Manuals of product MultiSync EA223WM
Technical Specifications MultiSync EA223WM
General Information
-
ModelMULTISYNC EA223WM
-
Brand
-
Category
-
Type
-
SKU159311
-
MPN159311
Screen
-
Screen size22 "
-
Response time
-
Screen brightness (typical)5 ms
-
Screen resolution
-
Display technology250 cd/m²
-
Contrast ratio
-
Dynamic contrast report1680 x 1050 pixels
-
Vertical viewing angle
-
Vertical viewing angleLED
-
Number of colors displayed
-
Image format1000:1
-
Type HD
-
Touch screen25000:1
-
Supported graphic resolutions
-
No pixel178 °
-
Horizontal digital frequency
-
Vertical scanning frequency178 °
-
Type of feedback
-
Screen shape16.78 million colors
-
Image format
-
Type of panel16:10
-
Maximum discount rate
-
Touch screenWSXGA+
-
-
No
-
-
640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 768 (WXGA),1280 x 960,1366 x 768,1400 x 1050 (SXGA+),1440 x 900 (WXGA+),1680 x 1050 (WSXGA+)
-
-
0.282 x 0.282 mm
-
-
31.5 - 82.3 kHz
-
-
56 - 75 Hz
-
-
W-LED
-
-
Flat
-
-
16:10
-
-
TN
-
-
60 Hz
-
-
No
Other features
-
ScreenLED
-
Energy efficiency class (old)A
-
Integrated TV tunerNo
-
Light sensorYes
-
CertificationCE; Energy Star 5.0; FCC Class B; GEEA/Energy Label; ISO 9241-307 (pixel failure class I); MPR III; PCT/Gost; RoHS; TCO 6.0; TÜV Ergonomics; TÜV GS; UL/C-UL, CSA
-
Light sensorYes
-
Light sensorYes
-
Consumption (eco mode)12 W
Connectivity
-
Number of DVI-D/DVI-I ports-
-
Quantity of HDMI ports-
-
Headphone outputYes
-
Number of upstream ports1
-
Number of upstream ports1
-
Number of downstream USB Type A ports4
-
Number of upstream ports1
-
Number of upstream ports1
-
Headphone outputYes
-
USB hub version2.0
-
Headphone outputYes
-
Number of upstream ports1
-
Headphone outputYes
-
Headphone outputYes
-
HDMINo
Design
-
Market position-
-
Product colorWhite
Multimedia
-
Built-in speakersYes
-
Number of speakers2
-
Rated power of RMS2 W
-
Built-in cameraNo
Ergonomics
-
PivotYes
-
PivotYes
-
PivotYes
-
VESA standard100 x 100 mm
-
Oscillation angle range-170 - 170 °
-
Inclination angle-5 - 30 °
-
Height adjustment130 mm
-
PivotYes
-
IndicatorsEnergy
-
PivotYes
-
PivotYes
-
PivotYes
-
PivotYes
-
Rotation angle0 - 90 °
-
Cable lock location typeKensington
Thin client
-
Thin client installedNo
Power
-
Consumption (max)25 W
-
Energy consumption (standby mode)- W
-
Typical electricity consumption12 W
-
Annual energy consumption18 kWh
-
Energy consumption (eco mode)0.5 W
Weight and dimensions
-
Device width (support included)503.5 mm
-
Height (without support)- mm
-
Height (without support)- mm
-
Weight (without support)- g
-
Device width (support included)503.5 mm
-
Depth (support included)218 mm
-
Height (support included)384 mm
-
Weight (with support)5600 g
Representation / realization
-
Support for the Windows operating systemYes
Environmental conditions
-
Operating relative humidity (H-H)20 - 80 %
-
Operating temperature
-
5 - 35 °C
Packaging contents
-
Cables includedAC
-
Quick Start GuideDisplayPort
-
USB
-
Yes
Sustainability
-
Sustainability certificatesEPEAT Gold
-
ENERGY STAR
Network
-
Ethernet/LANNo
-
Ethernet/LANNo
-
Ethernet/LANNo
Similar products
More product categories from brand NEC
More product types from brand NEC
Presentation of product MultiSync EA223WM specifications from brand NEC
Generalities
The product model NEC MultiSync EA223WM is MultiSync EA223WM | 60003293. This model ensures optimal performance and an enhanced user experience. The EAN code of the product NEC MultiSync EA223WM is 4053162535831, 5028695108790. This code allows for the unique identification of the product in the distribution system. The brand of the product NEC MultiSync EA223WM is NEC. This brand is known for its quality and innovation in the field of household appliances.
