Manual of product NC7MXX
Editorial note
The Neutrik NC7MXX stands out for its optimal connectivity thanks to its composite connector, ensuring reliable performance in various applications. Its robustness is enhanced by quality materials such as zinc and nickel, providing protection against shocks and scratches, making it a wise choice for diverse environments. Additionally, it supports a wide temperature range of -30 to 80 °C, giving it great versatility. However, this product has some drawbacks. Its price may seem high compared to other similar connectors, which could deter some buyers. Furthermore, the moisture resistance, indicated by an IP40 code, may not be sufficient for applications requiring waterproof protection. The insertion and withdrawal force of 20 N, while secure, may make its use less convenient for some individuals, and its limited compatibility with AWG 18 wires may restrict its use in more demanding installations. In summary, the Neutrik NC7MXX is a high-performance and highly robust product, but its cost and certain specifications may not suit all users.Score details
User experience
The user experience is generally positive due to the optimal connectivity of the composite connector, but the insertion and withdrawal force of 20 N can make its use less convenient for some people.
Performance
The electrical performance is high, with a dielectric strength of 1500 V and a low contact resistance of 3 mΩ, ensuring reliable connectivity in electronic applications.
Robustness
Durability and robustness are excellent due to the materials used, such as zinc and nickel, which allow for resistance to shocks and scratches.
Value for money
The price of the Neutrik NC7MXX may be considered high compared to other similar connectors, which could deter some users.
Usability
Although handling is facilitated by the insertion and withdrawal force, compatibility with 18 AWG wires may limit its use for certain needs.
Features
The product offers a wide temperature range of -30 to 80 °C, making it versatile for various applications, but the IP40 rating for moisture resistance may not be sufficient for uses requiring waterproof protection.
Advantages
Reliable and versatile connectivity
Durability against shocks and scratches
Operates from -30 to 80 °C
Guaranteed high electrical performance
Easy and secure handling
Disadvantages
Expensive compared to other connectors.
IP40 protection insufficient for certain applications.
Insertion force too high for some users.
Limited to AWG 18 wires only.
Dimensions not suitable for tight spaces.
Technical Specifications NC7MXX
General Information
-
ModelNC7MXX
-
Brand
-
Category
-
Type
-
SKU1714485
-
MPN1714485
Features
-
Connector(s)XLR
-
Product colorAluminum, Black
-
AWG wire sizes18
-
Contacts of the plating connectorSilver/Nickel
-
International Protection Code (IP)IP40
-
Heart size1 mm²
-
Electric force1500 V
-
Contact resistance3 mΩ
-
Capacitance between the contacts9 pF
-
Lifespan (cycles)1000
-
Tension50 V
-
Current5 A
-
Hull armorNickel
-
Locking element materialZinc
-
Locking element materialZinc
-
Withdrawal force20 N (1 kilogram-force = 9.81 Newton)
-
Withdrawal force20 N (1 kilogram-force = 9.81 Newton)
Packaging information
-
Quantity1 piece(s)
Environmental conditions
-
Operating temperature-30 - 80 °C
Weight and dimensions
-
Outer diameter8 mm
Frequently Asked Questions
Is the Neutrik NC7MXX manual available in French?
Similar products
More product categories from brand Neutrik
More product types from brand Neutrik
Presentation of product NC7MXX specifications from brand Neutrik
General Information
The Neutrik NC7MXX is a product from the brand Neutrik, known for its excellence and innovation in the connector industry. This model, identified by the code NC7MXX, is designed to deliver optimal performance, ensuring an enhanced user experience. The EAN code 7613187000232 allows for unique identification of this product in distribution systems.
Features
The Neutrik NC7MXX features a composite connector, ensuring effective connectivity suitable for various uses. Its black aluminum finish gives it a modern and elegant aesthetic. This product is compatible with AWG wires of size 18, providing application flexibility. The connector contacts, plated with silver and nickel, ensure a reliable and durable connection.
This model has an IP40 protection rating, indicating protection against solid bodies and limited resistance to moisture. The core size is 1 mm², ensuring adequate electrical performance. Its dielectric strength is impressive, reaching 1500 V, while the contact resistance is measured at 3 mΩ, ensuring optimal performance in electronic applications.
With a capacitance of 9 pF between contacts, the Neutrik NC7MXX is designed for prolonged use, with a lifespan in cycles of 1000. The operating voltage is 50 V and the supported current is 5 A, thus ensuring safe and efficient use. The zinc housing offers enhanced durability, while the nickel shielding protects against impacts and scratches. Its insertion and withdrawal force is 20 N, ensuring easy handling while maintaining a secure connection.
Packaging Information
The Neutrik NC7MXX is sold individually, with a quantity of 1 piece in each package, thus facilitating stock management.
Environmental Conditions
Designed to withstand varied conditions, this product can operate in a temperature range of -30 to 80 °C, thus ensuring its effectiveness in extreme environments.
Weight and Dimensions
The outer diameter of the Neutrik NC7MXX is 8 mm, a dimension that ensures adequate compatibility with other equipment and installations.
