Manual of product AV1300
Technical Specifications AV1300
General Information
-
ModelAV1300
-
Brand
-
Category
-
Type
-
SKU1042814
-
MPN1042814
Representation / realization
-
Maximum data transfer rate1300 Mbit/s
-
Plug and PlayYes
-
Type of Ethernet LAN interfaceGigabit Ethernet
-
LAN Ethernet: data transfer rate10,100,1000 Mbit/s
-
Number of Ethernet LAN ports (RJ-45)3
-
Plug and PlayYes
-
Wi-Fi standardWi-Fi 5 (802.11ac)
-
Wifi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
-
Network standardsIEEE 1901, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
-
Male connectorType C
-
Plug and PlayYes
-
Standard high voltage lineHomePlug AV2
-
ModulationOFDM
-
Security-supported algorithm128-bit AES, WEP, WPA-PSK, WPA2-PSK
-
Maximum operating distance300 m
-
Frequency degree2400 - 5000 MHz
-
Plug and PlayYes
-
Plug and PlayYes
Minimum system requirements
-
Mac CompatibilityYes
-
Mac CompatibilityYes
-
Support for the Mac operating systemmacOS
-
Support for the Windows operating systemWindows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional
Packaging contents
-
Quantity2 piece(s)
-
Quick Installation GuideYes
-
Cables includedLAN (RJ-45)
Power
-
Typical electricity consumption13.3 W
-
Energy consumption (standby mode)6.5 W
Design
-
IndicatorsYes
-
Product colorWhite
-
Antenna typeExternal
-
CertificationCE
Weight and dimensions
-
Depth68 mm
-
Height45 mm
-
Width140.6 mm
Environmental conditions
-
Operating temperature0 - 40 °C
-
Temperature out of operation-40 - 70 °C
-
Operating relative humidity (H-H)10 - 90 %
-
Relative humidity rate (storage)5 - 90 %
Certificate
-
Sustainability certificatesRoHS
Packaging information
-
Package weight950 g
-
Package height100 mm
-
Package width230 mm
-
Package depth190 mm
Logistics data
-
Harmonized System Code85171800
Similar products
More product categories from brand TP-Link
Other TP-Link
Phones TP-Link
Interior TP-Link
Software TP-Link
Audio TP-Link
More product types from brand TP-Link
Presentation of product AV1300 specifications from brand TP-Link
Generalities
The product model TP-Link AV1300 is AV1300 | TL-WPA8630 KIT V2. This model ensures optimal performance and an enhanced user experience. The EAN code of the product TP-Link AV1300 is 0845973081409, 6935364081393, 6935364093624, 6935364098650. This code allows for the unique identification of the product in the distribution system. The brand of the product TP-Link AV1300 is TP-Link. This brand is known for its quality and innovation in the field of household appliances.
Packaging contents
The quantity of the product TP-Link AV1300 is 2 pièce(s). This specification allows you to know the number of units included in the packaging. The included cable of the product TP-Link AV1300 contains a power plug. This cable is essential for ensuring an optimal electrical connection. Does the product TP-Link AV1300 have a Quick Installation Guide? Oui. This guide will help you easily install the product by following clear and concise steps.
Minimum system requirements
Does the product TP-Link AV1300 support the Linux operating system? Oui. This feature allows for optimal compatibility with Linux environments, thus providing increased usability flexibility. Is the product TP-Link AV1300 compatible with Mac? No. This product is not compatible with Mac systems. Does the product TP-Link AV1300 support the Mac operating system? macOS. This feature ensures optimal compatibility for Mac users. Does the product TP-Link AV1300 support the Windows operating system? Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional. This feature ensures optimal compatibility with Windows systems, providing a smooth and uninterrupted user experience.
Power
The energy consumption in standby mode of the product TP-Link AV1300 is 6.5 W. This feature helps reduce electricity consumption when the device is not in use, thus contributing to energy savings. The typical power consumption of the product TP-Link AV1300 is 13.3 W. This feature allows for the assessment of the energy efficiency of the device.
