Manual of product DS328
Technical Specifications DS328
General Information
-
ModelDS328
-
Brand
-
Category
-
Type
-
SKU60291
-
MPN60291
Projector
-
Projector brightness2800 ANSI lumens
-
Projection technologyDLP
-
Native resolution of the projectorSVGA (800x600)
-
Compatible screen size27.24 - 300.04 "
-
Image format4:3
-
Supported aspect ratios4:3, 16:9
-
Projection distance1.2 - 12 m
-
Contrast ratio13000:1
-
Number of colors1.073 billion colors
-
Uniformity85 %
-
Correction of the trapezium, vertical-40 - 40 °
-
Matrix size0.55 "
-
Vertical scanning frequency24 - 85 Hz
-
Horizontal scanning domain15.3 - 91.1 kHz
Objective system
-
Zoom ratio1.1:1
-
Zoom capacityYes
-
Focal length21.95 - 24.18 mm
-
Opening range2.51 - 2.69
-
Shift115 %
-
Projection ratio1.97 - 2.17:1
-
Zoom typeManual
Other features
-
Resolution (maximum analog)1600 x 1200 pixels
-
RS-232 port1
Light source
-
Lifespan of the light source- h
-
Power of the lamp190 W
-
Lifespan of the light source (eco mode)6500 h
-
Quantity of lamps1 lamp(s)
-
Type of light sourceLamp
Video
-
Analog signal format systemNTSC
-
Full HDNTSC 3.58
-
3D CompatibilityNTSC 4.43
-
Supported graphic resolutionsNTSC M
-
Supported video modesPAL
-
PAL B
-
PAL D
-
PAL G
-
PAL H
-
PAL I
-
PAL M
-
PAL N
-
SECAM
-
SECAM B
-
SECAM D
-
SECAM G
-
SECAM K
-
SECAM K1
-
SECAM L
-
No
-
Yes
-
1024 x 768 (XGA)
-
1280 x 1024 (SXGA)
-
1600 x 1200 (UXGA)
-
640 x 480 (VGA)
-
800 x 600 (SVGA)
-
1080i
-
480i
-
480p
-
576i
-
576p
-
720p
Multimedia
-
Built-in speakersYes
-
Rated power of RMS2 W
Screen
-
Built-in screen-
Connectivity
-
Number of VGA (D-Sub) ports3
-
Input component of the audiovisual device (YPbPr/YCbCr)0
-
S-Video Input1
-
S-Video Input1
-
Input component of the audiovisual device (YPbPr/YCbCr)0
-
S-Video Input1
-
Power entry sectorYes
-
S-Video Input1
-
Input component of the audiovisual device (YPbPr/YCbCr)0
-
DVI PortNo
-
Power entry sectorYes
-
Serial interface typeRS-232
Network
-
Wifi-
-
Number of Ethernet LAN ports (RJ-45)0
-
Ethernet/LANNo
Storage support
-
Built-in memory card readerNo
Features
-
Sound level- dB
-
Sound level (economy mode)26 dB
-
HDCPNo
-
Predefined modesCinema, Custom, Game, sRGB
-
On-Screen Display (OSD)Yes
-
Multilingual display on screenARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUM, RUS, SWE, TUR
Design
-
Product type-
-
Product colorBlack
-
Cable anti-theft lockYes
-
Cable lock location typeKensington
-
PositioningCeiling
Packaging contents
-
3D glasses includedNo
-
Warranty cardYes
-
Cables includedVGA
-
Warranty cardYes
-
Warranty cardYes
-
Warranty cardYes
Power
-
Power supplySector
-
Typical electricity consumption226 W
-
Energy consumption (standby mode)0.5 W
-
AC input voltage100 - 240 V
-
AC input frequency50 - 60 Hz
Weight and dimensions
-
Weight2210 g
-
Width316 mm
-
Depth224 mm
-
Height124 mm
Environmental conditions
-
Operating temperature5 - 40 °C
-
Operating altitude0 - 3000 m
Technical details
-
Sustainability certificatesRoHS
Similar products
More product categories from brand Optoma
More product types from brand Optoma
Presentation of product DS328 specifications from brand Optoma
Other features
The RS-232 port of the Optoma DS328 contains 1. This port is essential for ensuring reliable serial communication with other devices. The maximum analog resolution of the product Optoma DS328 is 1600 x 1200 pixels. This feature ensures optimal image quality for an enriching visual experience.
Generalities
The brand of the product Optoma DS328 is Optoma. This brand is known for its quality and innovation in the field of household appliances. The product model Optoma DS328 is DS328 | DS328. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Optoma DS328 is 5060059047338. This code allows for the unique identification of the product in the distribution system.
