Manuals of product TI-RP262i
Technical Specifications TI-RP262i
General Information
-
ModelTI-RP262I
-
Brand
-
Category
-
Type
-
SKU1942928
-
MPN1942928
Design
-
Stackable-
-
Product colorBlack
-
International Protection Code (IP)IP30
-
Material of the case/bodyMetal
-
IndicatorsYes
-
Format1U
-
IndicatorsYes
Management features
-
Switch typeManaged
-
Web-based managementYes
-
Web-based managementYes
-
Web-based managementYes
-
Web-based managementYes
-
Switching benchL2
Packaging contents
-
Rack mounting kitYes
-
Rack mounting kitYes
Certificate
-
CertificationCE
-
FCC
-
IEC 60068-2-27
-
IEC 60068-2-32
-
IEC 60068-2-6
Weight and dimensions
-
Weight3580 g
-
Width440 mm
-
Depth310 mm
-
Height44 mm
Environmental conditions
-
Operating temperature-40 - 70 °C
-
Operating relative humidity (H-H)0 - 95 %
PoE (Power over Ethernet)
-
Ethernet connection, supporting power over this port (PoE)Yes
-
Total Power over Ethernet (PoE) Budget685 W
-
Power over Ethernet (PoE) powered port30 W
-
Power over Ethernet (PoE)48 V
-
Quantity of Power Over Ethernet plus (PoE+) ports24
Representation / realization
-
Mean time between failures475352 h
-
Without fanYes
Network
-
Network standardsIEEE 802.1AX
-
Support 10GIEEE 802.1D
-
Port mirroringIEEE 802.1Q
-
Port mirroringIEEE 802.1ab
-
Virtual LAN functionsIEEE 802.1p
-
Number of VLANsIEEE 802.1w
-
Port mirroringIEEE 802.1x
-
Port mirroringIEEE 802.3ab
-
Port mirroringIEEE 802.3ad
-
Port mirroringIEEE 802.3af
-
IEEE 802.3at
-
IEEE 802.3az
-
IEEE 802.3u
-
No
-
Yes
-
Yes
-
MAC address-based VLAN
-
Tagged VLAN
-
4094
-
Yes
-
Yes
-
Yes
-
Yes
Power
-
Power supply included-
-
Electrical protection devicesOver current
-
Consumption (max)Short circuit
-
705 W
Security
-
DHCP FunctionsDHCP Option 82
-
BPDU filtering/protectionDHCP relay
-
BPDU filtering/protectionDHCP server
-
Queue scheduling algorithmsDHCP snooping
-
BPDU filtering/protectionYes
-
Security-supported algorithmYes
-
SP, WFQ, Weighted Round Robin (WRR)
-
Yes
-
SNMP, SNMPv2, SNMPv3, SSH-2
Multicast features
-
Multicast supportYes
-
Number of filtered multicast groups256
Data transmission
-
Switching capacity52 Gbit/s
-
MAC Directory8000 entries
-
Transfer rate38.7 Mpps
-
Giant frames10000
-
Registration-and-reissueYes
-
Packet cache memory0.5 MB
-
Registration-and-reissueYes
Connectivity
-
Quantity of SFP module slots2
-
Number of installed SFP modules0
-
Number of installed SFP modules0
-
Quantity of basic switching RJ-45 Ethernet ports24
-
Basic switching RJ-45 Ethernet port typeGigabit Ethernet (10/100/1000)
-
Console portRJ-45
Logistics data
-
Harmonized System Code85176990
Similar products
More product categories from brand TRENDnet
Other TRENDnet
Software TRENDnet
Phones TRENDnet
Tools TRENDnet
Audio TRENDnet
More product types from brand TRENDnet
Presentation of product TI-RP262i specifications from brand TRENDnet
Generalities
The brand of the product TRENDnet TI-RP262i is TRENDnet. This brand is known for its quality and innovation in the field of household appliances. The product model TRENDnet TI-RP262i is TI-RP262i | TI-RP262I. This model ensures optimal performance and an enhanced user experience. The EAN code of the product TRENDnet TI-RP262i is 0710931161700, 710931161700. This code allows for the unique identification of the product in the distribution system.
Packaging contents
Does the product TRENDnet TI-RP262i have a Quick Start Guide? Yes. This guide allows you to quickly and easily start using the product. Does the product TRENDnet TI-RP262i have a rack mounting kit? Oui. This kit allows for easy and secure installation in a standard rack.