Representation / realization
The maximum data transfer rate of the product TP-Link AV1300 is 1300 Mbit/s. This rate ensures a fast and efficient connection for all your networking needs. Does the product TP-Link AV1300 have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. The data transfer rate of the product TP-Link AV1300 is 10,100,1000 Mbit/s. This rate ensures a fast and efficient connection for your networking needs. The Ethernet LAN interface type of the product TP-Link AV1300 is Gigabit Ethernet. This specification ensures a fast and reliable network connection. The number of Ethernet LAN (RJ-45) ports of the product TP-Link AV1300 is 3. These ports provide a stable and fast network connection for your devices. The Wifi of the product TP-Link AV1300 contains Oui. This Wifi allows for a fast and reliable wireless connection for all your devices. The Wi-Fi standard of the product TP-Link AV1300 is Wi-Fi 5 (802.11ac). This standard ensures a fast and reliable wireless connection for your devices. The wifi standard of the product TP-Link AV1300 contains 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n). This wifi standard ensures a fast and reliable connection for all your devices. The network standards of the product TP-Link AV1300 are IEEE 1901, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u. These standards ensure optimal compatibility with various equipment and protocols. The male plug of the product TP-Link AV1300 contains Type C. This male plug is designed to ensure a reliable and secure electrical connection. Does the TP-Link AV1300 have a built-in power outlet? No. This feature would allow devices to be powered directly without the need for an additional power strip. The product TP-Link AV1300 has a standard high voltage line. This specification ensures efficient and stable transmission of electrical energy. The modulation of the product TP-Link AV1300 is OFDM. This feature allows for the operation of the product to be adapted according to the specific needs of the user. The supported security algorithm of the product TP-Link AV1300 contains 128-bit AES, WEP, WPA-PSK, WPA2-PSK. This algorithm ensures optimal protection of your data. The maximum operating distance of the product TP-Link AV1300 is 300 m. This specification ensures optimal connectivity over long distances. The frequency degree of the product TP-Link AV1300 is 2400 - 5000 MHz. This frequency degree allows for efficient and stable signal transmission. Does the product TP-Link AV1300 have MIMO (multiple inputs, multiple outputs)? Oui. This specification allows for efficient signal management by providing multiple inputs and outputs simultaneously. Does the product TP-Link AV1300 have Plug and Play? Oui. This feature allows for quick and hassle-free installation, making the use of the product even more enjoyable.
Design
The type of antenna of the product TP-Link AV1300 is Externe. This antenna is designed to provide optimal performance in a compact space. The color of the product TP-Link AV1300 is Blanc. This shade gives it a modern and elegant look. Does the product TP-Link AV1300 have indicators? Oui. These indicators allow you to visualize the operating status of the device. The certification of the product TP-Link AV1300 contains CE. This certification guarantees compliance with the required safety and performance standards.
Weight and dimensions
The width of the product TP-Link AV1300 is 140.6 mm. This dimension is essential to ensure optimal integration into your space. The depth of the product TP-Link AV1300 is 68 mm. This dimension allows for optimal integration into your space. The height of the product TP-Link AV1300 is 45 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Environmental conditions
The non-operating temperature of the product TP-Link AV1300 is -40 - 70 °C. This specification ensures that the product can withstand extreme conditions without suffering damage. The operating temperature of the product TP-Link AV1300 is 0 - 40 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The relative humidity (storage) rate of the product TP-Link AV1300 is 5 - 90 %. This rate ensures optimal conditions for the preservation and durability of the product. The product TP-Link AV1300 has an operating relative humidity (H-H) of 10 - 90 %. This specification ensures optimal operation in a wide range of ambient humidity.
Certificate
The product TP-Link AV1300 has Sustainability Certificates: RoHS. These certificates ensure that the product meets high standards for energy efficiency and environmental respect.
Packaging information
The width of the package of the product TP-Link AV1300 is 230 mm. This dimension is essential to ensure optimal transport and storage. The weight of the TP-Link AV1300 package is 950 g. This weight ensures optimal protection during transport and delivery. The height of the package of the product TP-Link AV1300 is 100 mm. This dimension is essential to ensure optimal transport and storage. The depth of the product package TP-Link AV1300 is 190 mm. This dimension is essential to ensure proper packaging and secure transport.
Logistics data
The Harmonized System code for the product TP-Link AV1300 is 85171800. This code allows for the unique identification of goods in international trade.
