Thumbnail of product TS-432XU-RP from brand QNAP
Logo of brand QNAP

Server QNAP TS-432XU-RP

QNAP
Computers and accessories
Server

The TS-432XU-RP is a product in the category Computers and accessories, specifically of type Server. We have listed 2 manuals of types User Manual, Technical Sheet for product Server QNAP TS-432XU-RP. We have also listed 75 specifications for product Server QNAP TS-432XU-RP. Have a question about product QNAP TS-432XU-RP and can't find the answer in the manual(s)? Do not hesitate to contact us.

Manuals of product TS-432XU-RP

First page image of the manual for TS-432XU-RP

User Manual
751 pages
View manual
First page image of the manual for TS-432XU-RP

Technical Sheet
9 pages
View manual

Technical Specifications TS-432XU-RP

General Information

Storage support

  • Storage unit interface
    -
  • Hot-swappable drive bays
    -
  • Total capacity of installed storage
    0 To
  • Type of installed storage drive
    No
  • Type of installed storage drive
    No
  • Number of installed storage readers
    0
  • Supported storage drive types
    HDD & SSD
  • Number of supported storage units
    4
  • Supported storage reader interfaces
    SATA III
  • Storage reader capacity
    - Go
  • Storage unit size
    - "
  • Online RAID expansion
    Yes
  • RAID Levels
    0, 1.5, 6, 10, JBOD
  • Online RAID expansion
    Yes
  • Online RAID expansion
    Yes
  • Supported file systems
    FAT32, HFS+, NTFS, ext3, ext4

Representation / realization

  • Image capture
    Yes
  • Type
    NAS
  • Device class
    SME
  • Image capture
    Yes
  • Backup functions
    iSCSI LUN
  • Image capture
    Yes
  • Security-supported algorithm
    256-bit AES
  • Supported browsers
    Apple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox

Software

  • Support for the Mac operating system
    Yes
  • Support for the Mac operating system
    Yes
  • Support for the Mac operating system
    Yes
  • Support for the Mac operating system
    Yes
  • Support for the server operating system
    Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
  • Installed operating system
    QNAP Turbo System
  • Operating system version
    4.3.4

Power

  • Power location
    Integrated
  • Number of power supplies
    2
  • AC input voltage
    100 - 240 V
  • AC input frequency
    50 - 60 Hz
  • Fan tension
    12 V

Processor

  • Processor model
    Alpine AL-324
  • Processor family
    Annapurna Labs
  • Processor frequency
    1.7 GHz
  • Number of processor cores
    4

Weight and dimensions

  • Width
    439 mm
  • Depth
    499 mm
  • Height
    44 mm

Memory

  • Type of internal memory
    DDR4
  • Internal memory
    2 GB
  • Maximum supported RAM
    16 GB
  • Memory locations
    1 x SODIMM

Network

  • Dynamic DNS (DDNS)
    Yes
  • Supported Ethernet LAN transmission speed (max.)
    10000 Mbit/s
  • Supported Ethernet LAN transmission speed (max.)
    10000 Mbit/s
  • Wifi
    No
  • Dynamic DNS (DDNS)
    Yes
  • Dynamic DNS (DDNS)
    Yes
  • Dynamic DNS (DDNS)
    Yes
  • Dynamic DNS (DDNS)
    Yes

Connectivity

  • Fibre Channel Ports
    2
  • USB port
    Yes
  • Quantity of USB 2.0 Ports
    0
  • Number of USB 3.2 Gen 1 (3.1 Gen 1) type A ports
    4
  • Fibre Channel Ports
    2
  • Fiber optic connector
    SFP+

Design

  • Chassis type
    Rack (1 U)
  • Cooling type
    Active
  • Product color
    Black
  • Number of fans
    2 fan(s)
  • Fan diameter
    40 mm

Environmental conditions

  • Operating temperature
    0 - 40 °C
  • Operating relative humidity (H-H)
    5 - 95 %

Logistics data

  • Harmonized System Code
    84714100
