The Hikvision DS-2CE57D3T-VPITF camera offers excellent performance, especially in low light, thanks to its minimum illumination of 0.005 lux, ensuring clear images even in dark conditions. Its usability flexibility is enhanced by a rotation angle of 355° and a tilt angle of 0 to 75°, allowing the camera to be adjusted as needed. Its robust design, with an IP67 protection rating, ensures resistance to water and dust, making it an ideal choice for outdoor use. Additionally, its maximum resolution of 1920 x 1080 pixels allows for capturing images and videos of exceptional clarity, although the total number of megapixels is relatively low (2 MP), which may not satisfy users looking for very high image quality. However, there are some drawbacks to consider. The lack of an integrated hard drive requires the use of an external storage device, which can complicate installation. Furthermore, the absence of Wi-Fi and Bluetooth connectivity limits the flexibility of access to wireless features. The 82° field of view may also seem restrictive for some users, especially in larger spaces. Finally, the documentation provided is only in English, which could pose difficulties for those who are not proficient in this language. In summary, the Hikvision DS-2CE57D3T-VPITF is a high-performing and robust camera, ideal for outdoor use, but it has some limitations in terms of connectivity and usability flexibility.Score details
User experience
The user experience is generally good, but the lack of Wi-Fi and Bluetooth connectivity limits flexibility and ease of access to wireless features.
Performance
The low-light performance is excellent thanks to a minimum illumination of 0.005 lux, ensuring clear images even in dark environments.
Design
The robust design with an IP67 rating ensures resistance to water and dust, making it ideal for outdoor use.
Features
The flexibility of use is optimized with a rotation angle of 355° and a tilt angle of 0 to 75°, but the 82° field of view may be restrictive for some users.
Value for money
Although the camera offers a good resolution of 1920 x 1080 pixels, the total number of megapixels is relatively low (2 MP), which may not satisfy users looking for very high-quality images.
Documentation
The product comes with a user manual and a quick start guide, making setup and use easier, although the documentation is only in English.
Advantages
Excellent low-light performance
355° rotation and 75° tilt
IP67 water protection rating
Night vision up to 30 meters
Resolution of 1920 x 1080 pixels
Disadvantages
No built-in hard drive
No Wi-Fi or Bluetooth connectivity
Resolution of only 2 MP
Field of view limited to 82°
Supports only English
Technical Specifications DS-2CE57D3T-VPITF
General Information
-
ModelDS-2CE57D3T-VPITF
-
Brand
-
Category
-
Type
-
SKU1303668
-
MPN1303668
Camera
-
Field of view of the lens, horizontal82 °
-
Minimum illumination0.005 lux
-
Rotation angle355 °
-
Inclination angle0 - 75 °
-
Panoramic0 - 355 °
-
Camera shutter speedPAL: 1/25 - 1/50000; NTSC: 1/30 - 1/50000 s
Representation / realization
-
TypeCCTV security camera
-
Supported installationOutdoor
-
Connectivity technologyWired
-
Infrared cutoff filterYes
-
Infrared cutoff filterYes
-
Infrared cutoff filterYes
-
Number of languages1
-
Languages taken into accountEnglish
-
Dynamic range120 dB
Storage support
-
Integrated hard driveNo
Design
-
FormatDome
-
Mounting typeCeiling
-
Product colorWhite
-
Material of the case/bodyMetal
-
International Protection Code (IP)IP67
-
Code IKIK10
Power
-
Power supply typeCC
-
Consumption (max)4.6 W
-
Output CC in volts12
Image sensor
-
Sensor typeCMOS
-
Number of sensors1
-
Progressive scanYes
Objective system
-
Number of lenses1
-
Maximum number of openings1.2
-
Fixed Focal Length3.6 mm
Environmental conditions
-
Operating temperature-40 - 60 °C
-
Operating relative humidity (H-H)0 - 90 %
Weight and dimensions
-
Diameter110.4 mm
-
Weight487 g
-
Height82.4 mm
Night vision
-
Night visionYes
-
Night vision distance30 m
Packaging contents
-
Number of cameras1
Video
-
Maximum resolution1920 x 1080 pixels
-
Total megapixels2 MP
-
Supported video modes1080p
-
Analog signal format systemNTSC, PAL
-
Smart IRYes
-
Noise reduction technology3D digital noise reduction
-
Image quality adjustmentBrightness, Contrast, DNR, Mirror, Sharpness
-
Smart IRYes
-
Smart IRYes
-
Number of images per second30 fps
Network
-
BluetoothNo
-
BluetoothNo
-
BluetoothNo
Frequently Asked Questions
What is the weight of the Hikvision DS-2CE57D3T-VPITF camera?
