Laptop Samsung Series 7 Chronos NP700Z5CH

Samsung
Computers and accessories
Laptop

The Samsung Series 7 Chronos NP700Z5CH is a high-performance laptop designed to meet the needs of demanding users. Equipped with an Intel® Core™ i7-3635QM processor running at 2.4 GHz, it offers optimal processing power with its 4 cores and 8 threads, allowing for smooth multitasking.

This model features 8 Go DDR3 of RAM, ensuring efficient application usage. With a hybrid storage of 750 Go, it provides ample capacity for your documents, photos, and videos, while offering fast access speeds thanks to its SATA II interface.

The 15.6-inch screen with a resolution of 1600 x 900 pixels and LED backlighting delivers a pleasant display quality, ideal for work and entertainment. The integrated Intel® HD Graphics 4000 and dedicated NVIDIA® GeForce® GT 640M graphics cards handle multimedia applications and games with ease.

Connectivity is also a strong point of this laptop, with options such as Wi-Fi, Bluetooth 4.0, and several USB ports, including an HDMI port for connecting to other devices. The stereo audio system and the 1.3 MP webcam enhance the overall multimedia experience.

Finally, the Samsung Series 7 Chronos NP700Z5CH is powered by an 80 Wh battery, providing extended battery life for on-the-go use. With its sleek silver design, this laptop combines performance and style, making it ideal for professionals on the move.

Manual of product Series 7 Chronos NP700Z5CH

First page image of the manual for Series 7 Chronos NP700Z5CH

User Manual
156 pages
View manual
7 10

Editorial note

The Samsung Series 7 Chronos NP700Z5CH stands out for its powerful performance, thanks to its Intel® Core™ i7 processor that ensures smooth execution of multitasking and demanding applications. Intel® Turbo Boost and Hyper Threading technology also contribute to optimal responsiveness when running multiple programs simultaneously. The 15.6-inch screen, with a HD+ resolution of 1600 x 900 pixels, offers pleasant display quality, although some users may desire a Full HD resolution for a more immersive visual experience. The 750 GB hybrid storage capacity allows for a combination of speed and sufficient space to store files and applications, thus optimizing overall performance. However, the weight of 2400 g may make this laptop impractical to carry, especially for users who are often on the go. Additionally, the lack of USB 3.0 ports and other modern connectivity options like Thunderbolt limits expansion and connectivity options, which can be a drawback for some users. Finally, the battery not having a specified autonomy raises questions about its lifespan during prolonged use without access to a power source. Overall, the Samsung Series 7 Chronos NP700Z5CH is a laptop offering good performance and a pleasant user experience, but it could benefit from some improvements in connectivity and portability.

Score details

Performance

Powerful performance thanks to an Intel® Core™ i7 processor allows for smooth execution of multitasking and demanding applications.

display

The 15.6-inch screen with a HD+ resolution of 1600 x 900 pixels offers pleasant display quality, but may seem insufficient for users seeking Full HD quality.

storage

The hybrid storage capacity of 750 GB combines speed and sufficient space to store files and applications, thus optimizing performance.

Features

Intel® Turbo Boost and Hyper-Threading technology enhance system responsiveness and efficiency when running multiple programs simultaneously.

Usability

Advanced wireless connectivity with Wi-Fi and Bluetooth allows for easy and fast connection, but the lack of USB 3.0 ports and other modern connectivity limits expansion options.

weight

The weight of 2400 g may make the laptop impractical to carry, especially for users who travel frequently.

Battery life

The battery does not have a specified runtime, which may raise questions about its lifespan during prolonged use without access to a power source.

Value for money

The maximum storage capacity is not specified, which could limit users needing more space for their data.

Advantages

Powerful Intel® Core™ i7 processor

Pleasant 15.6-inch HD+ display

750 GB hybrid storage

Turbo Boost and Hyper Threading technology

Advanced Wi-Fi and Bluetooth connectivity

Disadvantages

Heavy weight, impractical to transport.

Maximum storage capacity not specified.

Insufficient screen resolution for Full HD.

Absence of modern USB 3.0 ports.

Battery life not specified.

Technical Specifications Series 7 Chronos NP700Z5CH

General Information

Processor

  • Processor frequency
    2.4 GHz
  • Processor family
    Intel® Core™ i7
  • Processor model
    i7-3635QM
  • Processor Turbo Frequency
    3.4 GHz
  • Number of processor cores
    4
  • Number of processor threads
    8
  • Computer bus
    5 GT/s
  • Processor cache type
    Smart Cache
  • Processor cache memory
    6 Mo
  • Bus type
    DMI
  • ECC supported by the processor
    Non
  • Processor socket (processor receptacle)
    BGA 1224
  • Processor lithography
    22 nm
  • Processor operating modes
    64-bit
  • Processor code name
    Ivy Bridge
  • Thermal envelope (TDP, Thermal Design Power)
    35 W
  • Maximum number of PCI Express lanes
    16
  • Version of PCI Express locations
    3.0
  • PCI Express Configurations
    1x16, 1x8, 2x4, 2x8
  • Tjunction
    105 °C
  • Processor series
    Intel Core i7-3600 Mobile series
  • Processor manufacturer
    Intel
  • Processor generation
    Intel® Core™ i7 3rd generation

