The Newline TT-9823QA stands out with its 98-inch screen offering a 4K Ultra HD resolution and an impressive contrast ratio of 5000:1, ensuring an immersive and high-quality visual experience. Its infrared touch technology allows for smooth interaction with 1 mm precision and the ability to detect up to 40 simultaneous touch points, enhancing the user experience. Additionally, it is equipped with an Android 13 system, 8 GB of RAM, and an octa-core processor, ensuring optimal performance and efficient multitasking management. However, the significant weight of 108 kg can make installation and handling difficult, especially for wall mounting. The active power consumption of 207 W is also high, which could impact long-term energy costs. The lack of Type A USB ports limits connectivity with some common peripherals, potentially requiring adapters for optimal use. Furthermore, its imposing dimensions may pose space issues in restricted environments. In summary, the Newline TT-9823QA offers impressive features and remarkable display quality, but its weight, energy consumption, and connectivity limitations should be considered when purchasing.Score details
User experience
The user experience is enhanced by infrared touch technology with 1 mm precision and the ability to detect up to 40 simultaneous touch points, providing a smooth and responsive interaction.
Performance
Performance is optimal thanks to the integration of an Android 13 system with 8 GB of RAM and an octa-core processor, allowing for efficient multitasking management.
Battery life
The active power consumption of 207 W can be considered high, which could impact long-term energy costs.
Design
The product is built with a tempered glass screen, ensuring increased durability and resistance, although its weight of 108 kg may make installation difficult.
Features
The 98-inch screen with 4K Ultra HD resolution and a high contrast ratio offers exceptional display quality for an immersive visual experience.
Value for money
Although the product is feature-rich, the absence of Type A USB ports may limit connectivity, requiring additional adapters for optimal use.
Usability
The imposing dimensions of 2258.4 mm in width may pose space issues for some users, making it difficult to integrate into smaller environments.
Advantages
98-inch screen, 4K Ultra HD resolution
Precise touch technology, 40 simultaneous points
Wi-Fi 6 connectivity, Bluetooth 5.2
Tempered glass screen, durable and resistant
Android 13, 8 GB RAM, octa-core processor
Disadvantages
High weight, difficult installation.
High power consumption in active mode.
Absence of Type A USB ports.
Imposing dimensions, limited space.
Less responsive touch.
Technical Specifications TT-9823QA
General Information
-
ModelTT-9823QA
-
Brand
-
Category
-
Type
-
SKU1960926
-
MPN1960926
Screen
-
Contrast ratio5000:1
-
Vertical viewing angle178 °
-
Vertical viewing angle178 °
-
Screen size98 "
-
Screen brightness450 cd/m²
-
Response time5 ms
-
Screen resolution3840 x 2160 pixels
-
Workspace2161 x 1216 mm
-
Palm interferenceYes
-
Hardness of the mines7H
-
Palm interferenceYes
-
Tactile precision1 mm
-
Touch technologyMultiple pressures
-
LED backlightingDirect LED
-
Palm interferenceYes
-
Number of simultaneous touchpoints40
-
Image format16:9
-
Type HD4K Ultra HD
-
Surface materialTempered glass
-
Number of colors displayed1.07 billion colors
-
Spread rate5 %
-
Palm interferenceYes
-
Touch screen typeInfrared
Weight and dimensions
-
Weight108000 g
-
Height1344.8 mm
-
Width2258.4 mm
-
Depth122 mm
Power
-
Typical electricity consumption207 W
-
Energy consumption (standby mode)0.5 W
Ergonomics
-
Mean time between failures50000 h
-
VESA mountYes
-
Product colorBlack
-
VESA standard800 x 600 mm
-
VESA mountYes
Network
-
Bluetooth model5.2
-
WifiYes
-
WifiYes
-
WifiYes
-
Wi-Fi standardWi-Fi 6 (802.11ax)
-
LAN Ethernet: data transfer rate10,100,1000 Mbit/s
Audio
-
Speaker power20 W
-
Number of built-in speakers2
-
Built-in speakersYes
Connectivity
-
Quantity of USB Type C ports1
-
Number of Ethernet LAN ports (RJ-45)2
-
S/PDIF output portYes
-
Quantity of USB Type C ports1
-
HDMI version2.0
-
Quantity of USB Type C ports1
-
DisplayPort version1.2
-
Quantity of Type B USB 2.0 Touch ports4
-
Quantity of USB Type C ports1
-
Quantity of USB Type C ports1
-
Quantity of HDMI output ports3
-
Quantity of Type B USB 2.0 Touch ports4
Computer system
-
Installed operating systemAndroid 13
-
Number of processor cores8
-
Integrated into the processorYes
-
RAM capacity8 GB
-
The architecture of the processorARM Cortex A73 + ARM Cortex A53
-
Type of RAMDDR4
Projector
-
Built into the projectorNo
Packaging contents
-
Number of styluses2
Representation / realization
-
Built-in memory card readerYes
-
Compatible memory cardsSD
Frequently Asked Questions
What is the weight of the Newline TT-9823QA?
