Manuals of product V32
Technical Specifications V32
General Information
-
ModelV32
-
Brand
-
Category
-
Type
-
SKU1303995
-
MPN1303995
Representation / realization
-
Video input channels16 channels
-
Maximum video resolution throughput6 Mbit/s
-
Image adjustmentPrivacy mask
-
Web-based managementYes
-
Compatible operating systemsWindows 8.1, Windows 7 SP1, Windows Server 2008 R2 SP1
-
Web-based managementYes
-
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
-
Web-based managementYes
Video
-
Number of channels16 channels
-
Maximum video resolution960 x 576 pixels
-
Maximum cadence30 fps
-
Visual compression formatsH.264
Network
-
Supported network protocolsTCP
-
UDP
-
HTTP
-
HTTPS
-
DHCP
-
PPPoE
-
RTP
-
RTSP
-
IPv4/v6
-
DNS
-
DDNS
-
NTP
-
ICMP
-
ARP
-
IGMP
-
SMTP
-
FTP
-
UPnP
-
SNMP
-
Bonjour
-
IEEE 802.1X
Connectivity
-
Number of Ethernet LAN ports (RJ-45)1
-
BNC entry ports16
-
Input/Output terminal ports2
Security
-
Motion detector (video)Yes
-
Security-supported algorithmHTTPS
-
Password protectionUser
-
Motion detector (video)Yes
Power
-
Typical electricity consumption9.36 W
Weight and dimensions
-
Weight1886 g
-
Width444 mm
-
Depth142 mm
-
Height44.5 mm
Environmental conditions
-
Temperature out of operation-10 - 50 °C
-
Temperature out of operation-10 - 50 °C
-
Operating relative humidity (H-H)10 - 85 %
Design
-
CertificationCE
-
FCC
-
UL
-
CB
-
IEC 60950-1:2005
Similar products
More product categories from brand ACTi
More product types from brand ACTi
Presentation of product V32 specifications from brand ACTi
Network
The supported network protocols of the product ACTi V32 are TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv4/v6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour, IEEE 802.1X. These protocols ensure efficient and reliable communication for your networking needs.
Generalities
The product model ACTi V32 is V32 | V32. This model ensures optimal performance and an enhanced user experience. The EAN code of the product ACTi V32 is 4718201799642. This code allows for the unique identification of the product in the distribution system. The brand of the product ACTi V32 is ACTi. This brand is known for its quality and innovation in the field of household appliances.
Video
The maximum frame rate of the product ACTi V32 is 30 ips. This specification ensures optimal image smoothness for your recordings. The maximum video resolution of the product ACTi V32 is 960 x 576 pixels. This specification ensures optimal image quality for your videos. The quantity of channels of the product ACTi V32 is 16 canaux. This specification determines the number of communication paths available for optimal use. The product ACTi V32 has visual compression formats: H.264. These formats ensure optimal image quality for your videos.
Representation / realization
The number of video input channels of the product ACTi V32 is 16 canaux. These channels allow for optimal connectivity for your multimedia devices. The product image adjustment ACTi V32 includes options such as brightness, contrast, mirror, and privacy mask. These settings allow you to optimize visual quality according to your needs. The PTZ control of the product ACTi V32 is Oui. This control allows for precise and efficient management of pan, tilt, and zoom. The output at a maximum video resolution of the product ACTi V32 is 6 Mbit/s. This specification ensures optimal image quality for your videos. The compatible operating system for the product ACTi V32 is Windows XP, Windows Vista, Windows 7. These operating systems ensure optimal and smooth use of the product. Does the ACTi V32 have a built-in memory card reader? Oui. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution. The product ACTi V32 has compatible memory cards: MicroSD (TransFlash), MicroSDHC. These memory cards ensure optimal performance for storing your data. The ACTi V32 product has web-based management. This feature allows for easy and accessible administration of your data from any device connected to the Internet.
Connectivity
The number of Ethernet LAN (RJ-45) ports of the product ACTi V32 is 1. These ports provide a stable and fast network connection for your devices. The BNC input port of the ACTi V32 contains 16. This port allows for a reliable and quality connection for your equipment. The input/output terminal ports of the product ACTi V32 contain 2. These ports allow optimal connectivity with various devices.
Security
The supported security algorithm of the product ACTi V32 contains HTTPS. This algorithm ensures optimal protection of your data. Does the ACTi V32 product filter IP addresses? Oui. This feature enhances security by blocking unauthorized access. Does the product ACTi V32 have a Motion Detector (video)? Oui. This device provides effective monitoring by capturing video footage during motion detections. Does the product ACTi V32 have Password Protection? Utilisateur. This feature ensures the security of your personal data.
Power
The typical power consumption of the product ACTi V32 is 9.36 W. This feature allows for the assessment of the energy efficiency of the device.
Weight and dimensions
The width of the product ACTi V32 is 444 mm. This dimension is essential to ensure optimal integration into your space. The weight of the product ACTi V32 is 1886 g. This weight is ideal for ensuring optimal use and easy handling. The depth of the product ACTi V32 is 142 mm. This dimension allows for optimal integration into your space. The height of the product ACTi V32 is 44.5 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Environmental conditions
The product ACTi V32 has an operating relative humidity (H-H) of 10 - 85 %. This specification ensures optimal operation in a wide range of ambient humidity. The operating temperature of the product ACTi V32 is -10 - 50 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The non-operating temperature of the product ACTi V32 is -10 - 50 °C. This specification ensures that the product can withstand extreme conditions without suffering damage.
Design
The certification of the product ACTi V32 contains CE, FCC, UL, CB, IEC 60950-1:2005. This certification guarantees compliance with the required safety and performance standards.
