Manual of product DX319
Technical Specifications DX319
General Information
-
ModelDX319
-
Brand
-
Category
-
Type
-
SKU146514
-
MPN146514
Projector
-
Projector brightness2500 ANSI lumens
-
Projection technologyDLP
-
Native resolution of the projectorXGA (1024x768)
-
Matrix size0.55 "
-
Contrast ratio2500:1
-
Compatible screen size0.7 - 7.70 "
-
Uniformity80 %
-
Correction of the trapezium, vertical± 40 °
-
Vertical scanning frequency24 - 85 Hz
-
Horizontal scanning domain15.3 - 91.1 kHz
-
Projection distance1.2/12 m
Other features
-
Image format4:3, 16:9
-
Lens focal length2.41 - 2.55
-
RS-232 port1
-
Dimensions (LxWxH)286 x 192 x 84 mm
-
CompatibilityUXGA, SXGA, XGA, SVGA, VGA, Mac
-
Power requirements100-240V, 50-60Hz
Objective system
-
Projection ratio1.95 - 2.15:1
-
Focal length21.8 - 24 mm
Light source
-
Lifespan of the light source3000 h
-
Power of the lamp185 W
-
Lifespan of the light source (eco mode)4000 h
-
Type of light sourceLamp
Multimedia
-
Number of built-in speakers1
-
Rated power of RMS2 W
Connectivity
-
Input component of the audiovisual device (YPbPr/YCbCr)1
-
Input component of the audiovisual device (YPbPr/YCbCr)1
-
Input component of the audiovisual device (YPbPr/YCbCr)1
-
Serial interface typeRS-232
Weight and dimensions
-
Weight2300 g
Power
-
Typical electricity consumption233 W
-
Energy consumption (standby mode)1 W
Environmental conditions
-
Operating relative humidity (H-H)0 - 85 %
-
Operating temperature
-
5 - 40 °C
Design
-
PositioningCeiling
Similar products
More product categories from brand Optoma
More product types from brand Optoma
Presentation of product DX319 specifications from brand Optoma
Generalities
The brand of the product Optoma DX319 is Optoma. This brand is known for its quality and innovation in the field of household appliances. The product model Optoma DX319 is DX319 | DX319. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Optoma DX319 is 5052217063175, 8434072773487. This code allows for the unique identification of the product in the distribution system.
Objective system
The projection ratio of the product Optoma DX319 is 1.95 - 2.15:1. This ratio determines the distance at which the projected image will be displayed relative to the screen size. The focal length of the product Optoma DX319 is 21.8 - 24 mm. This specification determines the field of view and the distance at which subjects can be captured accurately.
Projector
The brightness of the product Optoma DX319 is 2500 ANSI lumens. This feature ensures a clear and bright projection, even in well-lit environments. The matrix size of the product Optoma DX319 is 0.55 ". This specification is essential to ensure optimal image quality. The projector Optoma DX319 features a DLP projection technology. This technology ensures optimal image quality and an immersive visual experience. The native resolution of the product Optoma DX319 is XGA (1024x768). This feature ensures optimal image quality for your presentations and entertainment. The contrast ratio of the product Optoma DX319 is 2500:1. A high contrast ratio makes images sharper and colors more vibrant, thus providing an enhanced visual experience. The compatible screen size of the product Optoma DX319 is 0.7 - 7.70 ". This specification allows the projector to adapt to different screen formats for an optimal viewing experience. The horizontal scanning range of the product Optoma DX319 is 15.3 - 91.1 kHz. This range allows for excellent display quality and optimal image smoothness. The product Optoma DX319 features trapezoidal correction, vertical of ± 40 °. This functionality allows for adjusting the projected image for optimal rendering, regardless of the projection angle. The vertical scanning frequency of the product Optoma DX319 is 24 - 85 Hz. This specification ensures optimal display smoothness for a pleasant visual experience. The projection distance of the product Optoma DX319 is 1.2/12 m. This specification allows for optimizing the visual experience based on the available space. The uniformity of the product Optoma DX319 is 80 %. This uniformity ensures a homogeneous distribution of light, thus providing an optimal visual experience.
Light source
The type of light source of the product Optoma DX319 is Lampe. This light source ensures effective illumination tailored to your needs. The power of the lamp of the product Optoma DX319 is 185 W. This power ensures optimal lighting for your needs. The lifespan of the light source (eco mode) of the product Optoma DX319 is 4000 h. This longevity ensures prolonged and economical use. The lifespan of the light source of the product Optoma DX319 is 3000 h. This feature ensures prolonged and efficient use, allowing you to enjoy lasting lighting.
Other features
The image format of the product Optoma DX319 is 4:3, 16:9. This format is ideal for an immersive visual experience. The focal length of the Optoma DX319 lens is 2.41 - 2.55. This feature allows for images with a depth of field suited to your photographic needs. The dimensions (LxWxH) of the product Optoma DX319 are 286 x 192 x 84 mm. These dimensions ensure an optimal fit in your space. The RS-232 port of the Optoma DX319 contains 1. This port is essential for ensuring reliable serial communication with other devices. The compatibility of the product Optoma DX319 is UXGA, SXGA, XGA, SVGA, VGA, Mac. This product is designed to work with a variety of devices, ensuring optimal use. The power requirements of the product Optoma DX319 are 100-240V, 50-60Hz. These requirements ensure optimal operation of the device.
Multimedia
The RMS rated power of the product Optoma DX319 is 2 W. This specification ensures optimal sound quality for an enriching multimedia experience. The number of built-in speakers of the product Optoma DX319 is 1. These speakers provide immersive audio quality for an optimal listening experience.
Weight and dimensions
The weight of the product Optoma DX319 is 2300 g. This weight is ideal for ensuring optimal use and easy handling.
Power
The energy consumption in standby mode of the product Optoma DX319 is 1 W. This feature helps reduce electricity consumption when the device is not in use, thus contributing to energy savings. The typical power consumption of the product Optoma DX319 is 233 W. This feature allows for the assessment of the energy efficiency of the device.
Connectivity
The product Optoma DX319 has an S-Video input. This input allows you to connect video devices with enhanced image quality. The serial interface type of the product Optoma DX319 is RS-232. This type of interface allows for effective communication between different devices. The product Optoma DX319 has an input component of the audiovisual device (YPbPr/YCbCr) 1. This specification allows for a high-quality connection for an optimal visual experience. The product Optoma DX319 has a composite video input. This input allows for easy connection of analog video devices for an optimal viewing experience.
Design
The positioning of the product Optoma DX319 is Plafond. This positioning allows for optimizing its use and ensuring an optimal user experience.
Environmental conditions
The product Optoma DX319 has an operating relative humidity (H-H) of 0 - 85 %. This specification ensures optimal operation in a wide range of ambient humidity. The operating temperature of the product Optoma DX319 is 5 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments.
