Manual of product ADS-4900W
Technical Specifications ADS-4900W
General Information
-
ModelADS-4900W
-
Brand
-
Category
-
Type
-
SKU1574890
-
MPN1574890
Digitization
-
Maximum scanning area215.9 x 355.6 mm
-
Optical scanning resolution600 x 600 DPI
-
Enhanced scanning resolution1200 x 1200 DPI
-
Double-sided scanningYes
-
Double-sided scanningYes
-
Input color display depth48 bit
-
Output color display depth24 bit
-
Gray levels256
-
ADF scanning speed (color, A4)60 ppm
-
ADF scanning speed (color, A4)60 ppm
-
ADF duplex scanning speed (color, A4)120 ipm
-
ADF duplex scanning speed (color, A4)120 ipm
-
Output grayscale resolution8 bit
Power
-
Type of power supplySector
-
Typical electricity consumption34 W
-
Energy consumption (standby mode)7.7 W
-
Electricity consumption (stop)0.1 W
-
Energy consumption (in standby mode)1.7 W
-
Automatic power cut-offYes
-
Output voltage24 V
-
Output current1.9 A
-
Automatic power cut-offYes
Network
-
IPv6 supportYes
-
Wifi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
-
IPv6 supportYes
-
Security-supported algorithmAES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3
-
IPv6 supportYes
-
Support for network protocols (IPv4)DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP
-
Support for network protocols (IPv6)RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6
Packaging information
-
Quantity1 piece(s)
-
Package width393 mm
-
Package depth288 mm
-
Package height334 mm
-
Package weight4200 g
Design
-
Type of scannerAutomatic document feeder + Sheet scanner
-
Color displayYes
-
Product colorBlack, White
-
Color displayYes
-
Color displayYes
-
Order typeTouchscreen
-
ScreenLCD
-
Screen size4.3 "
Minimum system requirements
-
Support for the Linux operating systemYes
-
Support for the Linux operating systemYes
-
Support for the Linux operating systemYes
-
Support for the server operating systemWindows Server 2012 R2, Windows Server 2016, Windows Server 2019
Environmental conditions
-
Operating temperature5 - 35 °C
-
Temperature out of operation-20 - 60 °C
-
Operating relative humidity (H-H)20 - 80 %
-
Relative humidity rate (storage)10 - 90 %
Representation / realization
-
Sensor typeDual CIS
-
Operating cycle per day (max)9000 pages
-
Service cycle (Maximum)180000 pages per month
-
Scan toE-mail Server, FTP, HTTP, PC, SMB
-
Scan driversISIS, SANE, TWAIN, WIA
-
Sound level of the scanner, in operation62 dB
-
Formats of scanned filesJPEG, PDF, TIFF
-
Light sourceLED
-
Ultrasonic sensorYes
Weight and dimensions
-
Width300 mm
-
Depth247 mm
-
Height236 mm
-
Weight3370 g
Input capacity
-
Automatic document feeder capacity100 sheets
Paper management
-
Maximum ISO A series paper sizeA4
-
Support for media scanning typesBusiness Card
-
Maximum sweep widthPlain paper
-
Maximum sweep lengthPlastic Card
-
Long paper modeRecycled paper
-
Thickness of supports (min)Thick paper
-
Card thickness (max)Thin paper
-
Weight of the media, automatic document feeder215.9 mm
-
Weight of the media, automatic document feeder5000 mm
-
Yes
-
0.08 mm
-
1.32 mm
-
25 - 413 g/m²
-
25 - 413 g/m²
Connectivity
-
USB portYes
-
USB Version2.0/3.2 Gen 1 (3.1 Gen 1)
Other features
-
Cable anti-theft lockYes
Certificate
-
CertificationGS Mark
-
WHQL
-
WHQL
-
ISIS
-
Wi-Fi CERTIFIED - WPA3 Enterprise
-
WPA3 Personal
-
Wi-Fi Protected Setup
-
Wi-Fi Direct
-
KofaxTM 5
-
10 - VRS Elite 5.2.0
-
Kofax Express 3.3.0
Packaging contents
-
Cables includedAC
-
USB
Logistics data
-
Harmonized System Code84716070
Similar products
More product categories from brand Brother
Home appliances Brother
Other Brother
Tools Brother
Phones Brother
Interior Brother
More product types from brand Brother
Presentation of product ADS-4900W specifications from brand Brother
Generalities
The brand of the product Brother ADS-4900W is Brother. This brand is known for its quality and innovation in the field of household appliances. The product model Brother ADS-4900W is ADS-4900W | ADS-4900W. This model ensures optimal performance and an enhanced user experience. The EAN code of the product Brother ADS-4900W is 0012502666363, 4977766814812, 4977766814775. This code allows for the unique identification of the product in the distribution system.