Design
The market position of the product NEC MultiSync EA223WM is -. This product is primarily aimed at professionals, offering features tailored to their specific needs. The color of the product NEC MultiSync EA223WM is Blanc. This shade gives it a modern and elegant look.
Other features
The NEC MultiSync EA223WM screen contains LED. This screen offers exceptional image quality for an immersive visual experience. The energy efficiency class (old) of the product NEC MultiSync EA223WM is A. This feature indicates the level of energy performance of the product. Does the product NEC MultiSync EA223WM have a built-in TV tuner? No. This product does not allow you to receive television channels directly. Does the product NEC MultiSync EA223WM have a built-in power button? Oui. This feature allows for simplified use and optimal control of the device. The certification of the product NEC MultiSync EA223WM contains CE; Energy Star 5.0; FCC Class B; GEEA/Energy Label; ISO 9241-307 (pixel failure class I); MPR III; PCT/Gost; RoHS; TCO 6.0; TÜV Ergonomics; TÜV GS; UL/C-UL, CSA. This certification guarantees compliance with the required safety and performance standards. Does the product NEC MultiSync EA223WM have ECO mode? Oui. This mode helps reduce energy consumption while maintaining optimal performance. Does the product NEC MultiSync EA223WM have a light sensor? Oui. This sensor allows for automatic adjustment of the lighting based on ambient brightness. The energy-saving consumption of the product NEC MultiSync EA223WM is 12 W. This feature allows for optimizing energy efficiency while reducing operating costs.
Connectivity
Does the product NEC MultiSync EA223WM have HDCP? Oui. This specification ensures the protection of digital content against unauthorized copying. The number of DVI-D/DVI-I ports of the product NEC MultiSync EA223WM is -. This feature determines compatibility with various screens and video equipment. The number of VGA (D-Sub) ports on the NEC MultiSync EA223WM is 1. This port allows for easy connection with various devices and monitors. The product NEC MultiSync EA223WM does not have DVI-D ports. This feature may be important depending on your connectivity needs. The number of HDMI ports on the NEC MultiSync EA223WM is -. This detail is essential for determining compatibility with your multimedia devices. The number of downstream USB Type A ports of the product NEC MultiSync EA223WM is 4. These ports allow for easy and fast connection to various devices. The number of DisplayPort interfaces of the product NEC MultiSync EA223WM is 1. This specification allows for optimal connectivity with various devices. The headphone output of the NEC MultiSync EA223WM is %. This output allows for easy connection of headphones or a headset for an optimal audio experience. Does the product NEC MultiSync EA223WM have a power input section? Oui. This section ensures a reliable and efficient power supply for the optimal operation of the device. The version of the USB hub of the product NEC MultiSync EA223WM is 2.0. This version ensures fast and efficient connectivity for all your devices. Does the product NEC MultiSync EA223WM have a DVI Port? Oui. This port allows you to connect devices with a digital video interface, ensuring optimal image quality. Does the product NEC MultiSync EA223WM have a built-in USB hub? Oui. This feature allows you to connect multiple USB devices simultaneously, thus enhancing your user experience. The number of upstream ports of the product NEC MultiSync EA223WM is 1. This number determines the connection capacity with other devices. Does the product NEC MultiSync EA223WM have a headphone output? Oui. This feature allows you to easily connect headphones or a headset for an immersive audio experience. Does the NEC MultiSync EA223WM have HDMI? Non. This connectivity allows for the transmission of both high-quality videos and audios.
