Name: Kyocera ECOSYS M3655idn
Brand: Kyocera
SKU: 1245365
Rating: 80 (16 reviews)

Manuals of product ECOSYS M3655idn

First page image of the manual for ECOSYS M3655idn

The Kyocera ECOSYS M3655idn multifunction printer stands out for its impressive performance, notably a printing speed of 55 pages per minute, making it an ideal choice for demanding work environments. Its maximum print resolution of 1200 x 1200 DPI ensures documents and images of exceptional clarity. Additionally, the color scanning capability at 40 pages per minute facilitates the quick management of important documents, making this model an effective all-in-one solution. However, some drawbacks are worth noting. The duplex printing function being manual may prove less convenient for users seeking a fully automatic solution. Furthermore, the lack of Wi-Fi connectivity limits usage flexibility, which can be problematic in modern work environments. Although the weight of 24.7 kg may complicate transport and installation, especially in tight spaces, the machine remains robust and reliable. The writing scores reflect an overall positive user experience, with a score of 80 for experience and 85 for features. The provided documentation is also very comprehensive, with a score of 90, thus facilitating product handling. In terms of value for money, the score of 78 indicates that, despite impressive features, some limitations, such as the absence of Wi-Fi, may influence the purchasing decision. In summary, the Kyocera ECOSYS M3655idn is an excellent choice for those looking for a high-performing and versatile printer, but it is essential to consider its drawbacks to ensure it meets the specific needs of your work environment.

Score details

User experience

The user experience is generally positive due to the integrated multi-functionality, although the manual duplex printing feature may be less convenient.

Performance

The printing speed of 55 pages per minute is impressive, but may not be sufficient for very high print volumes in demanding work environments.

Design

The weight of 24.7 kg can complicate transport and installation, especially in tight spaces.

Features

The features, including color printing and scanning at 40 pages per minute, are excellent and provide an all-in-one solution.

Value for money

Although the product offers good print quality with a maximum resolution of 1200 x 1200 DPI, the lack of Wi-Fi connectivity limits its usability flexibility.

Documentation

The product comes with comprehensive documentation, including a user manual and a FAQ, making it easy to get started.

Advantages

Fast printing of 55 pages per minute

Manual duplex printing to save paper

Maximum resolution of 1200 x 1200 DPI

Color scanning at 40 pages per minute

All-in-one functionality: printing, copying, scanning, faxing

Disadvantages

Manual double-sided printing

No Wi-Fi connectivity

Insufficient printing speed for large volumes

Heavy weight, difficult to move

Copy resolution lower than printing

Technical Specifications ECOSYS M3655idn

General Information

Model

ECOSYS M3655IDN
Brand

Kyocera
Category

Computers and accessories
Type

Printer
SKU

1245365
MPN

1245365

Print speed

Printing technology

Laser
Printing

Mono printing
Print speed (black, normal quality, A4/US Letter)

55 ppm
Maximum resolution

1200 x 1200 DPI
Duplex printing speed (Black, normal quality, A4/US Letter)

39.5 ppm
Preheating time

25 s
Copy time for the first page (Black, normal)

4.9 s
Poster printing function

Yes
Duplex printing mode

Auto
Poster printing function

Yes
Layout option

2, 4
Poster printing function

Yes
Poster printing function

Yes
Poster printing function

Yes
Poster printing function

Yes
Borderless printing

No

Copier

Copy

Simple copy
Maximum number of copies

999 copies
Resizing copy

25 - 400 %
Max. resolution of copies

600 x 600 DPI
All-in-one function (N=)

2, 4
Release time of the first print (black, normal)

6 s
Function ID-Card Copy

Yes
Duplex copy mode

Auto
Copy speed (normal quality, black, A4)

55 cpm
Function ID-Card Copy

Yes
Function ID-Card Copy

Yes
Function ID-Card Copy

Yes

Digitization

Digitization

Color scanning
Optical scanning resolution

600 x 600 DPI
Supported image formats

JPEG, TIFF
Support for text formats

PDF, XPS
Double-sided scanning

Yes
Duplex scanning mode

Auto
Scan to

E-mail, FTP, SMB, TWAIN, USB, WIA
Scanning speed (color)

40 ppm
Scanner speed (black)

60 ppm
Duplex scanning speed (color)

64 ppm
Duplex scanning speed (black)

100 ppm
Scan drivers

TWAIN, WIA
Gray levels

256
Scanning technology

CIS

Fax

Fax

Simple fax
Modem speed

33.6 Kbit/s
Fax transmission speed

3 sec/page
Fax coding methods

JBIG, MH, MMR (Fax coding method), MR
Quick numbering

Yes
Fax resolution (black)

400 x 400 DPI
Fax memory

256 pages
Quick numbering

Yes

Features

Service cycle (Maximum)

27500 pages per month
All-in-one multitasking

Yes
Number of print cartridges

1
Languages of the page description

Epson LQ, IBM ProPrinter XL24E, OpenXPS, PCL 6, PCL XL, TIFF, XPS
Service cycle (recommended)

5000 - 15000 pages per month
Printing colors

Black
Printer fonts

Barcode, Bitmap, Windows
All-in-one multitasking

Yes
Replacement cartridges

TK-3190 (25,000 pages)
Double-sided functions

Copy, Fax, Print, Scan
Number of printer fonts

93

Design

Product color

Black, White
Color display

Yes
Market position

Professional
Screen size

7 "
Color display

Yes
Color display

Yes
Order type

Touchscreen

Network

Contactless payment

No
Ethernet/LAN

Yes
LAN Ethernet: data transfer rate

10,100,1000 Mbit/s
Mobile printing technologies

Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Wiring technology

10/100/1000Base-T(X)
Contactless payment

No
Contactless payment

No

Representation / realization

Built-in memory card reader

-
Processor frequency

1200 MHz
Sound pressure level (impression)

56 dB
Sound pressure level (impression)