Design
The color of the product TRENDnet TI-RP262i is Noir. This shade gives it a modern and elegant look. Does the product TRENDnet TI-RP262i have a mounting bracket? Oui. This feature determines the compatibility and ease of installation of the product. The International Protection Code (IP) for product TRENDnet TI-RP262i contains IP30. This code indicates the level of protection against solid objects and moisture. The material of the product case TRENDnet TI-RP262i is Métal. This material ensures both durability and elegance. Is the product TRENDnet TI-RP262i stackable? No. This product cannot be stacked. The format of the product TRENDnet TI-RP262i is a bar. This format allows for practical and efficient use in various contexts. Does the product TRENDnet TI-RP262i have indicators? Oui. These indicators allow you to visualize the operating status of the device.
Management features
The switch type of the product TRENDnet TI-RP262i is Géré. This type of switch allows for advanced management and optimal control of the network. Does the product TRENDnet TI-RP262i have an ARP Inspection? Oui. This feature ensures optimal management of inspection processes. Does the product TRENDnet TI-RP262i have Quality of Service (QoS)? Oui. This feature ensures optimal management of network resources, thus providing a smooth and uninterrupted user experience. Does the product TRENDnet TI-RP262i have System Event Log? Oui. This log allows tracking and recording all system activities and events to ensure optimal security. The TRENDnet TI-RP262i product has web-based management. This feature allows for easy and accessible administration of your data from any device connected to the Internet. The switchboard of the product TRENDnet TI-RP262i contains L2. This switchboard allows for efficient and optimized network management.
Certificate
The certification of the product TRENDnet TI-RP262i contains CE\nFCC\nIEC 60068-2-27\nIEC 60068-2-32\nIEC 60068-2-6. This certification guarantees compliance with the required safety and performance standards.
Environmental conditions
The operating temperature of the product TRENDnet TI-RP262i is -40 - 70 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The product TRENDnet TI-RP262i has an operating relative humidity (H-H) of 0 - 95 %. This specification ensures optimal operation in a wide range of ambient humidity.
PoE (Power over Ethernet)
Does the TRENDnet TI-RP262i have an Ethernet connection, supporting power over this port (PoE)? Oui. This feature allows for simplified and efficient power supply to connected devices. The Total Power over Ethernet (PoE) budget of the product TRENDnet TI-RP262i is 685 W. This budget allows for the efficient powering of multiple devices through a single network cable. The product TRENDnet TI-RP262i has a PoE (Power over Ethernet) power port of 30 W. This feature allows compatible devices to be powered through the same Ethernet cable, thereby simplifying installation and reducing the need for additional electrical outlets. The product TRENDnet TI-RP262i features Power over Ethernet (PoE) of 48 V. This specification allows for the transmission of both data and electrical power over a single cable, thereby simplifying installation and reducing the need for additional electrical outlets. The product TRENDnet TI-RP262i has 24 Power Over Ethernet plus (PoE+) ports, allowing for efficient and simplified power supply to connected devices.
Weight and dimensions
The weight of the product TRENDnet TI-RP262i is 3580 g. This weight is ideal for ensuring optimal use and easy handling. The depth of the product TRENDnet TI-RP262i is 310 mm. This dimension allows for optimal integration into your space. The height of the product TRENDnet TI-RP262i is 44 mm. This dimension is essential to ensure that the product fits perfectly in your space. The width of the product TRENDnet TI-RP262i is 440 mm. This dimension is essential to ensure optimal integration into your space.
Representation / realization
The average time between failures of the product TRENDnet TI-RP262i is 475352 h. This feature demonstrates the reliability and durability of the product, ensuring prolonged use without interruptions. Does the product TRENDnet TI-RP262i have a fan? No. This product operates without a fan, ensuring silent operation and optimal use in various environments.
Power
The electrical protection devices of the product TRENDnet TI-RP262i include protections against overloads, surges, and short circuits. These devices ensure the safety and reliability of your electrical installation. Does the TRENDnet TI-RP262i come with a power supply included? -. This ensures that you have everything you need for immediate use. The maximum consumption of the product TRENDnet TI-RP262i is 705 W. This specification allows for the assessment of the energy efficiency of the device.
