Manuals of product AM112JNCDKH
Editorial note
The Samsung AM112JNCDKH is an air conditioner that stands out for its modern and aesthetic design, as well as its optimized island-type installation. Its white color allows it to easily blend into various interior decors, bringing a contemporary touch to any space. With its cooling and heating functions, this device ensures optimal thermal comfort throughout the year, with capacities of 11,200 W for cooling and 12,500 W for heating. The user experience is generally positive, with an indoor noise level of only 37 dB, ensuring discreet operation, although some users may find the maximum level of 61 dB a bit high in noise-sensitive environments. The availability of useful documents, such as the user manual and installation guide, is an asset for users, facilitating the understanding and installation of the device. However, the Samsung AM112JNCDKH has some drawbacks. The absence of the Multi split function limits its ability to cool or heat multiple zones independently. Additionally, the lack of an ionizer may affect indoor air quality, and some specifications regarding energy efficiency are not provided, making the assessment of its energy performance more difficult. Finally, the weight of the indoor unit, which reaches 33.5 kg, can complicate installation and may require the assistance of a professional. Overall, the Samsung AM112JNCDKH air conditioner offers good value for money, with satisfactory cooling and heating performance, but it would be beneficial for the brand to provide additional information regarding its energy efficiency for a more comprehensive assessment.Score details
User experience
The user experience is positive due to a modern and aesthetic design, and an optimized installation that improves air circulation.
Performance
The cooling and heating performance is satisfactory with capacities of 11,200 W and 12,500 W, allowing for a pleasant climate.
Design
The design is modern and easily integrates into various interior decors, bringing a contemporary touch to any space.
Value for money
The value for money is good, although some specifications on energy efficiency are lacking, making the assessment more difficult.
Usability
The usage is generally easy, but the weight of the indoor unit can complicate installation without the help of a professional.
Support
The availability of documents such as the user manual and installation guide is an asset for users.
Documentation
The available documents are clear and helpful, providing precise instructions for effective use and installation.
Advantages
Modern and aesthetic design in white
Year-round comfort, hot and cold
Silent operation at 37 dB
High cooling and heating capacity
Convenient installation with efficient air circulation
Disadvantages
No multi-split function.
Absence of ionizer for air quality.
Missing information on energy efficiency.
High weight complicates installation.
High noise level of 61 dB.
Technical Specifications AM112JNCDKH
General Information
-
ModelAM112JNCDKH
-
Brand
-
Category
-
Type
-
SKU1347564
-
MPN1347564
Features
-
Multi split-
-
Converter technology-
-
Ionizer-
-
Seasonal performance rating (cooling) (SEER)-
-
Seasonal performance rating (heating) (SCOP)-
-
Seasonal efficiency rate (heating) (SCOP) (warmest heating season)-
-
Seasonal efficiency rate (heating) (SCOP) (average of a heating season)-
-
Seasonal efficiency class (heating) (heating season)-
-
TypeIndoor air conditioning unit
-
Product colorWhite
-
Air conditioning functionsCooling, Heating
-
Heating capacity in watts (nominal) (coldest heating season)- W
-
Cooling capacity in Watts (max)11200 W
-
Heating capacity in watts (nominal) (coldest heating season)- W
-
Heating capacity in watts (nominal) (coldest heating season)- W
-
Heating capacity in watts (nominal) (coldest heating season)- W
-
Heating capacity in Watts (max)12500 W
-
Refresh rate (nominal)38200 BTU/h
-
Heat capacity (nominal)42700 BTU/h
-
Medium refrigerationR410A
-
Gas pipe diameter15.88 mm
-
Liquid pipe diameter9.52 mm
-
Indicator lightYes
Power
-
Energy efficiency class (heating) (SCOP) (warmer heating season)-
-
Energy efficiency class (heating) (average of a heating season)-
-
Energy efficiency class (heating) (heating season)-
-
Energy efficiency class (cooling)A
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Annual energy consumption (heating) (coldest heating season)- kWh
-
Electricity Consumption (cooling) (max)92 W
-
Electricity Consumption (heating) (max)80 W
-
AC input voltage220-240 V
-
AC input frequency50 Hz
-
Current (cooling)0.94 A
-
Current (heating)0.83 A
-
Design load (heating) (cold heating season)- kW
-
Design load (heating) (cold heating season)- kW
-
Design load (heating) (cold heating season)- kW
-
Design load (heating) (cold heating season)- kW
Indoor unit
-
Type of indoor unitCeiling
-
Noise level of the indoor unit (low speed)37 dB
-
Noise level of the indoor unit (high speed)45 dB
-
Sound power level of the indoor unit61 dB
-
Air cooling (indoor unit)1434 m³/h
-
Quantity interior units1
-
Weight of the indoor unit33500 g
-
Height of the indoor unit235 mm
-
Depth of the indoor unit675 mm
-
Width of the inner unit1350 mm
-
Weight of the inner unit packaging39500 g
-
Height of the indoor unit packaging758 mm
-
Depth of the indoor unit packaging321 mm
-
Width of the inner unit packaging1439 mm
Outdoor unit
-
Noise level of the outdoor unit- dB
Frequently Asked Questions
What is BTU?
