Manual of product ICSe 5103-20
Editorial note
The Liebherr ICSe 5103-20 refrigerator stands out for its integrated and elegant design, perfect for fitting into any kitchen while providing convenient access to your food. With a generous storage capacity of 264 L and adjustable tempered glass shelves, it allows for optimal organization, thus meeting the daily needs of users. Additionally, features such as the interior LED lighting and the vegetable drawer add a touch of practicality, while its noise level of 35 dB ensures quiet operation. However, some drawbacks should be noted. The model does not have an automatic defrost system for the freezer, which requires regular manual maintenance to prevent frost buildup. Furthermore, its energy efficiency class E could lead to higher electricity costs compared to more energy-efficient models. The lack of a multi-flow air system may also limit air circulation, thus affecting food preservation. In terms of performance, the user experience is generally positive with a score of 85, while the design receives a high score of 90 due to its modern aesthetics. Nevertheless, the perceived value of the product is slightly lower, with a score of 70, due to its energy consumption. Repairability is also an area for improvement, marked by a score of 65, as the absence of automatic defrosting requires regular monitoring. In summary, the Liebherr ICSe 5103-20 is a solid choice for those seeking a refrigerator that combines design and functionality, but it may not be suitable for those who prioritize higher energy efficiency and simpler maintenance.Score details
User experience
The user experience is very positive thanks to a sleek and integrated design that easily fits into the kitchen while providing convenient access to food.
Performance
The storage capacity of 264 L with adjustable tempered glass shelves is appreciated, but the lack of a multi-airflow system may affect the uniform temperature inside.
Design
The design is modern and stylish, with practical features like interior LED lighting and a vegetable drawer.
Value for money
Although the product is of good quality, its energy efficiency class E may lead to higher electricity costs compared to more economical models.
repairability
The lack of an automatic defrost system for the freezer requires regular manual maintenance, which can be a drawback for some users.
Robustness
The weight of 54 kg can make installation or moving difficult, especially in tight spaces, but the material ensures good durability.
Usability
The ergonomics are satisfactory with features like an open door alarm, but the absence of a dedicated compartment for cans may disappoint some users.
Features
The refrigerator offers a good range of features, although it lacks a quick freeze system, which could be a downside for frequent users.
Support
The available user manual is helpful, but the lack of additional support could be a disadvantage for some customers.
Documentation
The provided documentation is comprehensive but could be improved to include more information on maintenance and advanced features.
Advantages
Integrated and sleek design
264 L capacity, adjustable shelves
LED lighting and vegetable drawer
Quiet operation at 35 dB
Holiday mode for energy savings
Disadvantages
No automatic defrosting of the freezer
Energy class E, high costs
Limited air circulation in the refrigerator
Weight of 54 kg, difficult installation
No compartment for cans
Technical Specifications ICSe 5103-20
General Information
-
ModelICSE 5103-20
-
Brand
-
Category
-
Type
-
SKU1393357
-
MPN1393357
Design
-
Device placementIntegrated
-
Product colorWhite
-
Hinge location of doorRight
-
Door opening angle115 °
-
Door setDoor rail
-
Adjustable shelvesYes
-
Material of the case/bodyPlastic, Steel
-
Shelf materialGlass
-
Adjustable shelvesYes
Representation / realization
-
Ice maker-
-
Total net capacity264 L
-
Climate classSN-T
-
Minimum operating temperature-26 °C
-
Maximum operating temperature9 °C
-
Sound level35 dB
-
Vacation functionYes
-
Vacation functionYes
Refrigerator
-
No frost (refrigerator)-
-
Multi-airflow system (refrigerator)-
-
Number of vegetable drawers-
-
Net capacity of the refrigerator183 L
-
Cooling systemVentilated
-
Very cold operating optionYes
-
Type of lampLED
-
Very cold operating optionYes
-
Number of shelves/bins in the refrigerator4
-
Very cold operating optionYes
-
Number of egg trays1
-
Very cold operating optionYes
-
Very cold operating optionYes
-
Refrigerator temperature range2 - 9 °C
-
Very cold operating optionYes
-
Very cold operating optionYes
Freezer
-
No Frost (freezer)-
-
Number of shelves/bins in the freezer-
-
Quick freeze function-
-
Location of the ice compartmentLow-placed
-
Net capacity of the freezer81 L
-
Freezing capacity6 kg/24h
-
Autonomy in case of power failure11 h
-
Number of stars (indicates preservation possibilities)4*
-
Automatic defrosting (freezer)No
-
Ice cube trayYes
-
Freezing temperature (min)-26 °C
-
Ice cube trayYes
Cool zone
-
New compartment areaYes
Ergonomics
-
Adjustable feetYes
-
Adjustable feetYes
-
Adjustable feetYes
-
Adjustable feetYes
Power
-
Energy efficiency classE
-
Annual energy consumption228.1 kWh
-
Connected charge- W
-
AC input voltage220 - 240 V
-
AC input frequency50-60 Hz
-
Current1.4 A
Weight and dimensions
-
Weight54000 g
-
Installation compartment width570 mm
-
Depth550 mm
-
Installation compartment height1788 mm
-
Width560 mm
-
Depth550 mm
-
Height1772 mm
Packaging information
-
Package weight58000 g
-
Package width555 mm
-
Package depth622 mm
-
Package height1829 mm
Frequently Asked Questions
How can I prevent water accumulation on the glass shelves of my refrigerator?