Representation / realization

  • Motherboard chipset
    Intel HM76 Express

Memory

  • Internal memory
    8 GB
  • Type of internal memory
    DDR3-SDRAM
  • Memory frequency
    1600 MHz
  • Memory configuration (slot x size)
    1 x 4 GB
  • Memory locations
    1x SO-DIMM
  • Maximum internal memory
    - GB
  • Memory support
    Integrated + SO-DIMM

Storage support

  • Hybrid hard drive capacity (H-HDD)
    750 GB
  • Storage media
    Hybrid HDD
  • Hard drive interface
    SATA II
  • Hard disk rotation speed
    5400 RPM
  • Hybrid hard drive capacity (H-HDD)
    750 GB
  • Hybrid hard drive cache memory (H-HDD)
    16 GB
  • Built-in memory card reader
    Yes
  • Compatible memory cards
    MMC, SD, SDHC, SDXC
  • Optical reader
    DVD Super Multi DL

Screen

  • Screen size
    15.6 "
  • Screen resolution
    1600 x 900 pixels
  • Touch screen
    No
  • LED backlighting
    Yes
  • Image format
    16:9
  • Screen brightness
    300 cd/m²
  • Type HD
    HD+

Graphique

  • Graphics adapter model included
    Intel® HD Graphics 4000
  • Distinct graphics adapter model
    NVIDIA® GeForce® GT 640M
  • Type of graphics card
    GDDR5
  • Dedicated graphics card adapter
    Yes
  • Dedicated graphics card adapter
    Yes
  • Integrated graphics adapter family
    Intel® HD Graphics
  • Base frequency of integrated graphics card
    650 MHz
  • Dynamic frequency (max) of integrated graphics card
    1200 MHz
  • ID of the integrated graphics card
    0x166

Other features

  • LightScribe
    -
  • Power adapter included
    Yes

Audio

  • Audio system
    SoundAlive
  • Number of built-in speakers
    2
  • Speaker power
    2 W
  • Built-in microphone
    Yes
  • Built-in microphone
    Yes

Camera

  • Front camera resolution (digital)
    1.3 MP

Network

  • Ethernet/LAN
    Yes
  • Ethernet/LAN
    Yes
  • Wifi standards
    802.11a, 802.11b, 802.11g
  • Ethernet/LAN
    Yes
  • LAN Ethernet: data transfer rate
    10,100,1000 Mbit/s
  • Bluetooth model
    4.0
  • Wiring technology
    10/100/1000Base-T(X)
  • Network standards
    IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Connectivity

  • Number of Ethernet LAN ports (RJ-45)
    1
  • Number of USB 3.2 Gen 1 (3.1 Gen 1) type A ports
    2
  • Number of CardBus PCMCIA Housing(s)
    0
  • Number of CardBus PCMCIA Housing(s)
    0
  • Number of CardBus PCMCIA Housing(s)
    0
  • Number of CardBus PCMCIA Housing(s)
    0
  • Number of Ethernet LAN ports (RJ-45)
    1
  • Number of CardBus PCMCIA Housing(s)
    0
  • SmartCard Housing
    No
  • Number of Ethernet LAN ports (RJ-45)
    1
  • Number of CardBus PCMCIA Housing(s)
    0
  • Number of CardBus PCMCIA Housing(s)
    0
  • Number of CardBus PCMCIA Housing(s)
    0
  • SmartCard Housing
    No
  • SmartCard Housing
    No
  • Headset / microphone port
    Yes
  • SmartCard Housing
    No
  • SmartCard Housing
    No
  • Number of CardBus PCMCIA Housing(s)
    0
  • SmartCard Housing
    No
  • SmartCard Housing
    No
  • Charging port type
    DC-in jack

Keyboard

  • Keyboard layout
    -
  • Pointing device
    Touchpad
  • Numeric keypad
    Yes

Software

  • Operating System Architecture
    -
  • Installed operating system
    Windows 8
  • Drivers included
    Yes

Design

  • Product type
    Laptop
  • Product color
    Money
  • Format
    Flap

Special features of the processor

  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Intel® Turbo Boost Technology
    2.0
  • The available built-in options
    No
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • The available built-in options
    No
  • Thermal surveillance technologies
    Yes
  • The available built-in options
    No
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • CPU Configuration (max)
    1
  • The available built-in options
    No
  • Graphic lithography and IMC
    22 nm
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Thermal surveillance technologies
    Yes
  • Processor packaging size
    31 x 24 mm
  • Supported instruction set
    AVX
  • Processor ID ARK
    71460