What is the height dimension of the Hikvision DS-2CE57D3T-VPITF?
Is the user manual for the Hikvision DS-2CE57D3T-VPITF available in French?
Similar products
More product categories from brand Hikvision
Other Hikvision
Audio Hikvision
Interior Hikvision
Phones Hikvision
Tools Hikvision
More product types from brand Hikvision
Presentation of product DS-2CE57D3T-VPITF specifications from brand Hikvision
General Information
The Hikvision DS-2CE57D3T-VPITF is a camera from the renowned brand Hikvision, famous for its innovations in security and surveillance equipment. This model, identified by the code DS-2CE57D3T-VPITF | DS-2CE57D3T-VPITF(3.6MM), offers top performance and an intuitive user interface. The EAN code 0842571123081 allows for precise identification in distribution systems.
Camera
This model features a field of view of 82 °, ideal for capturing images with an extended perspective, particularly useful for landscapes and groups. With a minimum illumination of only 0.005 lux, it ensures clear images even in low-light conditions. Its flexibility is enhanced by a rotation angle of 355 ° and a tilt angle ranging from 0 to 75 °, allowing adjustments according to the specific needs of the user. The shutter speed ranges from 1/25 to 1/50000 seconds in PAL and from 1/30 to 1/50000 seconds in NTSC, ensuring sharp image capture in various lighting conditions.
Representation/Realization
The design of the device is of the island type, offering an aesthetic and practical solution for integration into different environments. It allows for vertical installation, facilitating adaptation to various spaces. This model connects via a cable, providing reliable use without the constraints of wireless connections. It is also equipped with Wide Dynamic Range (WDR) and a day/night mode, optimizing its use in different lighting conditions. The infrared cut filter enhances image quality by adjusting wavelengths, and the dynamic range of 120 dB allows for accurate sound reproduction.
Storage Support
The Hikvision DS-2CE57D3T-VPITF does not have a built-in hard drive, which implies the use of an external storage device for recording images and videos.
Design
This model features a bar format and is designed for ceiling mounting, making installation easier. Its white color gives it a modern look, while the metal casing ensures significant durability. With an IP67 protection rating, it is resistant to water and dust, making it suitable for outdoor use. The IK10 rating also indicates robustness against impacts.
Power
The Hikvision DS-2CE57D3T-VPITF operates on a DC power supply, with a maximum consumption of 4.6 W and an output of 12 V, ensuring stable performance suitable for electronic devices.
Image Sensor
Equipped with a CMOS sensor, this model ensures excellent image quality with a single sensor for effective detection. The progressive scan technology allows for the complete display of each image, guaranteeing a smooth visual experience.
Lens System
The lens system features a single lens with a maximum aperture of 1.2 and a fixed focal length of 3.6 mm, allowing for impressively sharp images.
Environmental Conditions
This model operates within a temperature range of -40 to 60 °C, with a relative humidity of operation from 0 to 90 %, ensuring optimal use in various environments.
Weight and Dimensions
The diameter of the device is 110.4 mm, and it weighs 487 g, making it easy to handle. Its height is 82.4 mm, allowing for harmonious integration into different spaces.
Night Vision
The Hikvision DS-2CE57D3T-VPITF is equipped with a night vision function, with a detection range of up to 30 meters, ensuring effective monitoring even in darkness.
Packaging Contents
This model comes with a camera, allowing for high-quality image capture right out of the box.
Video
The maximum resolution is 1920 x 1080 pixels, ensuring exceptional image clarity for your professional and personal needs. With a total of 2 MP, it meets quality requirements for 1080p video. Supported analog signal formats include NTSC and PAL, ensuring broad compatibility. Noise reduction is also included, providing an enhanced visual and auditory experience. Image quality settings include brightness, contrast, digital noise reduction, mirror, and sharpness, allowing for personalized adjustments. Additionally, highlight compensation (HLC) and intelligent IR features further enhance the user experience, with a frame rate of 30 fps for optimal smoothness.
Network
This model does not have Ethernet/LAN connectivity, nor Wi-Fi or Bluetooth functionality, thus limiting certain wireless connectivity options.
