Technical Specifications Z42
General Information
-
ModelZ42
-
Brand
-
Category
-
Type
-
SKU1204139
-
MPN1204139
Packaging contents
-
Number of cameras1
Representation / realization
-
TypeIP security camera
-
Supported installationOutdoor
-
Connectivity technologyWired
-
Large dynamic range (WRD)Yes
-
Large dynamic range (WRD)Yes
-
Large dynamic range (WRD)Yes
Network
-
BluetoothNo
-
BluetoothNo
-
Network standardsIEEE 802.3af
-
Supported network protocolsIPv4/v6, TCP, UDP, DHCP, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, UPnP, QoS, SSL
-
Ethernet/LANYes
-
Type of Ethernet interfaceFast Ethernet
-
Ethernet/LANYes
Power
-
Power supply typeDC, PoE
-
Output CC in volts12
-
Energy consumption (Power over Ethernet (PoE))6.5 W
Weight and dimensions
-
Weight1000 g
-
Width86.4 mm
-
Depth240.3 mm
-
Height75.6 mm
Environmental conditions
-
Operating temperature-30 - 60 °C
-
Operating relative humidity (H-H)10 - 95 %
Design
-
FormatTerminal
-
Mounting typeCeiling/wall
-
Product colorWhite
-
Material of the case/bodyMetal
-
Protection functionsAnti-vandalism
-
Weather-resistantYes
-
International Protection Code (IP)IP67
-
Code IKIK10
Storage support
-
Built-in memory card readerYes
-
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Integrated hard driveNo
-
Maximum memory card size256 GB
Connectivity
-
Number of Ethernet LAN ports (RJ-45)1
Management features
-
Web BrowserYes
-
Web BrowserYes
-
Behavior analysisIntrusion detection, Line crossing detection
Security
-
Alert notification typeE-mail, Snapshot alert message
-
MirrorYes
-
MirrorYes
-
MirrorYes
-
MirrorYes
-
Password protectionUser
-
MirrorYes
-
Functions of the IVS system (intelligent video surveillance)Face detection, People counting
Video
-
Video broadcastingYes
-
Video broadcastingYes
-
Video broadcastingYes
-
Video broadcastingYes
-
Noise reduction technologyDigital noise suppression 3d
-
Video broadcastingYes
-
Image quality adjustmentBrightness, Contrast, Sharpness
-
Gain control typeAuto
-
Video broadcastingYes
-
Binary rate controlConstant Bit Rate (CBR), Variable Bit Rate (VBR)
-
Number of images per second20 ips
-
Total megapixels4 MP
-
Maximum resolution2592 x 1520 pixels
-
Supported graphic resolutions352 x 288, 640 x 360, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1520, 2592 x 1520
-
Visual compression formatsH.264, H.265, M-JPEG
Objective system
-
Focal length2.8 - 12 mm
-
Maximum number of openings1.6
-
Zoom capacityYes
-
Number of lenses1
-
Optical zoom4.3 x
-
Zoom capacityYes
Image sensor
-
Sensor typeCMOS
-
Progressive scanYes
-
Number of sensors1
-
Effective pixel count (H x V)2688 x 1520 pixels
-
Optical sensor size1/3 "
Camera
-
Field of view of the lens, horizontal102.1 °
-
Angle of view of the lens, vertical55.3 °
-
Camera shutter speed1-1/100000 s
-
Camera shutter typeElectronics
-
Adjustment of shutter speedAuto/Manual
-
Minimum illumination0 lux
-
Camera tilt controlNo
-
Camera tilt controlNo
Night vision
-
Night vision distance40 m
-
Type of LEDIR
-
Night visionYes
Similar products
More product categories from brand ACTi
More product types from brand ACTi
Presentation of product Z42 specifications from brand ACTi
Packaging contents
The number of cameras of the product ACTi Z42 is 1. This product is equipped with a camera that allows capturing high-quality images.
Generalities
The brand of the product ACTi Z42 is ACTi. This brand is known for its quality and innovation in the field of household appliances. The product model ACTi Z42 is Z42 | Z42. This model ensures optimal performance and an enhanced user experience. The EAN code of the product ACTi Z42 is 4710751966536. This code allows for the unique identification of the product in the distribution system.
Network
The Wifi of the product ACTi Z42 contains Non. This Wifi allows for a fast and reliable wireless connection for all your devices. The network standards of the product ACTi Z42 are IEEE 802.3af. These standards ensure optimal compatibility with various equipment and protocols. The supported network protocols of the product ACTi Z42 are IPv4/v6, TCP, UDP, DHCP, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, UPnP, QoS, SSL. These protocols ensure efficient and reliable communication for your networking needs. Does the ACTi Z42 have Bluetooth? Non. This feature allows for a convenient wireless connection with other compatible devices. Does the product ACTi Z42 have Quality of Service (QoS)? Oui. This feature ensures optimal management of network resources, thus providing a smooth and uninterrupted user experience. The Ethernet interface type of the product ACTi Z42 is Fast Ethernet. This type of interface allows for fast and efficient network connections. Does the product ACTi Z42 have Ethernet/LAN? Oui. This specification determines the network connectivity of the product.