Screen
The screen size of the product NEC MultiSync EA223WM is 22 ". This dimension allows for an optimal visual experience for all your content. The response time of the product NEC MultiSync EA223WM is 5 ms. This fast response time ensures a smooth and responsive visual experience. The typical screen brightness of the product NEC MultiSync EA223WM is 250 cd/m². This feature ensures optimal visibility in various lighting conditions. The screen resolution of the product NEC MultiSync EA223WM is 1680 x 1050 pixels. This feature ensures optimal display quality for a pleasant visual experience. The display technology of the product NEC MultiSync EA223WM is LED. This technology ensures optimal image quality for an immersive visual experience. The contrast ratio of the product NEC MultiSync EA223WM is 1000:1. A high contrast ratio makes images sharper and colors more vibrant, thus providing an enhanced visual experience. The dynamic contrast ratio of the product NEC MultiSync EA223WM is 25000:1. This ratio helps enhance image quality by providing deeper blacks and brighter whites. The horizontal viewing angle of the product NEC MultiSync EA223WM is 178 °. This angle allows for optimal viewing from different angles, thus providing an immersive and comfortable experience. The vertical viewing angle of the NEC MultiSync EA223WM is 178 °. This angle allows for optimal viewing from different angles, thus providing an enhanced visual experience. The number of colors displayed for the product NEC MultiSync EA223WM is 16,78 millions de couleurs. This detail is essential for appreciating the visual quality of the screen. The image format of the product NEC MultiSync EA223WM is 16:10. This format is ideal for an immersive visual experience. The HD Type of the product NEC MultiSync EA223WM is WSXGA+. This HD Type ensures exceptional image quality for an immersive viewing experience. Does the product NEC MultiSync EA223WM have 3D Compatibility? No. This product does not support 3D technology. The supported graphic resolutions of the product NEC MultiSync EA223WM are 640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 768 (WXGA),1280 x 960,1366 x 768,1400 x 1050 (SXGA+),1440 x 900 (WXGA+),1680 x 1050 (WSXGA+). These resolutions provide optimal display quality for your content. The pixel pitch of the product NEC MultiSync EA223WM is 0.282 x 0.282 mm. This pixel pitch ensures optimal display quality without distortion. The vertical scanning frequency of the product NEC MultiSync EA223WM is 56 - 75 Hz. This specification ensures optimal display smoothness for a pleasant visual experience. The image format of the product NEC MultiSync EA223WM is 16:10. This format is ideal for an immersive visual experience. The type of feedback for the product NEC MultiSync EA223WM is W-LED. This type of feedback offers optimal display quality and vibrant colors. The screen shape of the product NEC MultiSync EA223WM is Plat. This feature ensures an optimal visual experience for all your multimedia needs. The horizontal digital frequency of the product NEC MultiSync EA223WM is 31.5 - 82.3 kHz. This specification ensures optimal performance for your display needs. The panel type of the product NEC MultiSync EA223WM is TN. This type of panel offers excellent display quality and vibrant colors. The maximum discount rate of the product NEC MultiSync EA223WM is 60 Hz. This rate ensures optimal display fluidity for an enhanced user experience. Does the product NEC MultiSync EA223WM have a touchscreen? Non.
Multimedia
Does the NEC MultiSync EA223WM have a built-in camera? Non. This camera allows you to capture precious moments with ease. The number of speakers of the product NEC MultiSync EA223WM is 2. This number ensures optimal sound quality for an enriching multimedia experience. Does the product NEC MultiSync EA223WM have built-in speakers? Oui. These speakers provide an immersive and convenient audio experience. The RMS rated power of the product NEC MultiSync EA223WM is 2 W. This specification ensures optimal sound quality for an enriching multimedia experience.
Thin client
Does the product NEC MultiSync EA223WM have Thin client installed? No. This product does not have this feature.
Representation / realization
Does the product NEC MultiSync EA223WM support the Windows operating system? Oui. This feature ensures optimal compatibility with Windows systems, providing a smooth and uninterrupted user experience.
Power
The maximum consumption of the product NEC MultiSync EA223WM is 25 W. This specification allows for the assessment of the energy efficiency of the device. The energy consumption in standby mode of the product NEC MultiSync EA223WM is - W. This feature helps reduce electricity consumption when the device is not in use, thus contributing to energy savings. The annual energy consumption of the product NEC MultiSync EA223WM is 18 kWh. This specification allows you to assess energy efficiency and the impact on your electricity bill. The typical power consumption of the product NEC MultiSync EA223WM is 12 W. This feature allows for the assessment of the energy efficiency of the device. The energy consumption in economy mode of the product NEC MultiSync EA223WM is 0.5 W. This feature significantly reduces electrical consumption while maintaining optimal performance.