56 dB
Sound power level (standby)

30 dB
Internal memory

1000 MB
Processor family

ARM Cortex-A9
Coprocessor frequency

1.2 GHz
Integrated into the processor

Yes
Maximum internal memory

3000 MB
Compatible memory cards

SD, SDHC
Number of processor cores

2

Power

AC input voltage

220 - 240 V
AC input frequency

50 - 60 Hz
Electricity consumption (average operation)

711 W
Average power consumption in Copy mode

731 W
Energy consumption (loan)

54 W
Energy consumption (in standby mode)

0.5 W
Electricity consumption (average operation)

711 W
Energy consumption (standby mode)

30 W
Energy Star, typical electrical consumption (TEC)

2.91 kWh/week

Paper management

Maximum ISO A series paper size

A4
Types of multi-purpose bins

Legal
ISO, Format Series A (A0...A9)

A4, A5, A6
Type of paper tray support

Plain paper
Weight of the media, automatic document feeder

50 - 120 g/m²
Weight of paper tray support

60 - 120 g/m²
Maximum print format

216 x 356 mm
ISO, Formats Series-B (B0...B9)

B5, B6
Non-ISO print support sizes

Folio (media size), Legal (media size), Letter (media size)
Support width customization

70 - 216 mm
Customization of support length

148 - 356 mm
Weight of paper tray support

60 - 120 g/m²
Weight of the multifunctional tray support

60 - 220 g/m²

Input and output capacity

Input capacity of the paper tray 1

500 sheets
Input capacity of the paper tray 1

500 sheets
Maximum input capacity

2600 sheets
Input capacity of the paper tray 1

500 sheets
Total number of power supply units

1
Input capacity of the paper tray 1

500 sheets
Automatic Document Feeder (ADF)

Yes
Input capacity of multi-purpose trays

100 sheets
Automatic Document Feeder (ADF)

Yes
Automatic document feeder capacity

75 sheets
Maximum number of feed bins

5
Paper feed type

Cassette, Paper tray

Weight and dimensions

Width

480 mm
Depth

495 mm
Height

590 mm
Weight

24700 g

Connectivity

USB port

Yes
Standard interfaces

Ethernet, USB 2.0
Quantity of USB 2.0 Ports

3
USB port

Yes
Optional connectivity

Ethernet, Wireless LAN

Certificate

Compliant with the standard (WEEE, Waste Electrical and Electronic Equipment)

Yes
Certification

TÜV/GS, CE, ISO 9001, ISO 14001.

Minimum system requirements

Support for the Linux operating system

Yes
Support for the Mac operating system

Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Support for the Linux operating system

Yes

Environmental conditions

Operating relative humidity (H-H)

15 - 80 %
Temperature out of operation
Operating temperature

-20 - 40 °C
Relative humidity rate (storage)
Operating altitude

10 - 32.5 °C
Non-operating altitude
10 - 90 %
0 - 3500 m
0.6 - 15000 m

Sustainability

Sustainability certificates

Blue Angel
REACH
RoHS
EPEAT Silver
ENERGY STAR

Packaging information

Package width

633 mm
Package depth

570 mm
Package height

710 mm
Package weight

31200 g

Packaging contents

Imaging unit included

Yes
Included cartridge capacity (black)

10000 pages
Imaging unit included

Yes
Cables included

Sector

Logistics data

Harmonized System Code

84433100

Frequently Asked Questions

What is the weight of the Kyocera ECOSYS M3655idn model?

The Kyocera ECOSYS M3655idn model weighs 24,700 g.

What is the recommended method for removing paper jammed in the printer?

It is advised to gently remove the paper. First, turn off the printer and ensure that the print head is not sticking out of the paper and that no pieces of paper are left inside.

Why is my printer not recognizing the original cartridges?

Non-authentic cartridges may not be detected by the printer, and a message may indicate that the cartridge is empty. The manual for the purchased cartridge often provides solutions; otherwise, it is best to contact the seller.

What can cause poor print quality?

Poor print quality can have several causes. Check if the toners or cartridges are full. For inkjet printers, cleaning is often necessary, as the cartridges may be dry or the print head damaged. For laser printers, calibration is recommended.

What is the difference between a laser printer and an inkjet printer?

A laser printer uses toner to print, while an inkjet printer uses ink.

Why is my inkjet printer printing black streaks?

Generally, this is due to a damaged inkjet printer cartridge that needs to be replaced.

What does the acronym DPI mean?

DPI stands for Dots Per Inch and indicates the number of ink droplets deposited on the paper per inch during printing.

What certifications does the Kyocera ECOSYS M3655idn have?

The Kyocera ECOSYS M3655idn has the following certifications: TÜV/GS, CE, ISO 9001, and ISO 14001.

How many cartridges can be inserted into the Kyocera ECOSYS M3655idn?

The Kyocera ECOSYS M3655idn can accommodate 1 cartridge.

What is the size of the screen on the Kyocera ECOSYS M3655idn?

The screen of the Kyocera ECOSYS M3655idn measures 7 inches.

What is the height of the Kyocera ECOSYS M3655idn?

The height of the Kyocera ECOSYS M3655idn is 590 mm.

What is the width of the Kyocera ECOSYS M3655idn?

The Kyocera ECOSYS M3655idn has a width of 480 mm.

What is the depth of the Kyocera ECOSYS M3655idn?

The depth of the Kyocera ECOSYS M3655idn is 495 mm.

Is the manual for the Kyocera ECOSYS M3655idn available in French?

Yes, the manual for the Kyocera ECOSYS M3655idn is available in French.