What does R-410A represent?
How often should I clean the filters of my Samsung air conditioner?
What is the energy label of the Samsung AM112JNCDKH?
Is the manual for the Samsung AM112JNCDKH available in French?
Similar products
More product categories from brand Samsung
Television and multimedia Samsung
Home appliances Samsung
Household appliances Samsung
Phones Samsung
Audio Samsung
Other Samsung
Interior Samsung
Tools Samsung
Software Samsung
More product types from brand Samsung
Presentation of product AM112JNCDKH specifications from brand Samsung
General Information
The Samsung AM112JNCDKH is an air conditioning unit from the Samsung brand, renowned for its excellence and innovation in the home appliance sector. This model, specifically designated AM112JNCDKH | AM112JNCDKH/EU, is designed to deliver optimal performance while enhancing the user experience.
Features
This air conditioning model is of the island type, a choice that combines functionality and aesthetics, facilitating the optimization of interior space. Although it does not have the Multi split feature, it stands out with its modern and elegant white hue. The system offers both cooling and heating functions, ensuring thermal comfort throughout the year.
In terms of energy efficiency, some specifications such as the seasonal efficiency ratio (SEER) for cooling and (SCOP) for heating are not provided, which could complicate the assessment of its energy performance. The maximum cooling capacity reaches 11,200 W, while its heating capacity can go up to 12,500 W, ensuring a pleasant climate even in extreme conditions.
The model uses an R410A refrigerant, known for its efficiency, and has pipe diameters of 15.88 mm for gas and 9.52 mm for liquid, thus ensuring optimal fluid circulation. Additionally, an indicator light is included, enhancing the user experience by signaling the operational status of the unit.
Power
The Samsung AM112JNCDKH is rated A for energy efficiency in cooling, which helps minimize energy consumption while maintaining high performance. However, information regarding energy efficiency in heating mode remains to be completed. The maximum electrical consumption is 92 W for cooling and 80 W for heating, thus ensuring optimal efficiency in these modes.
Indoor Unit
This model is equipped with a ceiling-mounted indoor unit, allowing for discreet installation suitable for various environments. Its noise level is 37 dB, ensuring quiet operation, although the sound power level can reach 61 dB in some cases. With an air circulation capacity of 1434 m³/h, this unit ensures effective air distribution for optimal thermal comfort.
The dimensions of the indoor unit are designed to ensure a harmonious installation: 1350 mm in width, 675 mm in depth, and 235 mm in height, with a total weight of 33.5 kg. The packaging of the unit weighs 39.5 kg, with dimensions of 1439 mm in width, 321 mm in depth, and 758 mm in height, thus facilitating transport and storage.
Outdoor Unit
Regarding the outdoor unit, its noise level is designed to be discreet, making it perfectly suitable for residential environments. Exact noise specifications are not provided, but the goal is to ensure quiet and pleasant operation.