Network
The Wifi of the product Brother ADS-4900W contains Oui. This Wifi allows for a fast and reliable wireless connection for all your devices. The supported security algorithm of the product Brother ADS-4900W contains AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3. This algorithm ensures optimal protection of your data. The wifi standard of the product Brother ADS-4900W contains 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n). This wifi standard ensures a fast and reliable connection for all your devices. Does the product Brother ADS-4900W have Ethernet/LAN? Oui. This specification determines the network connectivity of the product. Does the product Brother ADS-4900W support IPv6? Oui. This feature ensures modern and efficient network connectivity. The network protocol support (IPv4) of the product Brother ADS-4900W includes DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP. This support ensures optimal connectivity and efficient print management. The support for network protocols (IPv6) of the product Brother ADS-4900W includes RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6. This support ensures optimal connectivity and efficient management of IP addresses in modern environments.
Power
The power supply type of the product Brother ADS-4900W is Secteur. This specification ensures reliable and efficient use of the device. The typical power consumption of the product Brother ADS-4900W is 34 W. This feature allows for the assessment of the energy efficiency of the device. The power consumption (standby) of the product Brother ADS-4900W is 0.1 W. This feature helps to minimize energy consumption when the device is in standby mode. The energy consumption in standby mode of the product Brother ADS-4900W is 7.7 W. This feature helps reduce electricity consumption when the device is not in use, thus contributing to energy savings. The energy consumption in standby mode of the product Brother ADS-4900W is 1.7 W. This feature helps to reduce the energy impact when the device is not in use. Does the product Brother ADS-4900W have a standby mode? Oui. This feature helps save energy when the product is not in use. The output voltage of the Brother ADS-4900W is 24 V. This specification ensures optimal performance for your electrical needs. The output current of the product Brother ADS-4900W is 1.9 A. This current ensures optimal performance for your electrical needs. Does the product Brother ADS-4900W have an automatic power cut-off? Oui. This feature ensures increased safety by turning off the device when necessary.
Packaging information
The width of the package of the product Brother ADS-4900W is 393 mm. This dimension is essential to ensure optimal transport and storage. The depth of the product package Brother ADS-4900W is 288 mm. This dimension is essential to ensure proper packaging and secure transport. The height of the package of the product Brother ADS-4900W is 334 mm. This dimension is essential to ensure optimal transport and storage. The quantity of the product Brother ADS-4900W is 1 pièce(s). This specification allows you to know the number of units included in the packaging. The weight of the Brother ADS-4900W package is 4200 g. This weight ensures optimal protection during transport and delivery.
Digitization
The maximum scanning surface of the product Brother ADS-4900W is 215.9 x 355.6 mm. This feature allows for the precise and efficient scanning of large documents. The product Brother ADS-4900W has an enhanced scanning resolution of 1200 x 1200 DPI. This specification ensures images of exceptional clarity, ideal for professional documents and photos. Does the product Brother ADS-4900W have color scanning? Oui. This feature allows capturing images with vibrant and accurate colors, thus providing superior image quality. The product Brother ADS-4900W has an optical scanning resolution of 600 x 600 DPI. This specification ensures high-quality images and precise details during scanning. Does the product Brother ADS-4900W have Duplex scanning? No. This feature would allow scanning documents on both sides, but this product does not offer it. The color input display depth of the product Brother ADS-4900W is 48 bit. This specification ensures accurate color reproduction for an optimal visual experience. The output color display depth of the product Brother ADS-4900W is 24 bit. This feature ensures accurate and rich color reproduction for an optimal visual experience. The grayscale levels of the product Brother ADS-4900W contain 256. This specification allows for detailed and precise shades in scanned images. The product Brother ADS-4900W has an ADF scanning speed (b/w, A4) of 60 ppm. This performance ensures fast and efficient scanning for all your documents. The product Brother ADS-4900W has an ADF scanning speed (color, A4) of 60 ppm. This feature allows for optimizing efficiency when scanning color documents in A4 format. The product Brother ADS-4900W has a duplex ADF scanning speed (b/w, A4) of 120 ipm. This performance ensures fast and efficient scanning of your documents. The product Brother ADS-4900W has a duplex ADF scanning speed (color, A4) of 120 ipm. This specification allows for fast and efficient scanning of your documents. The output grayscale resolution of the Brother ADS-4900W is 8 bit. This specification allows for precise and detailed shades in scanned images.
Design
Does the product Brother ADS-4900W have a touchscreen? Oui. The color of the product Brother ADS-4900W is Black, White. This shade gives it a modern and elegant look. The Brother ADS-4900W has a built-in screen. This screen provides an immersive and convenient visual experience, making it easier to use the device. The type of scanner of the product Brother ADS-4900W is a Chargeur automatique de documents + Scanner à feuille. This type of scanner allows for fast and efficient scanning of multiple documents at once. Does the product Brother ADS-4900W have a color display? Oui. This feature allows for a rich and dynamic visual experience. The product Brother ADS-4900W order type consists of Tactile. This order type allows for intuitive and practical use. The Brother ADS-4900W screen contains LCD. This screen offers exceptional image quality for an immersive visual experience. The screen size of the product Brother ADS-4900W is 4.3 ". This dimension allows for an optimal visual experience for all your content.