What is the screen size of the Newline TT-9823QA?
What is the height of the Newline TT-9823QA?
What is the screen resolution of the Newline TT-9823QA?
What is the width of the Newline TT-9823QA?
What is the depth of the Newline TT-9823QA?
Is the manual for the Newline TT-9823QA available in French?
Similar products
More product categories from brand Newline
Presentation of product TT-9823QA specifications from brand Newline
General Information
The Newline TT-9823QA, manufactured by the renowned brand Newline, stands out for its innovation and quality in the field of household appliances. This model, identified by the EAN code 0850046374258, is designed to deliver exceptional performance and an enhanced user experience.
Screen
The 98-inch screen of the Newline TT-9823QA displays an impressive resolution of 3840 x 2160 pixels, providing remarkable image quality. With a contrast ratio of 5000:1, images are sharper and colors more vibrant, ensuring an immersive visual experience. The horizontal and vertical viewing angles of 178° allow for optimal viewing from different angles.
The brightness of 450 cd/m² ensures visibility even in bright environments, while the fast response time of 5 ms guarantees smooth display. The screen is also equipped with infrared touch technology, capable of detecting up to 40 simultaneous touch points, offering smooth and precise interaction.
With a workspace of 2161 x 1216 mm and an anti-glare screen, this model is ideal for optimizing comfort and productivity. The tempered glass surface, with a hardness of 7H, ensures increased durability and an elegant design.
Weight and Dimensions
The Newline TT-9823QA weighs 108 kg, which can make its installation and handling delicate. Its dimensions are 1344.8 mm in height, 2258.4 mm in width, and 122 mm in depth, requiring special attention when integrating into different spaces.
Power
In terms of energy efficiency, the typical power consumption is 207 W, while the standby consumption is only 0.5 W, allowing for energy savings when not in use.
Ergonomics
The average time between failures of the Newline TT-9823QA is 50,000 hours, demonstrating its reliability. This model is compatible with wall mounting thanks to the VESA 800 x 600 mm standard, facilitating its installation and allowing for space-saving. Its black color gives it a modern and elegant look.
Network
For connectivity, the Newline TT-9823QA is equipped with Wi-Fi 6 (802.11ax) technology and Bluetooth 5.2, ensuring fast and stable connections. It also offers Ethernet/LAN ports for reliable network connectivity.
Audio
The audio system of the Newline TT-9823QA includes two built-in speakers with a power of 20 W, providing immersive sound quality for an enjoyable listening experience.
Connectivity
This model includes several connectivity options, including 3 HDMI ports, 1 DisplayPort, and 1 USB Type-C port, allowing for easy connection to various devices. Additionally, it offers an RS-232 port for reliable serial communication.
Computer System
Running on the Android 13 operating system, the Newline TT-9823QA is equipped with an octa-core processor and 8 GB of RAM, ensuring smooth performance and efficient multitasking management.
Projector
This model also integrates a projector, providing an all-in-one solution for your projection needs.
Packaging Contents
The Newline TT-9823QA comes with two styluses, allowing for optimal use right out of the box.
Representation / Implementation
The product includes a memory card reader compatible with SD cards, facilitating the storage and management of your data.