Security
Does the product TRENDnet TI-RP262i have an Access Control List (ACL)? Oui. This feature allows for precise and secure management of user access rights. The product TRENDnet TI-RP262i has DHCP functions. These functions allow for efficient management of IP addresses within a network, thus facilitating the connection of devices. The product TRENDnet TI-RP262i contains queue scheduling algorithms, such as SP, WFQ, Weighted Round Robin (WRR), that optimize resource management and enhance system security. Does the product TRENDnet TI-RP262i have IGMP Snooping? Oui. This feature allows for efficient management of multicast traffic, thereby enhancing network security and performance. Does the product TRENDnet TI-RP262i have BPDU filtering/protection? Oui. This feature provides effective protection against unwanted network loops. The supported security algorithm of the product TRENDnet TI-RP262i contains SNMP, SNMPv2, SNMPv3, SSH-2. This algorithm ensures optimal protection of your data.
Multicast features
Does the product TRENDnet TI-RP262i support multicast? Oui. This support allows for efficient data transmission to multiple recipients simultaneously. The number of filtered multicast groups for the product TRENDnet TI-RP262i is 256. This number helps optimize the management of multicast data streams.
Network
Does the product TRENDnet TI-RP262i support VLAN? Oui. This feature allows for optimized network management by segmenting traffic. The network standards of the product TRENDnet TI-RP262i are IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. These standards ensure optimal compatibility with various equipment and protocols. Does the product TRENDnet TI-RP262i have 10G support? No. This product does not support the 10G support standard, which may affect its performance in high-speed environments. Does the product TRENDnet TI-RP262i have supported MAC address machine learning? Oui. This feature allows for optimized management of network connections. The virtual LAN functions of the TRENDnet TI-RP262i product contain MAC address-based VLAN, Tagged VLAN. This feature allows for network segmentation for better data management and security. The number of VLANs for the product TRENDnet TI-RP262i is 4094. This high number allows for effective network segmentation for better management and security. Does the product TRENDnet TI-RP262i have Link Aggregation? Oui. This feature allows for optimizing network connection management for enhanced performance. Does the product TRENDnet TI-RP262i have Spanning Tree Protocols (STP)? Oui. This protocol is essential to prevent loops in networks. Does the product TRENDnet TI-RP262i have a Broadcast storm Control? Oui. This feature allows for efficient network traffic management by preventing broadcast storms, thus ensuring optimal performance. Does the product TRENDnet TI-RP262i have Port mirroring? Oui. This feature allows for duplicating traffic from one port to another, thus facilitating network analysis and monitoring.
Logistics data
The Harmonized System code for the product TRENDnet TI-RP262i is 85176990. This code allows for the unique identification of goods in international trade.
Data transmission
The MAC directory of the product TRENDnet TI-RP262i contains 8000 entrées. This directory allows for precise identification of devices on the network. The switching capacity of the product TRENDnet TI-RP262i is 52 Gbit/s. This specification ensures efficient data transmission. The product TRENDnet TI-RP262i contains 15000 giant frames. These giant frames allow for efficient data management within the network. The transfer rate of the product TRENDnet TI-RP262i is 38.7 Mpps. This high rate ensures optimal performance for your networking needs. The product TRENDnet TI-RP262i supports jumbo frames. This feature allows for optimizing data transfer over the network, thereby improving overall performance. The packet cache memory of the product TRENDnet TI-RP262i contains 0.5 Mo. This memory helps optimize data transmission by temporarily storing packets for faster access. Does the product TRENDnet TI-RP262i have Recording-and-rebroadcasting? Oui. This feature allows for efficient data capture and retransmission.
Connectivity
The number of SFP module slots for the TRENDnet TI-RP262i product is 2. These slots allow for increased flexibility in network connectivity. The number of installed SFP+ modules for the product TRENDnet TI-RP262i is 0. This number helps optimize connectivity and ensure high performance. The number of SFP modules installed for the product TRENDnet TI-RP262i is 0. This number helps optimize connectivity and ensure efficient network performance. The number of basic switching RJ-45 Ethernet ports of the product TRENDnet TI-RP262i is 24. These ports enable efficient and fast network connectivity. The basic switching RJ-45 Ethernet port type of the product TRENDnet TI-RP262i is Gigabit Ethernet (10/100/1000). This port allows for a fast and reliable connection for your network devices. The console port of the product TRENDnet TI-RP262i contains RJ-45. This port allows for effective communication with other devices.