Battery

  • Number of battery cells
    8
  • Maximum battery life
    - h
  • Battery capacity
    80 Wh

Power

  • AC power adapter
    90 W

Security

  • Cable anti-theft lock
    Yes

Weight and dimensions

  • Weight
    2400 g
  • Width
    362.1 mm
  • Depth
    238.5 mm
  • Height
    23.9 mm

Packaging contents

  • Warranty card
    Yes
  • Warranty card
    Yes
  • Warranty card
    Yes

Frequently Asked Questions

What factors influence download speed on the Internet?
Download speed on the Internet is determined by the type of connection you are using. For example, if you have a 25 Mb/s connection, you should theoretically be able to download up to 25 MB per second.
What are the dimensions of my laptop screen?
The size of your laptop is generally indicated in inches, where 1 inch equals 2.54 centimeters. This size corresponds to the diagonal measurement of the screen, taken from the bottom left corner to the top right corner.
What does the acronym HDMI stand for?
HDMI stands for High-Definition Multimedia Interface. An HDMI cable allows for the transmission of audio and video signals between different devices.
What is the best method to clean my laptop?
To remove fingerprints, a slightly damp cleaning cloth or a soft, clean cloth is ideal. For hard-to-reach areas, it is advisable to use compressed air to eliminate dust.
How can I clean my keyboard?
Turn the keyboard upside down and use a can of compressed air to dislodge dirt. You can also clean the keys with a damp cloth.
What is Bluetooth?
Bluetooth allows for wireless data transmission between electronic devices via radio waves. Generally, the range of this connection can reach up to ten meters.
What is the weight of the Samsung Series 7 Chronos NP700Z5CH?
The weight of the Samsung Series 7 Chronos NP700Z5CH is 2400 g.
What is the screen size of the Samsung Series 7 Chronos NP700Z5CH?
The screen of the Samsung Series 7 Chronos NP700Z5CH measures 15.6 inches.
What is the height of the Samsung Series 7 Chronos NP700Z5CH?
The Samsung Series 7 Chronos NP700Z5CH measures 23.9 mm in height.
What is the resolution of the screen of the Samsung Series 7 Chronos NP700Z5CH?
The resolution of the screen of the Samsung Series 7 Chronos NP700Z5CH is 1600 x 900 pixels.
What is the width of the Samsung Series 7 Chronos NP700Z5CH?
The width of the Samsung Series 7 Chronos NP700Z5CH is 362.1 mm.
What is the depth of the Samsung Series 7 Chronos NP700Z5CH?
The Samsung Series 7 Chronos NP700Z5CH has a depth of 238.5 mm.
Is the manual for the Samsung Series 7 Chronos NP700Z5CH available in French?
Unfortunately, the manual for the Samsung Series 7 Chronos NP700Z5CH is not available in French. It is only offered in English.

Similar products

Samsung NP915S3G
1
Samsung Computers and accessories Laptop
Thumbnail of product Samsung NP915S3G
Discover the technical sheet of NP915S3G from Samsung and its manuals...
Available manuals:

Sony Vaio PCG-QR20
1
Sony Computers and accessories Laptop
Thumbnail of product Sony Vaio PCG-QR20
Discover the technical sheet of Vaio PCG-QR20 from Sony and its manuals...
Available manuals:

Sony Vaio VGN-FS295XP
1
Sony Computers and accessories Laptop
Thumbnail of product Sony Vaio VGN-FS295XP
Discover the technical sheet of Vaio VGN-FS295XP from Sony and its manuals...
Available manuals:

Sony Vaio VGN-CR29XN
1
Sony Computers and accessories Laptop
Thumbnail of product Sony Vaio VGN-CR29XN
Discover the technical sheet of Vaio VGN-CR29XN from Sony and its manuals...
Available manuals:

Sony Vaio VGN-FE39VP
1
Sony Computers and accessories Laptop
Thumbnail of product Sony Vaio VGN-FE39VP
Discover the technical sheet of Vaio VGN-FE39VP from Sony and its manuals...
Available manuals:

Samsung ATIV NP270E5G
1
Samsung Computers and accessories Laptop
Thumbnail of product Samsung ATIV NP270E5G
Discover the technical sheet of ATIV NP270E5G from Samsung and its manuals...
Available manuals:

Toshiba X500
1
Toshiba Computers and accessories Laptop
Thumbnail of product Toshiba X500
Discover the technical sheet of X500 from Toshiba and its manuals...
Available manuals:

Samsung ATIV NP870Z5G
1
Samsung Computers and accessories Laptop
Thumbnail of product Samsung ATIV NP870Z5G
Discover the technical sheet of ATIV NP870Z5G from Samsung and its manuals...
Available manuals:

Samsung ATIV NP915S3G
1
Samsung Computers and accessories Laptop
Thumbnail of product Samsung ATIV NP915S3G
Discover the technical sheet of ATIV NP915S3G from Samsung and its manuals...
Available manuals:

Samsung ATIV NP270E4E
1
Samsung Computers and accessories Laptop
Thumbnail of product Samsung ATIV NP270E4E
Discover the technical sheet of ATIV NP270E4E from Samsung and its manuals...
Available manuals:

Sony Vaio VGN-C2M
1
Sony Computers and accessories Laptop
Thumbnail of product Sony Vaio VGN-C2M
Discover the technical sheet of Vaio VGN-C2M from Sony and its manuals...
Available manuals:

Samsung 5 Series NP550P5C
1
Samsung Computers and accessories Laptop
Thumbnail of product Samsung 5 Series NP550P5C
Discover the technical sheet of 5 Series NP550P5C from Samsung and its manuals...
Available manuals:

More product categories from brand Samsung

More product types from brand Samsung

Presentation of product Series 7 Chronos NP700Z5CH specifications from brand Samsung

General Information

The Samsung Series 7 Chronos NP700Z5CH is a laptop from the Samsung brand, known for its innovation and quality in the technology sector. This model, identified by the reference NP700Z5C-S04CA, is designed to deliver optimal performance and an enriching user experience. The EAN code 0887276002309 allows for unique identification of this product in distribution systems.

Processor

Equipped with an Intel® Core™ i7-3635QM processor, the Samsung Series 7 Chronos NP700Z5CH features a base frequency of 2.4 GHz, with a Turbo mode reaching 3.4 GHz, ensuring smooth execution even for the most demanding tasks. With 4 cores and 8 threads, this processor is optimized for multitasking. Its 6 MB cache and 5 GT/s bus speed ensure rapid communication between components. The 22 nm lithography contributes to the energy efficiency and overall performance of the device.

Representation / Realization

The motherboard of the computer is equipped with an Intel HM76 Express chipset, providing efficient resource management for smooth operation.

Memory

The Samsung Series 7 Chronos NP700Z5CH integrates 8 GB of DDR3-SDRAM memory, operating at a frequency of 1600 MHz. This configuration ensures adequate performance for most common applications. The memory device is configured as 1 x 4 GB on a SO-DIMM slot, allowing for efficient resource utilization.

Storage

For storage, this computer offers a total capacity of 750 GB thanks to a hybrid hard drive (HDD) that combines the speed of an SSD with the space of a traditional disk. The SATA II interface ensures efficient data transfers, while the disk's rotation speed of 5400 RPM guarantees quick access to data. The Super Multi DL DVD optical drive also allows access to a variety of media.

Screen

The 15.6-inch screen with a resolution of 1600 x 900 pixels offers satisfactory display quality for multimedia content. It features LED backlighting for better visibility in different lighting environments. The 16:9 aspect ratio and a brightness of 300 cd/m² contribute to a pleasant visual experience.

Graphics

The Samsung Series 7 Chronos NP700Z5CH is equipped with integrated Intel® HD Graphics 4000 as well as a dedicated NVIDIA® GeForce® GT 640M graphics card, ensuring solid graphics performance for gaming and multimedia applications. The maximum dynamic frequency of the integrated graphics card reaches 1200 MHz, allowing for smooth image rendering.

Audio

This model features a stereo audio system with two built-in speakers, providing a power output of 2 W for an immersive sound experience. An integrated subwoofer enhances audio depth, while a built-in microphone allows for clear communications.

Network

The Samsung Series 7 Chronos NP700Z5CH is equipped with advanced connectivity options, including Bluetooth 4.0 and Wi-Fi compliant with 802.11a/b/g/n standards, ensuring fast and reliable connections. An Ethernet LAN port is also present for a stable network connection.

Connectivity

In terms of connectivity, this laptop offers an HDMI port for connection to external devices, as well as a USB 2.0 port. However, it does not have USB 3.0 ports or modern connectivity options such as Thunderbolt, which may limit expansion options.

Keyboard

The Samsung Series 7 Chronos NP700Z5CH is equipped with a touchpad for intuitive navigation. However, it does not include a numeric keypad, which may be a disadvantage for some users.

Battery

The 8-cell battery offers a capacity of 80 Wh, although no maximum autonomy is specified. This could raise questions about battery life during prolonged use.

Weight and Dimensions

Weighing 2400 g, this computer is relatively heavy, which may make it less convenient to carry. Its dimensions are 362.1 mm wide, 238.5 mm deep, and 23.9 mm high, making it suitable for desktop use.

Packaging Contents

The Samsung Series 7 Chronos NP700Z5CH comes with a user manual, a quick start guide, and a warranty card, allowing for easy handling and support after purchase.