Objective system
The opening amplitude of the product Optoma DS328 is 2.51 - 2.69. This amplitude allows for optimal results in various lighting conditions. The zoom ratio of the product Optoma DS328 is fixed. This ratio determines the lens's ability to enlarge or reduce the image while maintaining optimal image quality. Does the product Optoma DS328 have zoom capacity? Oui. This feature allows you to capture precise details, even from a distance. The focal length of the product Optoma DS328 is 21.95 - 24.18 mm. This specification determines the field of view and the distance at which subjects can be captured accurately. The offset of the product Optoma DS328 is 115 %. This offset helps to optimize the performance and accuracy of the objective. The projection ratio of the product Optoma DS328 is 1.97 - 2.17:1. This ratio determines the distance at which the projected image will be displayed relative to the screen size. The zoom type of the product Optoma DS328 is Manuel. This type of zoom allows for precise and customized handling to suit your photographic needs.
Light source
The lifespan of the light source of the product Optoma DS328 is - h. This feature ensures prolonged and efficient use, allowing you to enjoy lasting lighting. The power of the lamp of the product Optoma DS328 is 190 W. This power ensures optimal lighting for your needs. The lifespan of the light source (eco mode) of the product Optoma DS328 is 6500 h. This longevity ensures prolonged and economical use. The quantity of lamps for the product Optoma DS328 is 1 lampe(s). This product offers an efficient lighting solution tailored to your needs. The type of light source of the product Optoma DS328 is Lampe. This light source ensures effective illumination tailored to your needs.
Video
The supported graphic resolutions of the product Optoma DS328 are 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA). These resolutions provide optimal display quality for your content. Does the product Optoma DS328 have 3D Compatibility? No. This product does not support 3D technology. Does the product Optoma DS328 have Full HD? Non. This feature ensures exceptional image quality for an immersive viewing experience. The analog signal format system of the product Optoma DS328 contains NTSC, NTSC 3.58, NTSC 4.43, NTSC M, PAL, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L. This system ensures compatibility with various broadcasting formats, thus providing an optimal viewing experience. The supported video mode of the product Optoma DS328 is 1080i, 480i, 480p, 576i, 576p, 720p. This mode allows you to enjoy optimal image quality for your videos.
Projector
The projector Optoma DS328 features a DLP projection technology. This technology ensures optimal image quality and an immersive visual experience. The brightness of the product Optoma DS328 is 2800 ANSI lumens. This feature ensures a clear and bright projection, even in well-lit environments. The native resolution of the product Optoma DS328 is SVGA (800x600). This feature ensures optimal image quality for your presentations and entertainment. The compatible screen size of the product Optoma DS328 is 27.24 - 300.04 ". This specification allows the projector to adapt to different screen formats for an optimal viewing experience. The image format of the product Optoma DS328 is 4:3. This format is ideal for an immersive visual experience. The aspect ratio of the product Optoma DS328 supports 4:3, 16:9. This aspect ratio allows for display flexibility suited to different content. The number of colors of the product Optoma DS328 is 1,073 milliards de couleurs. This wide range of colors allows for the creation of varied and immersive atmospheres. The projection distance of the product Optoma DS328 is 1.2 - 12 m. This specification allows for optimizing the visual experience based on the available space. The contrast ratio of the product Optoma DS328 is 13000:1. A high contrast ratio makes images sharper and colors more vibrant, thus providing an enhanced visual experience. The uniformity of the product Optoma DS328 is 85 %. This uniformity ensures a homogeneous distribution of light, thus providing an optimal visual experience. The product Optoma DS328 features trapezoidal correction, vertical of -40 - 40 °. This functionality allows for adjusting the projected image for optimal rendering, regardless of the projection angle. The matrix size of the product Optoma DS328 is 0.55 ". This specification is essential to ensure optimal image quality. The vertical scanning frequency of the product Optoma DS328 is 24 - 85 Hz. This specification ensures optimal display smoothness for a pleasant visual experience. The horizontal scanning range of the product Optoma DS328 is 15.3 - 91.1 kHz. This range allows for excellent display quality and optimal image smoothness.
Screen
The Optoma DS328 has a built-in screen. This screen provides an immersive and convenient visual experience, making it easier to use the device.
Multimedia
The RMS rated power of the product Optoma DS328 is 2 W. This specification ensures optimal sound quality for an enriching multimedia experience. Does the product Optoma DS328 have built-in speakers? Oui. These speakers provide an immersive and convenient audio experience.
Network
The number of Ethernet LAN (RJ-45) ports of the product Optoma DS328 is 0. These ports provide a stable and fast network connection for your devices. The Wifi of the product Optoma DS328 contains -. This Wifi allows for a fast and reliable wireless connection for all your devices. Does the product Optoma DS328 have Ethernet/LAN? Non. This specification determines the network connectivity of the product.
Storage support
Does the Optoma DS328 have a built-in memory card reader? Non. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution.
