Manual of product UM351Wi
Technical Specifications UM351Wi
General Information
-
ModelUM351WI
-
Brand
-
Category
-
Type
-
SKU454019
-
MPN454019
Projector
-
Projector brightness3500 ANSI lumens
-
Projection technology3LCD
-
Native resolution of the projectorWXGA (1280x800)
-
Compatible screen size58 - 110 "
-
Supported aspect ratios16:10
-
Supported aspect ratios16:10
-
Projection distance0.1 - 0.51 m
-
Contrast ratio6000:1
-
Correction of the trapezium, vertical-10 - 10 °
-
Correction of the trapezium, vertical-10 - 10 °
-
Vertical scanning frequency50 - 120 Hz
-
Horizontal scanning domain15 - 100 kHz
Multimedia
-
Built-in speakersYes
-
Number of built-in speakers1
-
Rated power of RMS20 W
Objective system
-
Zoom ratio-
-
TuningManual
-
Focal length- mm
-
Shift81 %
-
Projection ratio0.36:1
-
Digital zoom1.4 x
-
Fixed Focal Length4.7 mm
-
Opening range1.8 - 1.8
Design
-
Product colorWhite
-
Product typeUltra short throw projector
-
Cable anti-theft lockYes
-
Cable lock location typeKensington
-
PositioningDesk
Screen
-
Built-in screenNo
Power
-
Power supplySector
-
Typical electricity consumption257 W
-
Energy consumption (standby mode)0.5 W
-
Consumption (max)324 W
-
AC input voltage100 - 240 V
-
AC input frequency50 - 60 Hz
-
Consumption (eco mode)214 W
-
Automatic power cut-offYes
Light source
-
Lifespan of the light source5000 h
-
Power of the lamp200 W
-
Lifespan of the light source (eco mode)6000 h
-
Lamp power (eco mode)160 W
-
Type of light sourceLamp
Video
-
Analog signal format systemNTSC
-
Full HDNTSC 3.58
-
3D CompatibilityNTSC 4.43
-
Supported graphic resolutionsPAL
-
PAL 60
-
PAL M
-
PAL N
-
SECAM
-
Yes
-
No
-
640 x 480 (VGA)
-
720 x 480
-
720 x 576
-
800 x 600 (SVGA)
-
832 x 624
-
1440 x 900 (WXGA+)
-
1600 x 1200 (UXGA)
-
1600 x 900
-
1680 x 1050 (WSXGA+)
-
1920 x 1080 (HD 1080)
-
1920 x 1200 (WUXGA)
Connectivity
-
Quantity of HDMI ports2
-
Quantity of HDMI ports2
-
Type of HDMI connectorFull size
-
Quantity of USB 2.0 Ports3
-
USB connectorUSB Type-A, USB Type-B
-
Headset output1
-
High-Definition Mobile Interface (MHL, Mobile High-Definition Link)Yes
-
S-Video Input0
-
S-Video Input0
-
DVI PortNo
-
High-Definition Mobile Interface (MHL, Mobile High-Definition Link)Yes
-
High-Definition Mobile Interface (MHL, Mobile High-Definition Link)Yes
-
Headset output1
-
Serial interface typeRS-232
Network
-
Number of Ethernet LAN ports (RJ-45)1
-
Ethernet/LANYes
-
WifiNo
Other features
-
RS-232 port1
-
Resolution (maximum analog)1920 x 1200 pixels
Environmental conditions
-
Operating temperature5 - 40 °C
-
Temperature out of operation-10 - 50 °C
-
Relative humidity rate (storage)20 - 80 %
-
Relative humidity rate (storage)20 - 80 %
Technical details
-
Sustainability certificatesRoHS
Features
-
HDCP-
-
CertificationCE
-
Password protectionGost-R
-
Sound level (economy mode)TÜV GS
-
Sound levelYes
-
Password protection28 dB
-
29 dB
-
Yes
Weight and dimensions
-
Width378 mm
-
Depth428 mm
-
Height112 mm
-
Weight5600 g
Storage support
-
Built-in memory card readerNo
Packaging contents
-
Lift hooks includedYes
-
Type of remote controlIR
-
Cables includedAC, VGA
-
Lift hooks includedYes
-
Lift hooks includedYes
-
Lift hooks includedYes
Similar products
More product categories from brand NEC
More product types from brand NEC
Presentation of product UM351Wi specifications from brand NEC
Generalities
The brand of the product NEC UM351Wi is NEC. This brand is known for its quality and innovation in the field of household appliances. The product model NEC UM351Wi is UM351Wi | 40000900. This model ensures optimal performance and an enhanced user experience. The EAN code of the product NEC UM351Wi is 4053162787285, 5028695611566, 5028695611740, 5028695611627, 5415247026037, 8032976097892, 4053162912441, 8592978059453. This code allows for the unique identification of the product in the distribution system.