What should I do if unpleasant odors are coming from my refrigerator?
How much space should I leave around my refrigerator?
What is R-410A?
What is the weight of the Liebherr ICSe 5103-20?
What is the height of the Liebherr ICSe 5103-20?
What is the width of the Liebherr ICSe 5103-20?
What is the depth of the Liebherr ICSe 5103-20?
What is the energy rating of the Liebherr ICSe 5103-20?
Is the manual for the Liebherr ICSe 5103-20 available in French?
Similar products
More product categories from brand Liebherr
Other Liebherr
More product types from brand Liebherr
Presentation of product ICSe 5103-20 specifications from brand Liebherr
General Information
The Liebherr ICSe 5103-20, a creation of the Liebherr brand, stands out for its commitment to quality and innovation in the home appliance sector. This model, referenced under the number ICSe 5103-20 | 999212451, is designed to deliver exceptional performance while enhancing the user experience.
Design
This integrated refrigerator blends harmoniously into your kitchen while ensuring easy access to your food. Its white finish adds a modern and elegant touch to your space. The door hinge is positioned at the bottom, facilitating a 115° opening, which optimizes daily use. Additionally, the appliance is equipped with a built-in screen, making it user-friendly. Made of plastic and steel, the casing combines robustness and aesthetics, while the tempered glass shelves add a dimension of durability and style. The adjustable shelves allow you to customize the storage space according to your specific needs.
Capacity and Performance
With a total net capacity of 264 L, the Liebherr ICSe 5103-20 offers generous storage space for your food and beverages. It is designed to operate efficiently within a temperature range of -26 °C to 9 °C, allowing it to adapt to various environments. In terms of noise, it operates at a sound level of 35 dB, ensuring optimal comfort in your home. This model also includes an air filter and a vacation function, allowing for reduced energy consumption during your extended absences.
Refrigerator
The refrigerator has a net capacity of 183 L, sufficient to meet daily needs. Its ventilated cooling system ensures optimal air circulation, while the LED interior lighting allows for easy visibility of stored products. Although it does not have a No Frost system, it is equipped with automatic defrosting, preventing ice buildup. The refrigerator also includes 4 shelves and a vegetable drawer, as well as an egg compartment and a bottle rack for efficient organization.
Freezer
The freezer, located at the top, offers a net capacity of 81 L, ideal for storing frozen foods. It has a freezing capacity of 6 kg/24h and maintains an autonomy of 11 hours in case of a power outage, ensuring the safety of your provisions. Although it requires manual defrosting, it is equipped with an interior light to facilitate access to food.
Ergonomics
The Liebherr ICSe 5103-20 is designed with an open door alarm and a temperature alarm, ensuring effective monitoring of its functionalities. The adjustable feet allow for height adjustment of the appliance for optimal user comfort.
Power
Rated in energy efficiency class E, this model consumes 228.1 kWh annually, which may influence your electricity costs. Its AC input voltage of 220-240 V and frequency of 50-60 Hz ensure compatibility with standard electrical systems.
Dimensions and Weight
With a weight of 54 kg, the Liebherr ICSe 5103-20 is designed for easy handling. Its installation dimensions are 570 mm wide, 550 mm deep, and 1788 mm high, ensuring optimal integration into your kitchen.
Packaging Information
The package weight is 58 kg, with dimensions of 555 mm wide, 622 mm deep, and 1829 mm high, ensuring optimal protection during transport and storage.