Representation / realization
The type of product ACTi Z42 is an island. This type of design offers a functional and aesthetic solution to optimize space in your interior. The design of the product ACTi Z42 supports vertical installation. This feature allows for optimal integration into various spaces, thus offering flexibility and practicality. Does the product ACTi Z42 have an infrared cut filter? Oui. This filter blocks infrared wavelengths, thereby improving image quality and color accuracy. The product ACTi Z42 features a Avec fil connectivity technology. This functionality allows for practical and flexible use without the constraints of cables. Does the product ACTi Z42 have a Day/Night Mode? Oui. This feature allows for adjusting the lighting according to the time of day, thus providing optimal comfort. Does the product ACTi Z42 have a Wide Range Dynamic (WRD)? Oui. This specification ensures optimal performance and increased adaptability in various conditions.
Power
The type of power source for the product ACTi Z42 is DC, PoE. This type of power supply ensures optimal performance and efficient use of the device. The product ACTi Z42 has a DC output in volts of 12. This specification ensures a stable power supply suitable for the needs of your electronic devices. The energy consumption of the product ACTi Z42 is 6.5 W. This specification allows powering devices via the Ethernet network, thus providing a practical and efficient solution to reduce the number of cables needed.
Weight and dimensions
The depth of the product ACTi Z42 is 240.3 mm. This dimension allows for optimal integration into your space. The weight of the product ACTi Z42 is 1000 g. This weight is ideal for ensuring optimal use and easy handling. The width of the product ACTi Z42 is 86.4 mm. This dimension is essential to ensure optimal integration into your space. The height of the product ACTi Z42 is 75.6 mm. This dimension is essential to ensure that the product fits perfectly in your space.
Environmental conditions
The operating temperature of the product ACTi Z42 is -30 - 60 °C. This specification ensures optimal performance within a temperature range suitable for various environments. The product ACTi Z42 has an operating relative humidity (H-H) of 10 - 95 %. This specification ensures optimal operation in a wide range of ambient humidity.
Storage support
The product ACTi Z42 has compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC. These memory cards ensure optimal performance for storing your data. Does the ACTi Z42 have a built-in memory card reader? Oui. This feature allows you to read and write data directly on memory cards, providing a convenient and efficient storage solution. The maximum size of the memory card for the product ACTi Z42 is 256 Go. This feature allows for storing a large amount of data, ideal for users who need more space. Does the ACTi Z42 have a built-in hard drive? No. This feature means that the product does not have internal storage.
Connectivity
The number of Ethernet LAN (RJ-45) ports of the product ACTi Z42 is 1. These ports provide a stable and fast network connection for your devices.
Management features
The ACTi Z42 product has web-based management. This feature allows for easy and accessible administration of your data from any device connected to the Internet. The ACTi Z42 system has behavior analysis. This feature allows for detecting intrusions, monitoring passage lines, reporting removed objects, and identifying unattended luggage. Does the product ACTi Z42 have a Web Browser? Oui. This feature allows easy access to the Internet to browse your favorite sites.
Design
The mounting type of the product ACTi Z42 is Plafond/mur. This type of mounting ensures easy and quick installation, thus guaranteeing optimal use of the product. The color of the product ACTi Z42 is Blanc. This shade gives it a modern and elegant look. The format of the product ACTi Z42 is a bar. This format allows for practical and efficient use in various contexts. The material of the product case ACTi Z42 is Métal. This material ensures both durability and elegance. The product ACTi Z42 has Anti-vandalisme protection features. These characteristics ensure reliable use in various environmental conditions. Is the ACTi Z42 weather-resistant? Oui. This product is designed to withstand the harshest weather conditions. The International Protection Code (IP) for product ACTi Z42 contains IP67. This code indicates the level of protection against solid objects and moisture. The IK Code of the product ACTi Z42 is IK10. This IK Code allows for easy identification of the specific design of the item.
Security
Does the product ACTi Z42 have HTTPS Encryption? Oui. This encryption ensures the security of the data exchanged between the user and the site. Does the ACTi Z42 product filter IP addresses? Oui. This feature enhances security by blocking unauthorized access. Does the product ACTi Z42 have a Motion Detector (video)? Oui. This device provides effective monitoring by capturing video footage during motion detections. The alert notification type for the product ACTi Z42 is E-mail, Snapshot alert message. This feature allows for real-time alerts for better security. Does the product ACTi Z42 have Password Protection? Oui. This feature ensures the security of your data by restricting unauthorized access. Does the product ACTi Z42 have Password Protection? Utilisateur. This feature ensures the security of your personal data. Does the product ACTi Z42 have a Mirror? Oui. This mirror ensures better visibility and contributes to the safety of your space. The intelligent video surveillance system of the product ACTi Z42 has features such as face detection and intrusion. These advanced functionalities ensure optimal security by enabling proactive and effective monitoring.