Multimedia
Does the product NEC UM351Wi have built-in speakers? Oui. These speakers provide an immersive and convenient audio experience. The RMS rated power of the product NEC UM351Wi is 20 W. This specification ensures optimal sound quality for an enriching multimedia experience. The number of built-in speakers of the product NEC UM351Wi is 1. These speakers provide immersive audio quality for an optimal listening experience.
Objective system
The zoom ratio of the product NEC UM351Wi is fixed. This ratio determines the lens's ability to enlarge or reduce the image while maintaining optimal image quality. The adjustment of the NEC UM351Wi is manual. This specification allows for precise and personalized control of the objective to meet the specific needs of each user. The offset of the product NEC UM351Wi is 81 %. This offset helps to optimize the performance and accuracy of the objective. The focal length of the product NEC UM351Wi is - mm. This specification determines the field of view and the distance at which subjects can be captured accurately. The projection ratio of the product NEC UM351Wi is 0.36:1. This ratio determines the distance at which the projected image will be displayed relative to the screen size. The digital zoom of the product NEC UM351Wi is 1.4 x. This zoom allows for capturing precise details even from a distance. The product goal system NEC UM351Wi has a fixed focal length of 4.7 mm. This feature allows for images with great sharpness and exceptional quality. The opening amplitude of the product NEC UM351Wi is 1.8 - 1.8. This amplitude allows for optimal results in various lighting conditions.
Projector
The brightness of the product NEC UM351Wi is 3500 ANSI lumens. This feature ensures a clear and bright projection, even in well-lit environments. The compatible screen size of the product NEC UM351Wi is 58 - 110 ". This specification allows the projector to adapt to different screen formats for an optimal viewing experience. The projector NEC UM351Wi features a 3LCD projection technology. This technology ensures optimal image quality and an immersive visual experience. The native resolution of the product NEC UM351Wi is WXGA (1280x800). This feature ensures optimal image quality for your presentations and entertainment. The image format of the product NEC UM351Wi is 16:10. This format is ideal for an immersive visual experience. The aspect ratio of the product NEC UM351Wi supports 16:10. This aspect ratio allows for display flexibility suited to different content. The projection distance of the product NEC UM351Wi is 0.1 - 0.51 m. This specification allows for optimizing the visual experience based on the available space. The contrast ratio of the product NEC UM351Wi is 6000:1. A high contrast ratio makes images sharper and colors more vibrant, thus providing an enhanced visual experience. The correction of the trapezoid, horizontal, of the product NEC UM351Wi is -10 - 10 °. This feature allows for adjusting the projected image for better accuracy and optimal rendering. The product NEC UM351Wi features trapezoidal correction, vertical of -10 - 10 °. This functionality allows for adjusting the projected image for optimal rendering, regardless of the projection angle. The vertical scanning frequency of the product NEC UM351Wi is 50 - 120 Hz. This specification ensures optimal display smoothness for a pleasant visual experience. The horizontal scanning range of the product NEC UM351Wi is 15 - 100 kHz. This range allows for excellent display quality and optimal image smoothness.
