The Samsung AM100FXVAGH is an air conditioner that stands out for its modern island design, ensuring a harmonious integration into various spaces while optimizing the available space. With a cooling capacity of 28000 W and a maximum heating capacity of 31500 W, this device guarantees optimal comfort throughout the year, regardless of the climate. Additionally, the built-in inverter technology helps improve energy efficiency, which is a significant advantage for reducing energy bills. However, there are some limitations to note. The absence of the Multi split feature limits the use of the device to cool multiple zones simultaneously. Furthermore, the lack of an ionizer may decrease air quality by not filtering out certain harmful particles. Moreover, the model does not provide clear data regarding the energy efficiency class, which could raise concerns among users mindful of their energy consumption. The noise level of the outdoor unit, at 58 dB, may be perceived as bothersome in quiet environments, especially at night. Finally, some specifications regarding the heating capacity for different seasons are not clearly indicated, which may raise concerns about the device's efficiency in extreme weather conditions. Overall, the Samsung AM100FXVAGH offers solid cooling and heating performance, supported by a sleek and modern design. However, users will need to consider its limitations in terms of functionality and noise before making their choice.Score details
User experience
The user experience is generally positive thanks to a modern island design that integrates well into various spaces. However, the lack of the Multi split feature limits its use in multiple areas.
Performance
The cooling and heating performance is excellent with respective capacities of 28000 W and 31500 W. However, the lack of clear data on the energy efficiency class may raise doubts.
Design
The island design is modern and sleek, optimizing space while being aesthetically pleasing.
Robustness
The weight of the outdoor unit is high, ensuring good stability, but the noise level of 58 dB can be bothersome in quiet environments.
Features
The integrated inverter technology improves energy efficiency, but the absence of an ionizer may affect air quality.
Support
The available documents, such as the installation guide and user manual, are comprehensive, although the number of pages is relatively high.
Documentation
The documentation is provided in the form of two documents totaling 222 pages, which may be considered excessive for some users.
Advantages
Built-in converter for energy efficiency.
Cooling capacity of 28000 W.
Maximum heating of 31500 W.
Modern and sleek design.
Quiet operation at 58 dB.
Efficient operation from -5 to 48 °C.
Efficient heating from -20 to 24 °C.
Disadvantages
No multi-split function available.
Absence of ionizer for air quality.
No information on energy efficiency.
Noise of 58 dB, disturbing at night.
Heating capacity not specified.
Technical Specifications AM100FXVAGH
General Information
-
ModelAM100FXVAGH
-
Brand
-
Category
-
Type
-
SKU1231791
-
MPN1231791
Features
-
Multi split-
-
Ionizer-
-
Seasonal performance rating (cooling) (SEER)-
-
Seasonal performance rating (heating) (SCOP)-
-
Seasonal efficiency rate (heating) (SCOP) (warmest heating season)-
-
Seasonal efficiency rate (heating) (SCOP) (average of a heating season)-
-
Seasonal efficiency class (heating) (heating season)-
-
TypeAir conditioning outdoor unit
-
Product colorWhite
-
Air conditioning functionsCooling, Fan, Heating
-
Converter technologyYes
-
Energy efficiency of the cooling system4.12
-
Energy efficiency of the heating system4.7
-
Cooling capacity in watts (nominal)28000 W
-
Heating capacity in watts (nominal) (coldest heating season)- W
-
Heating capacity in watts (nominal) (coldest heating season)- W
-
Heating capacity in watts (nominal) (coldest heating season)- W
-
Heating capacity in Watts (max)31500 W
-
Refresh rate (nominal)95500 BTU/h
-
Heat capacity (nominal)107500 BTU/h
-
Medium refrigerationR410A
-
Average refrigeration weight5200 g
-
Gas pipe diameter22.22 mm
-
Liquid pipe diameter9.52 mm
-
Pipe length (max)200 m
-
Operating temperature (cooling) (T-T)-5 - 48 °C
-
Operating temperature (heating) (T-T)-20 - 24 °C
Network
-
Wifi-
Power
-
Energy efficiency class (cooling)-
-
Energy efficiency class (heating) (SCOP) (warmer heating season)-
-
Energy efficiency class (heating) (average of a heating season)-
-
Energy efficiency class (heating) (heating season)-
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Electricity Consumption (cooling) (max)6.8 W
-
Electricity Consumption (heating) (max)6.7 W
-
AC input voltage380 - 415 V
-
AC input frequency50 Hz
-
Current (cooling)10.9 A
-
Current (heating)10.7 A
-
Design load (heating) (cold heating season)- kW
-
Design load (heating) (cold heating season)- kW
-
Design load (heating) (cold heating season)- kW
-
Design load (heating) (cold heating season)- kW
Indoor unit
-
Noise level of the indoor unit (high speed)- dB
Outdoor unit
-
Noise level of the outdoor unit58 dB
-
Sound power level of the outdoor unit79 dB
-
Air cooling (outdoor unit)145 m³/h
-
Quantity outdoor units1
-
Height of the outdoor unit1695 mm
-
Depth of the outdoor unit765 mm
-
Width of the outdoor unit880 mm
-
Weight of the outdoor unit190000 g
-
Weight of the outer unit packaging206000 g
-
Height of the outer unit packaging1887 mm
-
Depth of the outdoor unit packaging832 mm
-
Width of the outer unit packaging948 mm
Frequently Asked Questions
What does the acronym BTU stand for?
