
-
LAN Ethernet: data transfer rate10, 100 Mbit/s
-
DC InputYes
-
Audio RCA inputs1
-
Audio RCA inputs1
-
Quantity of USB 2.0 Ports2
-
Audio RCA inputs1
-
Supported network protocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
-
DC InputYes
-
Audio RCA inputs1
Weight and dimensions
-
Width320 mm
-
Depth240 mm
-
Height48 mm
-
Weight1000 g
Environmental conditions
-
Operating relative humidity (H-H)10 - 90 %
-
Operating temperature-10 - 55 °C
Power
-
Output voltage12 V
-
Typical electricity consumption10 W
Features
-
Product colorBlack
-
Assembly gridYes
-
Rack capacity1U
-
Assembly gridYes
-
CertificationFCC Part 15 Subpart B, ANSI C63.4-2014
-
CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:
Similar products
More product categories from brand Hikvision
Other Hikvision
Audio Hikvision
Interior Hikvision
Phones Hikvision
Tools Hikvision
More product types from brand Hikvision
Presentation of product DS-7608NI-Q1 specifications from brand Hikvision
Wireless LAN Features
The Wifi of the product Hikvision DS-7608NI-Q1 contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices.
Generalities
The brand of the product Hikvision DS-7608NI-Q1 is Hikvision. This brand is known for its quality and innovation in the field of household appliances. The product model Hikvision DS-7608NI-Q1 is DS-7608NI-Q1 | DS-7608NI-Q1. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Hikvision DS-7608NI-Q1 is 6954273670245. This code allows for the unique identification of the product in the distribution system.
Disk reader
The number of installed hard drives for the product Hikvision DS-7608NI-Q1 is 0. This number helps optimize storage and improve the overall performance of the device. The maximum storage capacity of the product Hikvision DS-7608NI-Q1 is 8 To. This capacity meets all your storage needs. The hard drive capacity of the product Hikvision DS-7608NI-Q1 is - Go. This capacity allows for storing a large amount of data, ideal for users with significant storage needs. The number of hard drives supported by the product Hikvision DS-7608NI-Q1 is 1. This feature allows for optimizing storage and adapting needs based on users. The hard drive interface of the product Hikvision DS-7608NI-Q1 is SATA. This interface allows for a fast and efficient connection for data transfer.
Representation / realization
The number of video input channels of the product Hikvision DS-7608NI-Q1 is 8 canaux. These channels allow for optimal connectivity for your multimedia devices. The maximum resolution of the product Hikvision DS-7608NI-Q1 is 4096 x 2160 pixels. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. The input bandwidth of the product Hikvision DS-7608NI-Q1 is 80 Mbit/s. This specification ensures optimal performance for data processing. The number of channels read simultaneously for the product Hikvision DS-7608NI-Q1 is 8 canaux. This feature allows for a smooth and efficient user experience when using multiple audio or video sources. The supported video format of the product Hikvision DS-7608NI-Q1 contains H.264, H.264+, H.265, H.265+, MPEG4. This format allows for smooth and high-quality playback of your multimedia content. The output bandwidth of the product Hikvision DS-7608NI-Q1 is 80 Mbit/s. This feature ensures fast and efficient data transmission. The supported resolutions of the product Hikvision DS-7608NI-Q1 are 4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720. These resolutions provide exceptional image quality for an immersive viewing experience. Does the product Hikvision DS-7608NI-Q1 have bi-directional communication? Oui. This feature allows for smooth and reciprocal interaction, thereby enhancing the user experience. The supported audio formats of the product Hikvision DS-7608NI-Q1 are G.711 A-law, G.711 μ-law, G.726. These formats ensure optimal compatibility for an enriching listening experience. The number of users of the product Hikvision DS-7608NI-Q1 is 64 utilisateur(s). This product is ideal for several people.
Weight and dimensions
The height of the product Hikvision DS-7608NI-Q1 is 48 mm. This dimension is essential to ensure that the product fits perfectly in your space. The depth of the product Hikvision DS-7608NI-Q1 is 240 mm. This dimension allows for optimal integration into your space. The width of the product Hikvision DS-7608NI-Q1 is 320 mm. This dimension is essential to ensure optimal integration into your space. The weight of the product Hikvision DS-7608NI-Q1 is 1000 g. This weight is ideal for ensuring optimal use and easy handling.
Environmental conditions
The product Hikvision DS-7608NI-Q1 has an operating relative humidity (H-H) of 10 - 90 %. This specification ensures optimal operation in a wide range of ambient humidity. The operating temperature of the product Hikvision DS-7608NI-Q1 is -10 - 55 °C. This specification ensures optimal performance within a temperature range suitable for various environments.
Connectivity
The number of Ethernet LAN (RJ-45) ports of the product Hikvision DS-7608NI-Q1 is 1. These ports provide a stable and fast network connection for your devices. The data transfer rate of the product Hikvision DS-7608NI-Q1 is 10, 100 Mbit/s. This rate ensures a fast and efficient connection for your networking needs. The number of HDMI ports on the Hikvision DS-7608NI-Q1 is 1. This detail is essential for determining compatibility with your multimedia devices. Does the Hikvision DS-7608NI-Q1 have an HDMI Output? Oui. This feature allows for easy connection of the product to external displays for a better visual experience. The VGA output port (D-Sub) of the product Hikvision DS-7608NI-Q1 contains 1. This port allows for easy connection of monitors and projectors for an optimal viewing experience. The product Hikvision DS-7608NI-Q1 has 1 RCA audio output. This output allows for an easy and high-quality connection for your audio devices. The number of USB 2.0 ports on the Hikvision DS-7608NI-Q1 is 2. These ports allow for a fast and efficient connection for your devices. The supported network protocols of the product Hikvision DS-7608NI-Q1 are TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS. These protocols ensure efficient and reliable communication for your networking needs. Does the product Hikvision DS-7608NI-Q1 have a DC Input? Oui. This specification ensures compatibility with DC power supplies. The product Hikvision DS-7608NI-Q1 has 1 RCA audio input. This feature allows for an easy and high-quality connection with various audio devices.
Power
The output voltage of the Hikvision DS-7608NI-Q1 is 12 V. This specification ensures optimal performance for your electrical needs. The typical power consumption of the product Hikvision DS-7608NI-Q1 is 10 W. This feature allows for the assessment of the energy efficiency of the device.
Features
The color of the product Hikvision DS-7608NI-Q1 is Noir. This shade gives it a modern and elegant look. Does the product Hikvision DS-7608NI-Q1 have a built-in power button? Oui. This feature allows for simplified use and optimal control of the device. The capacity of the Hikvision DS-7608NI-Q1 rack is 1U. This specification ensures optimal space for the installation of your equipment. Does the product Hikvision DS-7608NI-Q1 have a mounting bracket? Oui. This feature determines the compatibility and ease of installation of the product. The certification of the product Hikvision DS-7608NI-Q1 contains FCC Part 15 Subpart B, ANSI C63.4-2014\nCE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:. This certification guarantees compliance with the required safety and performance standards.