Objective system
The focal length of the product ACTi Z42 is 2.8 - 12 mm. This specification determines the field of view and the distance at which subjects can be captured accurately. The maximum number of openings for the product ACTi Z42 is 1.6. This feature allows for optimal use and increased flexibility. Does the ACTi Z42 have Auto focus? Oui. This feature allows for capturing sharp and accurate images by automatically adjusting the focus. The number of lenses in the product ACTi Z42 is 1. This number determines the quality and versatility of the lens. The optical zoom of the product ACTi Z42 is 4.3 x. This zoom allows for capturing precise details from a distance, thus providing superior image quality. Does the product ACTi Z42 have zoom capacity? Oui. This feature allows you to capture precise details, even from a distance.
Image sensor
The number of sensors of the product ACTi Z42 is 1. This number of sensors allows for precise and efficient image detection. The sensor type of the product ACTi Z42 is CMOS. This type of sensor ensures optimal image quality for your needs. Does the product ACTi Z42 have a Progressive Scan? Oui. This feature allows for superior image quality by displaying each image in its entirety, thus providing a smoother and sharper visual experience. The effective pixel count (H x V) of the product ACTi Z42 is 2688 x 1520 pixels. This specification ensures accurate and detailed image quality. The optical sensor size of the product ACTi Z42 is 1/3 ". This size contributes to better image quality, allowing for sharper and more detailed shots.
Video
Does the product ACTi Z42 have Scrolling and mirroring? Oui. This feature allows for a smooth and immersive visual experience. Does the product ACTi Z42 have noise reduction? Oui. This feature allows for an optimal sound experience by minimizing external distractions. Does the product ACTi Z42 have Personal Data Masking? Oui. This feature ensures the protection of users' personal information when streaming videos. Does the product ACTi Z42 have Text Overlay? Oui. This feature allows you to add text captions directly on the video for better understanding. The product ACTi Z42 features advanced noise reduction technology. This technology effectively eliminates noise disturbances, providing an optimal visual and auditory experience. Does the product ACTi Z42 have a Brightness Compensation? Oui. This feature allows for automatic adjustment of the image brightness for a better visual experience. The image quality setting of the product ACTi Z42 contains Brightness, Contrast, Sharpness. This setting allows for optimizing the display for an enhanced visual experience. Does the product ACTi Z42 have a video broadcast? Oui. This feature allows sharing content in real-time with a large audience. The binary bitrate control of the product ACTi Z42 contains Constant Bit Rate (CBR), Variable Bit Rate (VBR). This control allows for optimizing video quality while effectively managing file sizes. The number of frames per second of the product ACTi Z42 is 20 ips. This specification ensures optimal smoothness when playing videos. The gain control type of the product ACTi Z42 is Auto/Manual. This type of control allows for easy adjustment of the gain level according to needs, thus providing optimal flexibility for your video recordings. The total megapixels of the product ACTi Z42 is 4 MP. This total ensures exceptional image quality for your photos. The maximum resolution of the product ACTi Z42 is 2592 x 1520 pixels. This resolution ensures prints of exceptional clarity, ideal for all your professional and personal needs. The supported graphic resolutions of the product ACTi Z42 are 352 x 288,640 x 360,704 x 576,1280 x 720 (HD 720),1920 x 1080 (HD 1080),2048 x 1520,2592 x 1520. These resolutions provide optimal display quality for your content. The product ACTi Z42 has visual compression formats: H.264, H.265, M-JPEG. These formats ensure optimal image quality for your videos.
Camera
The field of view of the ACTi Z42 lens is 102.1 °. This field of view allows for capturing images with a wide perspective, ideal for landscapes and group shots. The type of shutter of the camera of the product ACTi Z42 is Électronique. This type of shutter allows for precise and fast image capture, ideal for action photography. The shutter speed of the camera of the product ACTi Z42 is 1-1/100000 s. This feature allows capturing sharp images even in low light conditions. The vertical field of view of the product ACTi Z42 is 55.3 °. This field of view allows for image capture with an expanded perspective, ideal for dynamic compositions. The ability to adjust the shutter speed of the product ACTi Z42 is Auto/Manual. This adjustment allows for precise image capture, whether in automatic mode for simplified use or in manual mode for total creative control. The minimum illumination of the product ACTi Z42 is 0 lux. This feature ensures optimal performance even in low light conditions. The tilt command of the ACTi Z42 camera is %. This feature allows you to adjust the viewing angle to capture images from different perspectives. Does the product ACTi Z42 have a camera pan command? No. This feature is not available on this model.
Night vision
The type of LED of the product ACTi Z42 is IR. This type of LED allows for optimal night vision, ensuring image clarity even in darkness. The night vision distance of the product ACTi Z42 is 40 m. This feature allows for clear and precise observation even in darkness. Does the product ACTi Z42 have night vision? Oui. This feature allows for clear visibility in the dark, thus providing enhanced security.