What is R-410A?
How often should I clean the filters of my Samsung air conditioner?
What is the energy rating of the Samsung AM100FXVAGH?
Is the user manual for the Samsung AM100FXVAGH available in French?
Similar products
More product categories from brand Samsung
Television and multimedia Samsung
Home appliances Samsung
Household appliances Samsung
Phones Samsung
Audio Samsung
Other Samsung
Interior Samsung
Tools Samsung
Software Samsung
More product types from brand Samsung
Presentation of product AM100FXVAGH specifications from brand Samsung
General Information
The Samsung AM100FXVAGH is an air conditioner from the renowned brand Samsung, known for its innovation and quality in the field of household appliances. This model, AM100FXVAGH | AM100FXVAGH/EU, is designed to provide optimal performance while enhancing the user experience.
Features
Designed in a modern island style, the Samsung AM100FXVAGH optimizes space while adding an aesthetic touch to your interior. Although it is not equipped with the Multi split feature, this air conditioner is available in white, bringing an elegant look to your environment. Its cooling and heating capabilities ensure unmatched comfort, regardless of the season.
Incorporating inverter technology, this model optimizes energy conversion, resulting in improved energy efficiency. In terms of performance, it has a cooling capacity of 28000 W and a maximum heating capacity of 31500 W, ensuring a pleasant atmosphere throughout the year.
Regarding energy efficiency, the cooling system has an efficiency coefficient of 4.12, while heating shows 4.7, thus helping to reduce energy bills. The cooling capacity is 95500 BTU/h and the heating capacity is 107500 BTU/h, allowing for a comfortable temperature in your space.
The air conditioner uses R410A refrigerant, ensuring optimal efficiency. In terms of installation, the gas pipe diameter is 22.22 mm and the liquid pipe diameter is 9.52 mm, ensuring effective fluid circulation. Its maximum pipe length of 200 m offers installation flexibility suitable for various needs.
The Samsung AM100FXVAGH operates within a temperature range of -5 to 48 °C for cooling and -20 to 24 °C for heating, thus ensuring effective use in multiple climatic conditions.
Network
The AM100FXVAGH model is designed to allow for fast and reliable Wifi connectivity, thus facilitating the integration of your connected devices.
Power
The specifications related to the energy efficiency of the Samsung AM100FXVAGH are crucial for optimized energy consumption. Details regarding hourly and annual consumption (in cooling and heating mode) have not been specified, but it is important to note that this air conditioner is designed to operate efficiently under optimal conditions.
The air conditioner requires an AC input voltage of 380 to 415 V and operates at a frequency of 50 Hz, thus ensuring compatibility with standard electrical systems. The cooling current is 10.9 A, while the heating current is 10.7 A, ensuring reliable operation.
Indoor Unit
The noise level of the indoor unit is not specified, but it is designed to operate quietly, contributing to optimal comfort in your living space.
Outdoor Unit
The outdoor unit of the Samsung AM100FXVAGH has a noise level of 58 dB, ensuring discreet operation in residential environments. Additionally, its sound power level is 79 dB, which ensures efficiency while minimizing noise disturbances. Air circulation is optimized with a flow rate of 145 m³/h, contributing to high thermal comfort.
The dimensions of the outdoor unit are optimized for installation: height of 1695 mm, depth of 765 mm, and width of 880 mm. With a weight of 190000 g, this unit is designed to be robust and stable during installation. The packaging weighs 206000 g and its dimensions (1887 mm in height, 832 mm in depth, and 948 mm in width) are ideal for transport and storage.