Features
Does the product Optoma DS328 have HDCP? Non. This specification ensures the protection of digital content against unauthorized copying. The noise level in eco mode of the product Optoma DS328 is 26 dB. This noise level ensures discreet and pleasant use, ideal for noise-sensitive environments. The noise level of the product Optoma DS328 is - dB. This noise level allows for pleasant use without excessive noise disturbances. The predefined modes of the product Optoma DS328 are Cinema, Custom, Game, sRGB. These modes allow for optimizing the display according to the desired use, whether for cinema, gaming, presentations, or standard use. Does the product Optoma DS328 have an on-screen display (OSD)? Oui. This display allows for intuitive navigation through the product settings. The multilingual display on the Optoma DS328 screen contains ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUM, RUS, SWE, TUR. This system allows users to easily navigate in multiple languages, making the experience more accessible and user-friendly.
Connectivity
The number of VGA (D-Sub) ports on the Optoma DS328 is 3. This port allows for easy connection with various devices and monitors. The number of HDMI ports on the Optoma DS328 is 0. This detail is essential for determining compatibility with your multimedia devices. The number of USB 2.0 ports on the Optoma DS328 is 1. These ports allow for a fast and efficient connection for your devices. The product Optoma DS328 has a composite video input. This input allows for easy connection of analog video devices for an optimal viewing experience. The integrated audio connector (L,R) of the product Optoma DS328 has 0. This connector allows for a high-quality stereo audio connection for an optimal sound experience. The headphone output of the Optoma DS328 is %. This output allows for easy connection of headphones or a headset for an optimal audio experience. Does the product Optoma DS328 have a microphone jack input? No. This feature means that the product does not allow connecting a microphone via a jack. The product Optoma DS328 has an S-Video input. This input allows you to connect video devices with enhanced image quality. The product Optoma DS328 has an input component of the audiovisual device (YPbPr/YCbCr) 0. This specification allows for a high-quality connection for an optimal visual experience. Does the product Optoma DS328 have a DVI Port? Non. This port allows you to connect devices with a digital video interface, ensuring optimal image quality. Does the product Optoma DS328 have a power input section? Oui. This section ensures a reliable and efficient power supply for the optimal operation of the device. The serial interface type of the product Optoma DS328 is RS-232. This type of interface allows for effective communication between different devices.
Design
The product type of Optoma DS328 is -. This product is ideal for an immersive and comfortable audio experience. The color of the product Optoma DS328 is Noir. This shade gives it a modern and elegant look. Does the product Optoma DS328 have a cable lock port? No. This product does not have this security feature. The type of cable lock location for the product Optoma DS328 is Kensington. This type of lock provides optimal security to protect your device against theft. The positioning of the product Optoma DS328 is Plafond. This positioning allows for optimizing its use and ensuring an optimal user experience.
Packaging contents
Does the product Optoma DS328 come with 3D Glasses included? Non. These glasses allow you to enjoy an immersive and captivating experience. Does the product Optoma DS328 come with a remote control? Oui. Does the product Optoma DS328 have a Quick Start Guide? Yes. This guide allows you to quickly and easily start using the product. The included cable of the product Optoma DS328 contains a power plug. This cable is essential for ensuring an optimal electrical connection. Does the product Optoma DS328 have a User Manual? Oui. This document provides clear instructions for optimal use of the product. Does the product Optoma DS328 have a warranty card? Oui. This card allows you to benefit from additional protection for your purchase.
Weight and dimensions
The weight of the product Optoma DS328 is 2210 g. This weight is ideal for ensuring optimal use and easy handling. The depth of the product Optoma DS328 is 224 mm. This dimension allows for optimal integration into your space. The height of the product Optoma DS328 is 124 mm. This dimension is essential to ensure that the product fits perfectly in your space. The width of the product Optoma DS328 is 316 mm. This dimension is essential to ensure optimal integration into your space.
Power
The power supply of the product Optoma DS328 is Secteur. This power supply ensures optimal autonomy for prolonged use. The energy consumption in standby mode of the product Optoma DS328 is 0.5 W. This feature helps reduce electricity consumption when the device is not in use, thus contributing to energy savings. The AC input voltage of the Optoma DS328 is 100 - 240 V. This specification ensures optimal compatibility with standard electrical systems. The typical power consumption of the product Optoma DS328 is 226 W. This feature allows for the assessment of the energy efficiency of the device. The AC input frequency of the product Optoma DS328 is 50 - 60 Hz. This specification is essential to ensure optimal operation and compatibility with electrical systems.
Environmental conditions
The operating altitude of the product Optoma DS328 is 0 - 3000 m. This specification ensures optimal performance across a wide range of altitudes. The operating temperature of the product Optoma DS328 is 5 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments.
Technical details
The product Optoma DS328 has Sustainability Certificates: RoHS. These certificates ensure that the product meets high standards for energy efficiency and environmental respect.