Screen
The NEC UM351Wi has a built-in screen. This screen provides an immersive and convenient visual experience, making it easier to use the device.
Design
The color of the product NEC UM351Wi is Blanc. This shade gives it a modern and elegant look. The product type of NEC UM351Wi is Projecteur à focale ultra courte. This product is ideal for an immersive and comfortable audio experience. Does the product NEC UM351Wi have a cable lock port? No. This product does not have this security feature. The type of cable lock location for the product NEC UM351Wi is Kensington. This type of lock provides optimal security to protect your device against theft. The positioning of the product NEC UM351Wi is Bureau. This positioning allows for optimizing its use and ensuring an optimal user experience.
Light source
The lifespan of the light source of the product NEC UM351Wi is 5000 h. This feature ensures prolonged and efficient use, allowing you to enjoy lasting lighting. The power of the lamp (economy mode) of the product NEC UM351Wi is 160 W. This specification ensures optimal energy efficiency while providing quality lighting. The lifespan of the light source (eco mode) of the product NEC UM351Wi is 6000 h. This longevity ensures prolonged and economical use. The power of the lamp of the product NEC UM351Wi is 200 W. This power ensures optimal lighting for your needs. The type of light source of the product NEC UM351Wi is Lampe. This light source ensures effective illumination tailored to your needs.
Power
The maximum consumption of the product NEC UM351Wi is 324 W. This specification allows for the assessment of the energy efficiency of the device. The energy consumption in standby mode of the product NEC UM351Wi is 0.5 W. This feature helps reduce electricity consumption when the device is not in use, thus contributing to energy savings. The typical power consumption of the product NEC UM351Wi is 257 W. This feature allows for the assessment of the energy efficiency of the device. The power supply of the product NEC UM351Wi is Secteur. This power supply ensures optimal autonomy for prolonged use. The AC input voltage of the NEC UM351Wi is 100 - 240 V. This specification ensures optimal compatibility with standard electrical systems. The AC input frequency of the product NEC UM351Wi is 50 - 60 Hz. This specification is essential to ensure optimal operation and compatibility with electrical systems. The energy-saving consumption of the product NEC UM351Wi is 214 W. This feature allows for optimizing energy efficiency while reducing operating costs. Does the product NEC UM351Wi have an automatic power cut-off? Oui. This feature ensures increased safety by turning off the device when necessary.
Video
Does the product NEC UM351Wi have Full HD? Oui. This feature ensures exceptional image quality for an immersive viewing experience. The supported graphic resolutions of the product NEC UM351Wi are 640 x 480 (VGA),720 x 480,720 x 576,800 x 600 (SVGA),832 x 624,1440 x 900 (WXGA+),1600 x 1200 (UXGA),1600 x 900,1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA). These resolutions provide optimal display quality for your content. Does the product NEC UM351Wi have 3D Compatibility? No. This product does not support 3D technology. The analog signal format system of the product NEC UM351Wi contains NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM. This system ensures compatibility with various broadcasting formats, thus providing an optimal viewing experience.
Network
The number of Ethernet LAN (RJ-45) ports of the product NEC UM351Wi is 1. These ports provide a stable and fast network connection for your devices. Does the product NEC UM351Wi have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. The Wifi of the product NEC UM351Wi contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices.
Other features
The RS-232 port of the NEC UM351Wi contains 1. This port is essential for ensuring reliable serial communication with other devices. The maximum analog resolution of the product NEC UM351Wi is 1920 x 1200 pixels. This feature ensures optimal image quality for an enriching visual experience.
Environmental conditions
The non-operating temperature of the product NEC UM351Wi is -10 - 50 °C. This specification ensures that the product can withstand extreme conditions without suffering damage. The operating temperature of the product NEC UM351Wi is 5 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The relative humidity (storage) rate of the product NEC UM351Wi is 20 - 80 %. This rate ensures optimal conditions for the preservation and durability of the product. The product NEC UM351Wi has an operating relative humidity (H-H) of 20 - 80 %. This specification ensures optimal operation in a wide range of ambient humidity.