Minimum system requirements
Does the product Brother ADS-4900W support the Windows operating system? Oui. This feature ensures optimal compatibility with Windows systems, providing a smooth and uninterrupted user experience. Does the product Brother ADS-4900W support the Linux operating system? Oui. This feature allows for optimal compatibility with Linux environments, thus providing increased usability flexibility. The server operating system support for the product Brother ADS-4900W includes Windows Server 2012 R2, Windows Server 2016, Windows Server 2019. This support ensures optimal compatibility with modern server environments. Does the product Brother ADS-4900W support the Mac operating system? Oui. This feature ensures optimal compatibility for Mac users.
Environmental conditions
The operating temperature of the product Brother ADS-4900W is 5 - 35 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The relative humidity (storage) rate of the product Brother ADS-4900W is 10 - 90 %. This rate ensures optimal conditions for the preservation and durability of the product. The non-operating temperature of the product Brother ADS-4900W is -20 - 60 °C. This specification ensures that the product can withstand extreme conditions without suffering damage. The product Brother ADS-4900W has an operating relative humidity (H-H) of 20 - 80 %. This specification ensures optimal operation in a wide range of ambient humidity.
Input capacity
The capacity of the automatic document feeder of the product Brother ADS-4900W is 100 feuilles. This capacity allows for the efficient processing of a large volume of documents at once.
Weight and dimensions
The depth of the product Brother ADS-4900W is 247 mm. This dimension allows for optimal integration into your space. The width of the product Brother ADS-4900W is 300 mm. This dimension is essential to ensure optimal integration into your space. The weight of the product Brother ADS-4900W is 3370 g. This weight is ideal for ensuring optimal use and easy handling. The height of the product Brother ADS-4900W is 236 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Representation / realization
The daily operating cycle (max) of the product Brother ADS-4900W is 9000 pages. This cycle allows for intensive use while ensuring optimal performance. The sensor type of the product Brother ADS-4900W is Dual CIS. This type of sensor ensures optimal image quality for your needs. The maximum service cycle of the product Brother ADS-4900W is 180000 pages par mois. This cycle allows for intensive use and meets the needs of demanding users. The scanning mode of the product Brother ADS-4900W contains E-mail Server, FTP, HTTP, PC, SMB. This mode allows flexibility in the choice of scanning protocols. The scan driver for the product Brother ADS-4900W contains ISIS, SANE, TWAIN, WIA. This scan driver ensures optimal compatibility with various scanning systems. The noise level of the scanner Brother ADS-4900W is 62 dB. This noise level ensures discreet use, ideal for noise-sensitive work environments. The format of the scanned files of the product Brother ADS-4900W contains JPEG, PDF, TIFF. This format allows for great flexibility in storing and sharing documents. The product Brother ADS-4900W has a light source LED. This light source offers energy efficiency and a long lifespan, ensuring optimal lighting. Does the product Brother ADS-4900W have an ultrasonic sensor? Oui. This sensor allows for precise distance measurement using sound waves.
Other features
Does the product Brother ADS-4900W have a cable lock port? No. This product does not have this security feature.
Connectivity
Does the Brother ADS-4900W have a USB Port? Oui. This feature allows for easy and quick connection to various devices. The USB Version of the product Brother ADS-4900W is 2.0/3.2 Gen 1 (3.1 Gen 1). This USB Version allows for a fast and efficient connection with various devices.
Paper management
The maximum sweep length of the product Brother ADS-4900W is 5000 mm. This feature helps optimize efficiency when using the device. The maximum sweep width of the product Brother ADS-4900W is 215.9 mm. This specification allows for optimized paper management for various formats. The support for the scanning types of the product Brother ADS-4900W is suitable for business cards, envelopes, and plastic cards. This varied support allows for optimal flexibility for all your scanning needs. The product Brother ADS-4900W has a maximum ISO A series paper size of A4. This specification ensures optimal compatibility with standard printers and office equipment. Does the product Brother ADS-4900W have a long paper mode? Oui. This feature allows the use of elongated paper sheets, thus providing more flexibility for your prints. The minimum thickness of supports for the product Brother ADS-4900W is 0.08 mm. This specification ensures optimal quality for your prints. The product Brother ADS-4900W has a card thickness (max) of 1.32 mm. This specification ensures optimal quality for your printing projects. The weight of the paper tray support of the product Brother ADS-4900W is 25 - 413 g/m². This specification ensures optimal quality for your prints. The weight of the product support Brother ADS-4900W is 25 - 413 g/m². This weight allows for optimal use with the automatic document feeder, thus ensuring efficient and reliable performance.
Certificate
The certification of the product Brother ADS-4900W contains GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5, 10 - VRS Elite 5.2.0, Kofax Express 3.3.0. This certification guarantees compliance with the required safety and performance standards.
Packaging contents
The included cable of the product Brother ADS-4900W contains a power plug. This cable is essential for ensuring an optimal electrical connection.
Logistics data
The Harmonized System code for the product Brother ADS-4900W is 84716070. This code allows for the unique identification of goods in international trade.