Weight and dimensions
The width of the product NEC MultiSync EA223WM is 503.5 mm. This dimension allows for optimal integration into various spaces. The height of the product NEC MultiSync EA223WM is - mm. This dimension is essential to ensure the product fits your space. The weight of the product NEC MultiSync EA223WM is - g. This weight is essential for assessing the maneuverability and transport of the product. The unsupported depth of the product NEC MultiSync EA223WM is - mm. This dimension is essential to ensure optimal integration into your space. The width of the device NEC MultiSync EA223WM is 503.5 mm. This dimension includes the stand, ensuring a seamless integration into your space. The depth of the product NEC MultiSync EA223WM is 218 mm. This dimension is essential to ensure optimal integration into your space. The height (including support) of the product NEC MultiSync EA223WM is 384 mm. This dimension is essential to ensure that the product fits perfectly in your space. The weight (with support) of the product NEC MultiSync EA223WM is 5600 g. This weight includes all the necessary accessories for its use.
Ergonomics
Does the product NEC MultiSync EA223WM have an on-screen display (OSD)? Oui. This display allows for intuitive navigation through the product settings. Does the product NEC MultiSync EA223WM have a cable lock port? No. This product does not have this security feature. Does the product NEC MultiSync EA223WM have VESA Mounting? Oui. This feature allows you to easily attach your screen to a wall mount, thereby optimizing space and improving user comfort. The product NEC MultiSync EA223WM has the VESA Standard 100 x 100 mm. This standard ensures optimal compatibility with wall mounts and articulated arms, thus facilitating the installation and adjustment of your screen. The tilt angle of the product NEC MultiSync EA223WM is -5 - 30 °. This angle allows for adjusting the position for optimal comfort. The oscillation angle range of the product NEC MultiSync EA223WM is -170 - 170 °. This feature allows for optimal flexibility during its use. Does the product NEC MultiSync EA223WM have indicators? Énergie. These indicators allow you to visualize the operating status of the device. Is the NEC MultiSync EA223WM product Rotating? Oui. This feature allows for optimal usage flexibility. Does the product NEC MultiSync EA223WM have a height adjustment? No. This product does not allow for height adjustment. Does the product NEC MultiSync EA223WM have Plug and Play? Oui. This feature allows for quick and hassle-free installation, making the use of the product even more enjoyable. Does the product NEC MultiSync EA223WM have a height adjustment? No. This product does not allow for height adjustment. Does the product NEC MultiSync EA223WM have an Incline Adjustment? Oui. This feature allows you to adjust the angle according to your needs for optimal comfort. The type of cable lock location for the product NEC MultiSync EA223WM is Kensington. This type of lock provides optimal security to protect your device against theft. Does the product NEC MultiSync EA223WM have Pivot? Oui. This feature allows for optimal flexibility to adapt to your needs. The rotation angle of the product NEC MultiSync EA223WM is 0 - 90 °. This angle allows for optimal usage flexibility.
Environmental conditions
The product NEC MultiSync EA223WM has an operating relative humidity (H-H) of 20 - 80 %. This specification ensures optimal operation in a wide range of ambient humidity. The operating temperature of the product NEC MultiSync EA223WM is 5 - 35 °C. This specification ensures optimal performance within a temperature range suitable for various environments.
Packaging contents
The included cable of the product NEC MultiSync EA223WM contains a power plug. This cable is essential for ensuring an optimal electrical connection. Does the product NEC MultiSync EA223WM have a Quick Start Guide? Yes. This guide allows you to quickly and easily start using the product.
Sustainability
The product NEC MultiSync EA223WM has Sustainability Certificates: EPEAT Gold, ENERGY STAR. These certificates ensure that the product meets high standards for energy efficiency and environmental respect.
Network
The Wifi of the product NEC MultiSync EA223WM contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices. Does the product NEC MultiSync EA223WM have Ethernet/LAN? Non. This specification determines the network connectivity of the product. Does the NEC MultiSync EA223WM have Bluetooth? Non. This feature allows for a convenient wireless connection with other compatible devices.