Technical details
The product NEC UM351Wi has Sustainability Certificates: RoHS. These certificates ensure that the product meets high standards for energy efficiency and environmental respect.
Connectivity
The HDMI connector type of the product NEC UM351Wi is Pleine taille. This connector allows for an optimal connection for your multimedia devices. The number of HDMI ports on the NEC UM351Wi is 2. This detail is essential for determining compatibility with your multimedia devices. The number of VGA (D-Sub) ports on the NEC UM351Wi is 2. This port allows for easy connection with various devices and monitors. The number of USB 2.0 ports on the NEC UM351Wi is 3. These ports allow for a fast and efficient connection for your devices. The USB connector of the product NEC UM351Wi is USB Type-A, USB Type-B. This connector allows for a fast and efficient connection for data transfer and device charging. The product NEC UM351Wi has a composite video input. This input allows for easy connection of analog video devices for an optimal viewing experience. Does the product NEC UM351Wi have a microphone jack input? No. This feature means that the product does not allow connecting a microphone via a jack. The product NEC UM351Wi has an input component of the audiovisual device (YPbPr/YCbCr) 0. This specification allows for a high-quality connection for an optimal visual experience. The product NEC UM351Wi has an S-Video input. This input allows you to connect video devices with enhanced image quality. Does the product NEC UM351Wi have a DVI Port? Non. This port allows you to connect devices with a digital video interface, ensuring optimal image quality. Does the product NEC UM351Wi have a DC Input? Oui. This specification ensures compatibility with DC power supplies. Does the product NEC UM351Wi have a high-definition mobile interface (MHL, Mobile High-Definition Link)? Oui. This specification allows for easy connection of mobile devices to high-definition screens for an optimal viewing experience. The headphone output of the NEC UM351Wi is %. This output allows for easy connection of headphones or a headset for an optimal audio experience. The serial interface type of the product NEC UM351Wi is RS-232. This type of interface allows for effective communication between different devices.
Features
The certification of the product NEC UM351Wi contains CE, Gost-R, TÜV GS. This certification guarantees compliance with the required safety and performance standards. Does the product NEC UM351Wi have an on-screen display (OSD)? Oui. This display allows for intuitive navigation through the product settings. Does the product NEC UM351Wi have HDCP? -. This specification ensures the protection of digital content against unauthorized copying. The noise level in eco mode of the product NEC UM351Wi is 28 dB. This noise level ensures discreet and pleasant use, ideal for noise-sensitive environments. The noise level of the product NEC UM351Wi is 29 dB. This noise level allows for pleasant use without excessive noise disturbances. Does the product NEC UM351Wi have Password Protection? Oui. This feature ensures the security of your data by restricting unauthorized access.
Weight and dimensions
The width of the product NEC UM351Wi is 378 mm. This dimension is essential to ensure optimal integration into your space. The depth of the product NEC UM351Wi is 428 mm. This dimension allows for optimal integration into your space. The height of the product NEC UM351Wi is 112 mm. This dimension is essential to ensure that the product fits perfectly in your space. The weight of the product NEC UM351Wi is 5600 g. This weight is ideal for ensuring optimal use and easy handling.
Storage support
Does the NEC UM351Wi have a built-in memory card reader? Non. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution.
Packaging contents
Does the product NEC UM351Wi come with a remote control? Oui. Does the product NEC UM351Wi have a Quick Start Guide? Yes. This guide allows you to quickly and easily start using the product. The included cable of the product NEC UM351Wi contains a power plug. This cable is essential for ensuring an optimal electrical connection. The remote control of the product NEC UM351Wi is wireless. This feature provides great freedom of movement and makes it easy to use. Does the product NEC UM351Wi have a User Manual? Oui. This document provides clear instructions for optimal use of the product. Does the product NEC UM351Wi come with included lift hooks? Oui. These hooks make it easier to use and store the product.
